FUES1DS
1 Amp. Surface Mounted Glass Passivated Ultrafast Efficient Rectifier
Dimensions in mm.
CASE:
SMA/DO-214AC
Voltage
200 V
Current
1.0 A
R
Week code
Glass passivated junction
High current capability
The plastic material carries U/L 94 V-0
Low profile package
Easy pick and place
High temperature soldering 260 ºC 10 sec
MECHANICAL DATA
Terminals: Solder plated, solderable per IEC 68-2-20.
Standard Packaging: 4 mm. tape (EIA-RS-481).
Weight: 0.064 g.
Year code
Type No. Class
Standard soldering pad
Maximun Ratings and Electrical Characteristics at 25 °C
FUES1DS
Marking Code
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximun DC Blocking voltage
Forward current at T
L
= 75 °C
8.3 ms. peak forward surge current
(Jedec Method)
U9
(V)
(V)
(V)
200
140
200
1.0 A
30 A
0.920 V
0.865 V
2 µA
100 µA
200 nA
1 µA
25 ns
8 pF
27 °C/W
75 °C/W
-55 to + 150 °C
Max. Instantaneous Forward Voltage Drop at 1.0 A
at 0.6 A
Maximum DC Reverse Current Ta = 25 °C
at Rated DC Blocking Voltage
at 10V DC Blocking Voltage
at 10V DC Blocking Voltage
Ta = 100 °C
Ta = 25 °C
Ta = 100 °C *
(0.5/1/0.25A)
T
rr
C
j
R
th (j-l)
R
th (j-a)
T
j
- T
stg
Typical Reverse Recovery Time
Typical Thermal Resistance
(5x5 mm
2
x 130 µ Copper Area)
Operating Junction and Storage
Temperature Range
Typical Junction Capacitance (1MHz; -4V)
* Each batch is tested and certified to meet an AQL = 0.1% for this parameter.
Mar - 07
FUES1DS
Electrical Characteristics at Tj = -40 °C to + 150 °C
V
F
Max. forward voltage drop at IF = 1 A
Maximum DC Reverse Current at
rated DC Blocking Voltage
1.05 V
1500 µA
I
R
Rating And Characteristic Curves
FORWARD CURRENT DERATING CURVE
TYPICAL FORWARD CHARACTERISTIC
I
F(AV)
, average forward rectified current (A)
1.2
1
0.8
0.6
0.4
0.2
0
0
25 50 75 100 125 150 175
Lead temperature (°C)
MAXIMUM NON REPETITIVE
PEAK FORWARD SURGE CURRENT
5x5 mm
2
x130 µ
Thick Copper Land Areas
I
F
, instantaneous forward current (A)
1.4
10
2
1
0.2
0.1
T
j
= 25 °C
0.01
0.6
0.8
1
1.2
1.4
1.6
V
F
, instantaneous forward
voltage (V)
TYPICAL JUNCTION
CAPACITANCE
I
FSM
, peak forward surge current (A)
30
25
20
15
10
5
C
j
, junction capacitance (pF)
20
T
j
= 25 °C
f = 1 MHz
10
8
6
4
2
1
2 4 6
10 20
40
100
1
0.1
0.4 1.0
4
10
40 100
Number of cycles at 60 Hz
V
R
,
reverse voltage (V)
Mar - 07
