Cannon, VEAM, BIW
A Historical Achievement of Technology Leadership
Defining and Championing Innovation
Showcasing a portfolio of creativity, ITT’s “Engineered For Life” execution embraces products which have
become ubiquitous in a broad collection of markets including: Military/Aerospace, Civil Aircraft, Industrial
Instrumentation, Medical, Oil & Gas, Energy, Transportation, Telecom/Handset, Computer, Consumer, and
Automotive.
ITT’s rich interconnect history embraces contributions to both technological breakthroughs and social
movements. With one of the industry’s broadest product offerings, ITT’s interconnect products have
supported:
•
•
•
•
•
•
•
Every Free World space mission, bringing the universe to our doorstep.
Motion picture, radio, and television equipment, serving laughter and entertainment to millions.
Commercial and military communications systems, linking the voices of the world.
Computerized tools, reshaping the information highway.
Aircraft, rapid transit, and automobiles, mobilizing our expanding society.
Oil and natural gas production, powering the world’s economies.
Agricultural equipment, attacking the roots of world hunger.
First
“Cannon Plug”
4 Pole Power
Connector
Cannon pioneers
sound and film
connectors with
the M Series
Cannon creates
“K” series
connectors for
DC-1’s
The first aviation
circular & rack
panel connectors
developed by
Cannon
Cannon creates
“AN” military
plugs
Cannon develops
the first
Tri-Service
connector, the
mother of modern
day military
spec’s
Cannon originates
the first “D-Sub”
connectors
Cannon pioneers
guided missle
umbilical
connectors
Cannon develops Cannon establishes
the first “Micro” an aviation milestone
connectors
through the expansion
of Rack and Panel
Cannon partners connectors with the
BKAD/E Series
with technology
leaders to develop
the first complete
fiber optic
systems
1980
+2000
The first commercial and power connectors
Cannon connectors made possible the first
radio microphones, the first black and white
television cameras as well as the first
color television equipment.
Breakaway
Technology
Leadership
Lean
manufacturing
PHD
Internet deployed
systems
Pioneering
technologies
Quadrax
Chip-on-Flex
Cannon’s
Cannon’s AF
Firewall connectors X connector is the
first microminiature
used in early
audio connector
DC-3 transports
Cannon
founded by
James Cannon
1940
1930
1915
1920
Photo courtesy of The Academy of
Motion Pictures, Arts and Sciences.
1970
1960
1950
Cannon’s first entry
into the Medical
Electronics market
Military
Telecom
Space
Medical,
Transportation
Engineered
solutions
Growth
Stacking
Charting
the Future
The
Beginning
Power, Film,
Commercial
Aviation
ITT Interconnect Solutions
ITT Interconnect Solutions is a division of the multi-
national ITT Corporation, a $7.8 billion dollar global enter-
prise representing the brands Cannon, VEAM,
and BIW. Our connector portfolio remains the most
extensive in the industry offering the most reliable and
cost effective range of interconnect solutions. These
innovations have enabled ITT to provide products and
technologies to such markets as:
•
•
•
•
•
•
•
Automotive
Computer/Consumer
Industrial/Instrumentation
Military/Aerospace
Oil Fields
Telecom/Handset
Transportation
prices. Our capabilities, especially in robotics, computer-
ized precision tooling, Kaizen Project Management, Six
Sigma tools, and testing, give ITT the most optimized
global manufacturing footprint in the interconnect
industry.
The Custom Difference
As the industry leader in harsh environment interconnect
applications, ITT’s world class engineering teams will
work directly with our customers to design and develop
cost effective solutions for their applications. In many
cases we may modify one of our standard designs to
ensure a highly reliable solution where timing is critical.
Yet, in those cases where a complete custom inter-
connect solution is required, ITT will work with our
customer’s Engineers to design an interconnect
solution which will be cost effective yet highly reliable.
As professional consultants, our Engineering teams will
provide a thorough systems and mechanical analysis of
any proposed solution. These analyses provide our
customers with sophisticated electrical signal and
mechanical characterizations to determine the best
solution for their application.
