Panasonic Industrial Company
Aluminum Electrolytic Capacitors
TS-UP Series
85°C, 3000 hours
RoHS
Compliant
Compact size for general purpose and industrial applications
2 and 3 pin versions available
20mm lengths for low profile applications
Rated Working Voltage:
Operating Temperature:
Nominal Capacitance:
Capacitance Tolerance:
Dissipation Factor:
(120 Hz, +20°C)
Leakage Current:
Ripple Current Multipliers:
16 ~ 250 VDC
-40 ~ +85°C
120 ~ 68000µF
± 20%
Working Voltage [V]:
Max. D.F. (%):
16
50
25
40
35
35
50
30
63
25
80
20
100
20
160 ~ 500
15
350 ~ 500 VDC
-25 ~ +85°C
33 ~ 820µF
For capacitance values > 33000µF, add the value of:
(rated cap. [µF] - 33000 )
1000
3 CV (µA) max. after 5 minutes;
C = Capacitance in µF, V = WV
Frequency(Hz):
16~100WV:
160~450WV:
50
0.93
0.75
60
0.95
0.8
100~120
1.0
1.0
500
1.05
1.2
1k
1.08
1.25
10k
1.15
1.4
Ripple Current Ambient Temperature Factors**
Temperature (°C): 85°C
70°C
60°C
Multiplier: 1.0
1.3
1.4
45°C
1.5
Endurance:
3000 hours* at +85°C with maximum specified ripple current (see page 4)
*2000 hours for 20mm length sizes
**Use of temperature ripple current multipliers may limit life to the hours specified for the maximum operating temperature.
Part Number System
E
C
O
S
P
Series
Code
Terminal Style
Prefix Length # of Pins
ECOS
6.3mm
2
ECEC
4.0mm
2
ECE3
4.0mm
3
Capacitance
Code
A
X
L
Suffix
Standard Ratings
Extended CV Ratings
20mm Length Ratings
RoHS compliant PVC sleeve and top
plate is standard. PET sleeve is
available without top plate.
1C
16
1E
25
1V
35
1H
50
1J
63
Voltage Code
1K 2A 2C 2D 2E 2V 2T 2G 2S 2W 2H
80 100 160 200 250 350 385 400 420 450 500
Diameter
Diameter
Code
22
B
25
C
30
D
35
E
Dimensions in millimeters
2 Pin Mounting Style
10.0±0.1
Circuit Board Mounting Holes
L+2 max.
T
D+1 max.
2 x Ø2.0±0.1
10.0±0.1
Circuit Board Mounting Holes
Ø2.0±0.1
4.75±0.1
3.3±0.1
3 Pin Mounting Style
L+2 max.
T
D+1 max.
Ø2.0±0.1
Ø2.5 min.
Pin Dimensions
2.0 max.
0.8
+0.2
-0.1
2.0 max.
4.0
1.5±0.2
6.3±1.0
Top of Capacitor Body
0.8
-0.1
3.5
1.5±0.2
4.0±0.5
+0.2
"T" 6.3mm Length: Standard on 2 Pin Mounting Style
4mm Length: Standard on 3 Pin, Available on 2 Pin Mounting Styles
14
Design and specifications are subject to change without notice.
Contact the factory or your sales representative for technical specifications before purchase and/or use.
When safety concerns arise, please contact Panasonic immediately for technical consultation.
Panasonic Industrial Company
TS-UP Standard Ratings
Cap.
(µF)
4700
6800
8200
10000
Size (mm)
DxL
22
22
22
25
22
22
25
30
22
25
22
25
35
22
25
22
25
30
25
30
25
30
35
30
35
30
35
35
35
22
22
22
25
22
22
25
30
22
25
22
25
30
35
22
25
30
22
25
30
25
30
25
30
30
35
30
35
35
35
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
20
25
25
20
25
30
25
20
30
25
35
30
20
40
30
45
35
30
45
35
50
40
30
45
35
50
40
45
50
20
25
25
20
25
30
25
20
30
25
35
30
25
20
40
35
30
50
40
30
45
35
50
40
45
35
50
40
45
50
Max 85°C R.C. (A
rms
)
120Hz
1.60
1.77
2.57
1.80
3.10
3.78
3.78
2.40
4.52
4.52
5.26
5.26
3.20
5.57
5.57
6.10
6.10
6.10
6.31
6.31
6.84
6.84
6.84
6.94
6.94
7.47
7.47
8.73
9.05
1.60
1.68
2.39
1.80
2.86
3.47
3.47
2.30
3.57
3.57
3.78
3.78
3.78
2.70
4.10
4.10
4.10
4.63
4.63
4.63
5.47
5.47
6.10
6.10
6.21
6.21
6.84
6.84
7.36
8.00
1.40
1.52
20°C ESR ( , max.)
