RFMD Green, RoHS Compliant, Pb-Free (Z Part Number)
Package: 3x3 QFN, 16-Pin
Product Description
RFMD’s SGB-2433 is a high performance SiGe HBT MMIC amplifier utilizing a Dar-
lington configuration with an active bias network. The active bias network provides
stable current over temperature and process Beta variations. Designed to run
directly from a 3Vto5V supply the SGB-2433 does not require a drop resistor as
compared to typical Darlington amplifiers. This robust amplifier features a Class 1C
ESD rating, low thermal resistance, and unconditional stability. The SGB-2433 prod-
uct is designed for high linearity 3V gain block applications that require small size
and minimal external components. It is on chip matched to 50Ω and an external
bias inductor choke is required for the application band.
Optimum Technology
Matching® Applied
GaAs HBT
GaAs MESFET
InGaP HBT
SiGe BiCMOS
Si BiCMOS
SiGe HBT
GaAs pHEMT
Si CMOS
Si BJT
GaN HEMT
RF MEMS
GND
NC
NC
NC
RFIN
NC
NC
NC
Active
Bias
NC
NC
RFOUT
Vbias
VCC
NC
NC
Features
High Reliability SiGe HBT
Technology
Robust Class 1C ESD
Simple and Small Size
P
1dB
=6.9dBm at 1950MHz
IP
3
=18.0dBm at 1950MHz
Low Thermal
Resistance=221C/W
Applications
3V Battery Operated Applica-
tions
LO Buffer Amp
RF Pre-Driver and RF Receive
Path
NC
Parameter
Small Signal Gain
Min.
15.7
Specification
Typ.
19.1
17.2
16.2
7.7
6.9
6.2
19.5
18.0
18.0
3.5
25.0
13.4
13.6
221
Max.
18.7
Unit
dB
dB
dB
dBm
dBm
dBm
dB
dB
dB
dB
MHz
mA
dB
dB
°C/W
850MHz
1950MHz
2400MHz
850MHz
1950MHz
2400MHz
850MHz
1950MHz
2400MHz
1950MHz
Condition
Output Power at 1dB Compression
5.4
Output Third Order Intercept Point
16.0
Noise Figure
Frequency of Operation
Current, I
C
DC
21.0
4.5
4000
29.0
Input Return Loss
10.0
Output Return Loss
10.0
Thermal Resistance
Test Conditions: Z
0
=50Ω, V
CC
=3V, I
C
=25mA, T=30°C
1950MHz
1950MHz
junction to backside
RF MICRO DEVICES®, RFMD®, Optimum Technology Matching®, Enabling Wireless Connectivity™, PowerStar®, POLARIS™ TOTAL RADIO™ and UltimateBlue™ are trademarks of RFMD, LLC. BLUETOOTH is a trade-