When you specify a Cannon, VEAM or BIW connector,
you can rely on a product designed, developed, and
manufactured to the highest quality and reliability
standards. This tradition of excellence is based on ITT’s
corporate culture of operating its businesses under the
principles of Six Sigma. At ITT, Six Sigma is not just a
quality philosophy but a complete corporate culture that
drives the entire business. Our Value BasedManagement
and Value Based Product Development systems are two
cornerstones that allow for the development of both
leadership and product engineering principles, ensuring
the correct industry leading products are developed to
the accepted market driven lead time s. These principles
have allowed ITT to become the market leader in all of
our business portfolios.
RoHS Compliance Information
ITT has implemented a strict parts control plan for all ITT
electronics plants worldwide that allows the Cannon,
VEAM, and BIW connector product portfolios to meet the
requirements of European Union Directive 2002/95/EC
better know as the Reduction of Hazardous Substances
initiative. As appropriate, specific Cannon, VEAM, and
BIW products may be ordered with an R prefix number
which insures our custo mers will receive RoHS compliant
parts for their commercial electronics applications and
equipment. Since most RoHS hazardous substances
center around specific metal plating and lead solder
coatings, ITT's products for RoHS compliance are avail-
able in the following plating finishes: electroless nickel,
stainless steel, Anodize over aluminum and Gold plating.
It should be noted that gold plating would b e recom-
mended as the replacement for tin-lead solder when
ordering board mount connectors.
Six Sigma Manufacturing
ITT operates manufacturing facilities in the United States,
Germany, Italy, Mexico, China, Japan and the UK, all of
which have particular product area strengths allowing ITT
to offer a truly global footprint to our customers. Our
facilities are world class and accommodate full vertical
integration utilizing the latest manufacturing technologies
including: automated and robotic machining centers,
Supe r Market manufacturing cells, Kanban pull systems,
and automated electrical, mechanical, and optical test
and inspection equipment. The combination of our
manufacturing strength and our advanced manufacturing
facilities allows ITT to offer products at market driven
www.ittcannon.com
Cannon Combo D
®
Table of Contents
Combo D* Introduction
................................................................................................................... 5-8
Combo D* PCB Connectors with Coaxial Contacts
–
–
–
–
–
–
–
–
–
–
90°, PCB Plug (sizes DE-DC), with metal bracket..........................................................................
90°, PCB Plug (size DD), with metal bracket. ................................................................................
90°, PCB Receptacle (sizes DE-DC) with metal bracket................................................................
90°, PCB Receptacle (sizes DD) with metal bracket......................................................................
European 90°, PCB Plug (size DE-DC), with bracket. ...................................................................
European 90°, PCB Receptacle (size DE-DC), with bracket. ........................................................
Straight PCB Plug (sizes DE-DD) .................................................................................................
Straight PCB Receptacle (sizes DE-DD) ......................................................................................
Straight, European solder pins (sizes DE-DD) ..............................................................................
Straight, European solder socket (sizes DE-DD) ..........................................................................
9
10
11
12
13
14
15
16
17
18
Combo D* PCB Connectors with High Power Contacts 40 A
– 90°, PCB Plug (sizes DE-DC), with metal bracket..........................................................................
– 90°, PCB Plug (size DD), with metal bracket. ................................................................................
– 90°, PCB Receptacle (sizes DE-DC) with metal bracket................................................................
– 90°, PCB Receptacle (sizes DD) with metal bracket.....................................................................
– 90°, PCB Plug, European footprint (sizes DE-DC), with bracket. .................................................
– 90°, PCB Plug, European footprint (size DD), with bracket. .........................................................
– 90°, PCB Receptacle, European footprint (sizes DE-DC), with bracket. ......................................
– 90°, PCB Receptacle, European footprint (size DD), with bracket. ..............................................
– Straight PCB Plug (sizes DE-DC) .................................................................................................
– Straight PCB Plug (size DD) .........................................................................................................
– Straight PCB Receptacle (sizes DE-DC) ......................................................................................
