LCD BACK LIGHT
KB1805YC
YELLOW
Features
!
LOW
Description
The Yellow source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide
Yellow Light Emitting Diode.
POWER REQUIREMENTS.
AREA, UNIFORM, BRIGHT LIGHT
!
LARGE
EMITTING SURFACE.
!
EASY
!
LOW
FOR INSTALLATION.
POWER CONSUMPTION.
Package Dimensions & Internal Circuit Diagram
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subjected to change without notice.
SPEC NO:DSAB2394
APPROVED : J. Lu
REV NO: V.1
CHECKED :Joe Lee
DATE:MAY/09/2002
DRAWN: Y.G
PAGE: 1 OF 3
Selection Guide
Iv (L u x )
@ 20 m A
Min .
KB1805YC
YELLOW (GaAsP/GaP)
WATER CLEAR
_
Ty p .
515
P ar t N o .
Dic e
L en s Ty p e
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
p e a k
λ
D
∆λ
1/2
V
F
I
R
P ar am et er
Peak Wavelength
Dominate Wavelength
Spectral Line Half-width
Forward Voltage
Reverse Current
Mi n
_
_
_
_
_
Ty p .
590
588
35
10.5
_
Max .
_
_
_
11
10
Un its
nm
nm
nm
V
uA
Tes t Co n d it io n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
F
=360mA
V
R
= 12V
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
Yello w
105
30
140
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un its
mW
mA
mA
V
SPEC NO:DSAB2394
APPROVED : J. Lu
REV NO: V.1
CHECKED :Joe Lee
DATE:MAY/09/2002
DRAWN: Y.G
PAGE: 2 OF 3