10kHz~
120Hz
20kHz
16 VDC Working,
20 VDC Surge
1.84
0.159
0.135
2.04
0.159
0.135
2.96
0.110
0.093
2.07
0.110
0.093
3.57
0.091
0.077
4.35
0.075
0.063
4.35
0.075
0.063
2.76
0.083
0.070
5.20
0.062
0.053
5.20
0.062
0.053
6.05
0.053
0.045
6.05
0.053
0.045
3.68
0.055
0.047
6.41
0.046
0.039
6.41
0.046
0.039
7.02
0.038
0.032
7.02
0.038
0.032
7.02
0.038
0.032
7.26
0.031
0.026
7.26
0.031
0.026
7.87
0.025
0.021
7.87
0.025
0.021
7.87
0.025
0.021
7.98
0.021
0.018
7.98
0.021
0.018
8.59
0.019
0.017
8.59
0.021
0.019
10.04
0.019
0.018
10.41
0.018
0.017
25 VDC Working,
32 VDC Surge
1.84
0.176
0.141
1.93
0.161
0.129
2.75
0.113
0.090
2.07
0.123
0.099
3.29
0.095
0.076
3.99
0.078
0.062
3.99
0.078
0.062
2.65
0.078
0.062
4.11
0.065
0.052
4.11
0.065
0.052
4.35
0.058
0.046
4.35
0.058
0.046
4.35
0.058
0.046
3.11
0.061
0.049
4.72
0.048
0.039
4.72
0.048
0.039
4.72
0.048
0.039
5.32
0.039
0.031
5.32
0.039
0.031
5.32
0.039
0.031
6.29
0.035
0.028
6.29
0.035
0.028
7.02
0.029
0.023
7.02
0.029
0.023
7.14
0.023
0.019
7.14
0.025
0.020
7.87
0.020
0.017
7.87
0.020
0.017
8.46
0.019
0.017
9.20
0.017
0.015
35 VDC Working,
44 VDC Surge
1.61
0.181
0.136
1.75
0.166
0.124
Aluminum Electrolytic Capacitors
Part numbers shown with 2 pins
Panasonic Part Number (By Terminal Length)
6.3mm Length Terminal
4.0mm Length Terminal
ECOS1CP472BL
ECOS1CP472BA
ECOS1CP682BA
ECOS1CP682CL
ECOS1CP822BA
ECOS1CP103BA
ECOS1CP103CA
ECOS1CP103DL
ECOS1CP123BA
ECOS1CP123CA
ECOS1CP153BA
ECOS1CP153CA
ECOS1CP153EL
ECOS1CP183BA
ECOS1CP183CA
ECOS1CP223BA
ECOS1CP223CA
ECOS1CP223DA
ECOS1CP273CA
ECOS1CP273DA
ECOS1CP333CA
ECOS1CP333DA
ECOS1CP333EA
ECOS1CP393DA
ECOS1CP393EA
ECOS1CP473DA
ECOS1CP473EA
ECOS1CP563EA
ECOS1CP683EA
ECOS1EP332BL
ECOS1EP332BA
ECOS1EP472BA
ECOS1EP472CL
ECOS1EP562BA
ECOS1EP682BA
ECOS1EP682CA
ECOS1EP682DL
ECOS1EP822BA
ECOS1EP822CA
ECOS1EP103BA
ECOS1EP103CA
ECOS1EP103DA
ECOS1EP103EL
ECOS1EP123BA
ECOS1EP123CA
ECOS1EP123DA
ECOS1EP153BA
ECOS1EP153CA
ECOS1EP153DA
ECOS1EP183CA
ECOS1EP183DA
ECOS1EP223CA
ECOS1EP223DA
ECOS1EP273DA
ECOS1EP273EA
ECOS1EP333DA
ECOS1EP333EA
ECOS1EP393EA
ECOS1EP473EA
ECOS1VP222BL
ECOS1VP222BA
ECEC1CP472BL
ECEC1CP472BA
ECEC1CP682BA
ECEC1CP682CL
ECEC1CP822BA
ECEC1CP103BA
ECEC1CP103CA
ECEC1CP103DL
ECEC1CP123BA
ECEC1CP123CA
ECEC1CP153BA
ECEC1CP153CA
ECEC1CP153EL
ECEC1CP183BA
ECEC1CP183CA
