KGF2441P Overview

Narrow Band Low Power Amplifier, LEAD FREE, SOP-8

KGF2441P Parametric

Parameter Name	Attribute value
Maker	OKI
Objectid	2118471694
Reach Compliance Code	unknown
compound_id	11734567
Characteristic impedance	175 Ω
structure	COMPONENT
Gain	30 dB
RF/Microwave Device Types	NARROW BAND LOW POWER

Preview

Download Datasheet

View All

Electronic Components

KGF2441P

AGC Amplifier

ODRKGF2441P-02

Issue Date:Apr 8, 2005

GENERAL DESCRIPTION

The KGF2441P is a GaAs FET AGC amplifier offering a wide dynamic range of >80dB. With control over

+30dB(max.) to

–50dB(min.)

range at 130MHz, the device also provides excellent gain slope linearity. The

KGF2441P operates with a shingle 5V power supply with a low current operation of 5mA(typ.). The device is

particularly suited to IF-stage amplifier application, such as portable handy phones based on CDMA-type digital

cellular technology operating over wide dynamic ranges.

FEATURES

•

Wide dynamic range: >80dB

Excellent gain slope linearity for AGC voltage

Low current operation: 5V, 5mA(typ.)

Package: 8Pin SOP

FUNCTION DIAGRAM

GND

(8)

AGC

(7)

GND

(6)

Input

(5)

(1)

Output

(2)

DD3

(3)

DD2

(4)

DD1
