BAS16T
BAW56T
BAV70T
BAV99T
150mW 85Volt
Switching Diode
Features
•
•
•
•
Ultra-Small Surface Mount Package
For General Purpose Switching Applications
High Conductance
Case Material: Molded Plastic.
Classification Rating 94V-0
UL Flammability
BAS16T
Marking : A2
BAW56T
Marking : JD
BAV70T
Marking : JJ
BAV99T
Marking : JE
SOT-523
A
D
Maximum Ratings
•
•
Operating Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
B
G
C
Electrical Characteristics @ 25°C Unless Otherwise Specified
Peak Repetitive
Reverse Voltage
Continuous
Forward Current
Power Dissipation
Peak Forward Surge
Current @t=1.0us
@t=1.0ms
@t=1.0s
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Total
Capacitance
Reverse Recovery
Time
V
RRM
I
F
P
D
I
FSM
85V
75mA
150mW
4.0A
1.0A
0.5A
715mV
855mV
1000mV
1250mV
2µA
0.03µA
1.5pF
4nS
I
F
= 1mA
I
F
= 10mA;
I
F
= 50mA
I
F
= 150mA
V
R
=75Volts
V
R
=25Volts
Measured at
1.0MHz, V
R
=0V
IF = IR = 10mA,
Irr = 0.1 x IR,
RL = 100Ω
G
E
H
J
K
DIMENSIONS
INCHES
MIN
MAX
.059
.067
.030
.033
.057
.069
.020 Nominal
.035
.043
.000
.004
.028
.031
.004
.008
.010
.014
MM
MIN
MAX
1.50
1.70
0.75
0.85
1.45
1.75
0.50Nominal
0.90
1.10
.000
.100
.70
0.80
.100
.200
.25
.35
V
F
I
R
DIM
A
B
C
D
E
G
H
J
K
NOTE
C
T
T
rr
Revision: 3
www.mccsemi.com
1 of 3
2006/05/13
BAS16T/BAW56T
BAV70T/BAV99T
MCC
Micro Commercial Components
1
TM
300
250
I
F
, FORWARD CURRENT (mA)
200
Single diode loaded
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
0.1
T
A
= 150ºC
T
A
= 75ºC
T
A
= 25ºC
T
A
= 0ºC
T
A
= -40ºC
150
100
Double diode loaded
0.01
50
0
0
50
100
150
200
0.001
0
0.5
1.0
1.5
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Forward Characteristics
10
1
V
R
= 75V
V
R
= 20V
0.1
0.01
0.001
0.0001
0
50
100
150
200
T
j
, JUNCTION TEMPERATURE (°C)
Fig. 3, Typical Reverse Characteristics
Revision: 3
www.mccsemi.com
2 of 3
2006/05/13
MCC
Micro Commercial Components
TM
***IMPORTANT NOTICE***
Micro Commercial Components Corp
.
reserves the right to make changes without further notice to any
product herein to make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components Corp
.
does not assume any liability arising out of the application or
use of any product described herein; neither does it convey any license under its patent rights ,nor
the rights of others . The user of products in such applications shall assume all risks of such use
and will agree to hold
Micro Commercial Components Corp
.
and all the companies whose
products are represented on our website, harmless against all damages.
***APPLICATIONS DISCLAIMER***
Products offer by
Micro Commercial Components Corp
.
are not intended for use in Medical,
Aerospace or Military Applications.
www.mccsemi.com
Revision: 3
3 of 3
2006/05/13
