BAS40T/-04/-05/-06
SURFACE MOUNT SCHOTTKY BARRIER DIODE
Features
NEW PRODUCT
·
·
·
·
Low Forward Voltage Drop
Fast Switching
Ultra-Small Surface Mount Package
PN Junction Guard Ring for Transient and ESD
Protection
SOT-523
TOP VIEW
Dim
A
B
B
C
Min
0.15
0.75
1.45
¾
0.90
1.50
0.00
0.60
0.10
0.10
0.45
Max
0.30
0.85
1.75
¾
1.10
1.70
0.10
0.80
0.30
0.20
0.65
Typ
0.22
0.80
1.60
0.50
1.00
1.60
0.05
0.75
0.22
0.12
0.50
C
D
G
H
J
K
L
Mechanical Data
·
·
·
·
·
·
Case: SOT-523, Molded Plastic
Terminals: Solderable per MIL-STD-202,
Method 208
Polarity: See Diagram
Marking: See Diagram
Weight: 0.002 grams (approx.)
Ordering Information, see Sheet 2
G
H
K
N
M
A
M
N
J
D
L
All Dimensions in mm
BAS40T Marking: 43
BAS40T-04 Marking: 44
BAS40T-05 Marking: 45
BAS40T-06 Marking: 46
Maximum Ratings
@ T
A
= 25°C unless otherwise specified
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current
Non-Repetitive Peak Forward Surge Current
Power Dissipation (Note 1)
Thermal Resistance Junction to Ambient (Note 1)
Operating Junction Temperature Range
Storage Temperature Range
@ t = 1.0s
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
FSM
P
d
R
qJA
T
j
T
STG
BAS40T
40
28
200
600
150
833
-55 to +125
-65 to +150
Unit
V
V
mA
mA
mW
°C/W
°C
°C
Electrical Characteristics
@ T
A
= 25°C unless otherwise specified
Characteristic
Reverse Breakdown Voltage (Note 2)
Forward Voltage (Note 2)
Leakage Current (Note 2)
Junction Capacitance
Reverse Recovery Time
Notes:
Symbol
V
(BR)R
V
F
I
R
C
j
t
rr
Min
40
¾
¾
¾
¾
Max
¾
380
1000
200
5.0
5.0
Unit
V
mV
mV
nA
pF
ns
Test Condition
I
R
= 10mA
I
F
= 1.0mA, t
p
< 300ms
I
F
= 40mA, t
p
< 300ms
V
R
= 30V
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100W
1. Device mounted on FR-4 PC board with recommended pad layout.
2. Short duration pulse test to minimize self-heating effect.
DS30265 Rev. C-2
1 of 2
BAS40T/-04/-05/-06