– Straight PCB Receptacle (size DD) ..............................................................................................
– Straight, European solder pins (sizes DE-DC) ..............................................................................
– Straight, European solder socket (sizes DE-DC) ..........................................................................
– Plug, Pressfit Termination ..............................................................................................................
– Receptacle, Pressfit Termination ...................................................................................................
Combo D* Connectors with empty Contact Cavities Size 8
–
–
–
–
–
–
Plug, Solder cup (sizes DE – DC) ................................................................................................. 35
Receptacle , Solder cup (Size DE-DC) ....................................................................................... 36
Plug, Crimp connectors, without contacts (sizes DE – DD) .......................................................... 37
Receptacle, Crimp connectors, without contacts (sizes DE – DD) ............................................... 38
Crimp contacts size 20 .............................................................................................................. 39-40
Loose contacts size 8 ................................................................................................................. 41-53
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Contact Arrangements
................................................................................................................ 61-62
Tooling
.............................................................................................................................................. 99
Product Safety Information
............................................................................................................
PCB Holes Pattern
....................................................................................................................... 66-98
Mounting Methods
...........................................................................................................................59
101
www.ittcannon.com
4
Cannon Combo D
®
Combination D Subminiature connectors for the advan-
tages of an industry standard shield I/O interconnect, with
the flexibility of a customized special, designed for any
application.
Applications
• Video Coaxial Transmission (75 )
• RF and Telecom Transmission (50 )
• Power interconnects (Up to 40 A)
Product Features
• Standard and European Footprints
• Pre-installed 75 /50 Coaxial or High Power contacts (One
Part Number)
• Vertical Standoffs or 90° Brackets
• 90° or Straight PCB
• PC Boards up to 3,2 (.125) Thick
• PCB Variants Available with Boardlocks and/or Screw Locks
(#4-40 or M3)
• Fiber Optics (PhD)
• High Voltage up to 2800 VAC
This connector system is ideal for applications that require
optimization of space while improving overall shielding.
Combo D
®
accomplishes this by combining multiple
interconnect types into one fully shielded product,
decreasing the number I/O interfaces and reducing the
possibility of EMI/RFI leakage.
Specifications
Standard materials & finishes
Temperature Rating –55°C to 125°C
Signal Contact Current Rating 7.5 A current capacity
Signal Contact Resistance 55 millivolt max. at 7.5 test current
Signal Contact
Dielectric Withstanding Voltage 1250 VAC at Sea Level
Coaxial Current Rating 5 A
Coaxial Dielectric Withstanding Voltage
Coaxial VSWR
Coaxial Insertion Loss
Less than 1.40 + .03F for F up to 1GHz
.2dB loss at 1 GHz
High Power current Rating Up to 40 A
High Power
Dielectric Withstanding Voltage 1000 VAC at Sea Level
High Voltage Current Rating 5 A
High Voltage Contact
Dielectric Withstanding Voltage 2800 V at Sea Level
1000 VAC at Sea Level
or 50
Coaxial Impedance 75
Materials and Finishes
Connector Assembly
Shell
Description
Carbon Steel
Copper Alloy
Copper Alloy
Steel
Steel
Steel
Copper Alloy
Copper Alloy
Copper Alloy
Teflon
Thermoplastic
Material
Tin-Nickel (Industrial), Chromate/Zinc (Military)*
None
Gold over Nickel
Gold over Nickel
Tin
Tin
Tin
Gold over Nickel
Nickel
None
none
Trivalent Chromate over Zinc
Finish/Treatment
Insulator
Standoff
Bracket
Rivnut
Pin Contact
Black Polyester, UL 94V-0
Socket Contact
Boardlock
Contacts and outer shells
Ring, Retaining
Insulator (Coaxial only)
Coaxial/High Power/High Voltage Contact Assemblies
Insulator (High Voltage only)
* Cadmium and Stainless Also Available
Dimensions shown in mm
Specifications and dimensions subject to change
www.ittcannon.com
5
stm32/stm8
京公网安备 11010802033920号
EEWORLD
