General Purpose Relays
PCB Relays
Power PCB Relay Card E
n
n
n
n
n
n
SCHRACK
1 pole 8A, 1 form C (CO) or 1 form A (NO) contact
4kV coil-contact
Vertical and horizontal version
Version with bifurcated contacts
Wash tight
RoHS compliant (Directive 2002/95/EC)
Typical applications
I/O modules, heating control, timers
F0151-B
VZ
Coil Data
Coil voltage range
6 to 60VDC
Release
voltage
VDC
0.6
1.2
2.4
4.8
6.0
Coil
resistance
Ω±15%
1)
80
1)
330
1)
1200
4700
7200
Rated coil
power
mW
450
436
480
490
500
Approvals
VDE REG.-Nr. 5146, UL E214025
Technical data of approved types on request
Contact Data
Contact arrangement
Rated voltage
Max. switching voltage
Rated current
Limiting making current,
max 4 s, duty factor 10%
Breaking capacity max.
Contact material
1 form C (CO) or 1 form A (NO)
250VAC
400VAC
8A
5A
5A
-
1250VA
AgNi0.15
8A
5A
bifurcated
15A
2000VA
AgCdO,
AgNi20
Contact style
single
contact
Frequency of operation, with/without load
Operate/release time typ.
Bounce time typ., form A/form B
Contact ratings
Type
Contact
IEC61810
AgCdO
C (CO)
AgNi20
C (CO)
AgCdO
A (NO)
AgNi20
A (NO)
AgNi0.15
A (NO)
Mechanical endurance
-
1250VA
AgNi0.15
Coil versions, DC coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
001
6
4.0
002
12
8.0
006
24
16.0
013
48
32.0
023
60
40.0
single
bifurcated
contact
contact
-1
360/72000h
7/3ms
0.5/3ms
1) Coil resistance ±10%.
All figures are given for coil without pre-energization, at ambient temperature +23°C.
Other coil voltages on request.
Load
8A, 250VAC, resistive, 70°C
8A, 250VAC, resistive 70°C
8A, 250VAC, resistive, 70°C
8A, 250VAC, resistive, 70°C
5A, 250VAC, resistive, 70°C
>20x10
6
operations
Cycles
20x10
3
20x10
3
20x10
3
30x10
3
20x10
3
Insulation Data
Initial dielectric strength
between open contacts
between contact and coil
Clearance/creepage
between contact and coil
Material group of insulation parts
Tracking index of relay base
1000V
rms
4000V
rms
≥4/4mm
IIIa
PTI225V
04-2011, Rev. 0411
www.te.com
© 2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
1
General Purpose Relays
PCB Relays
Power PCB Relay Card E
(Continued)
Other Data
PCB layout / terminal assignment
Bottom view on solder pins
SCHRACK
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Ambient temperature
-40 to +70°C
Category of environmental protection
IEC 61810
RTIII - wash tight
Terminal type
PCB-THT
Mounting distance
5mm
Weight
14g
Resistance to soldering heat THT
IEC 60068-2-20
260°C/5s
Packaging/unit
tube/20 pcs., box/400 pcs.
Vertical version
S0257-AH
S0257-AB
Horizontal version
S0257-AI
Dimensions
Vertical version
Horizontal version
S0257-AE
S0280-AH
S0281-BI
2
04-2011, Rev. 0411
www.te.com
© 2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
General Purpose Relays
PCB Relays
Power PCB Relay Card E
(Continued)
Product code structure
Type
Typical product code
SCHRACK
V23057
-A
0
006
-A
1
01
V23057
Power PCB Relay Card E
Version
A
Horizontal
B
Vertical
Version
0
Standard
Coil
Coil code: please refer to coil versions table
Contact set
A
Single contact
B
Bifurcated contact (form C/CO version only)
Contact material
1
AgNi 0.15
4
AgCdO
2
AgNi 20
Contact configuration
01
1 form C contact (1 CO)
02
1 form A contact (1 NO)
V23057-A0002-A101
Horizontal
1 form C (CO) contact
AgNi0.15
V23057-A0002-A401
AgCdO
V23057-A0006-A101
AgNi0.15
V23057-A0006-A201
AgNi 20
V23057-A0006-A401
AgCdO
V23057-B0001-A101
Vertical
AgNi0.15
V23057-B0002-A101
V23057-B0002-A201
AgNi 20
V23057-B0002-A401
AgCdO
V23057-B0006-A101
AgNi0.15
V23057-B0006-A102
1 form A (NO) contact
V23057-B0006-A201
1 form C (CO) contact
AgNi 20
V23057-B0006-A401
AgCdO
V23057-B0006-A402
1 form A (NO) contact
V23057-B3006-A101
1 form C (CO) contact
AgNi0.15
V23057-B3023-A101
This list represents the most common types and does not show all variants covered by this datasheet.
Other types on request
Product code
Version
Contact arrangement Contact material
12VDC
24VDC
6VDC
12VDC
24VDC
Coil
Part number
1393215-4
1393215-9
2-1393215-1
2-1393215-3
2-1393215-5
6-1393215-6
6-1393215-7
6-1393215-9
7-1393215-1
7-1393215-5
7-1393215-9
8-1393215-1
8-1393215-5
8-1393215-6
2-1393216-6
2-1393216-8
60VDC
04-2011, Rev. 0411
www.te.com
© 2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
3