ECEC1CP223BA
ECEC1CP223CA
ECEC1CP223DA
ECEC1CP273CA
ECEC1CP273DA
ECEC1CP333CA
ECEC1CP333DA
ECEC1CP333EA
ECEC1CP393DA
ECEC1CP393EA
ECEC1CP473DA
ECEC1CP473EA
ECEC1CP563EA
ECEC1CP683EA
ECEC1EP332BL
ECEC1EP332BA
ECEC1EP472BA
ECEC1EP472CL
ECEC1EP562BA
ECEC1EP682BA
ECEC1EP682CA
ECEC1EP682DL
ECEC1EP822BA
ECEC1EP822CA
ECEC1EP103BA
ECEC1EP103CA
ECEC1EP103DA
ECEC1EP103EL
ECEC1EP123BA
ECEC1EP123CA
ECEC1EP123DA
ECEC1EP153BA
ECEC1EP153CA
ECEC1EP153DA
ECEC1EP183CA
ECEC1EP183DA
ECEC1EP223CA
ECEC1EP223DA
ECEC1EP273DA
ECEC1EP273EA
ECEC1EP333DA
ECEC1EP333EA
ECEC1EP393EA
ECEC1EP473EA
ECEC1VP222BL
ECEC1VP222BA
12000
15000
18000
22000
27000
33000
39000
47000
56000
68000
3300
4700
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
39000
47000
2200
22 x 20
22 x 25
Design and specifications are subject to change without notice.
Contact the factory or your sales representative for technical specifications before purchase and/or use.
When safety concerns arise, please contact Panasonic immediately for technical consultation.
15
Panasonic Industrial Company
TS-UP Standard Ratings (continued)
Cap.
(µF)
3300
3900
4700
Size (mm)
DxL
22
25
22
22
25
30
22
25
22
25
35
22
25
22
25
30
35
25
30
35
25
30
35
30
35
30
35
35
35
22
22
22
25
22
22
25
30
22
25
22
25
30
35
22
25
30
22
25
30
25
30
25
30
35
30
35
30
35
35
35
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
25
20
25
30
25
20
30
25
35
30
20
40
35
45
40
30
25
45
35
30
50
40
30
45
35
50
40
45
50
20
25
25
20
25
30
25
20
30
25
35
30
25
20
40
35
30
50
40
30
45
35
50
40
30
45
35
50
40
45
50
120Hz
2.29
1.70
2.71
3.26
3.26
2.00
3.36
3.36
3.68
3.68
2.40
4.00
4.00
4.42
4.42
4.42
4.42
5.05
5.05
5.05
5.57
5.57
5.57
5.68
5.68
6.10
6.10
6.84
7.15
1.20
1.24
1.82
1.40
2.23
2.73
2.73
1.70
2.75
2.75
3.03
3.03
3.03
2.10
3.42
3.42
3.42
3.85
3.85
3.85
4.41
4.41
4.97
4.97
4.97
5.58
5.58
6.44
6.44
6.94
7.57
1.20
Max 85°C R.C. (A
rms
)
Aluminum Electrolytic Capacitors
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
1500
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
1000
22 x 20
Part numbers shown with 2 pins
20°C ESR ( , max.)
Panasonic Part Number (By Terminal Length)
6.3mm Length Terminal
10kHz~
120Hz
20kHz
4.0mm Length Terminal
35 VDC Working,
44 VDC Surge (continued)
ECEC1VP332BA
ECOS1VP332BA
2.63
0.111
0.083
ECOS1VP332CL
ECEC1VP332CL
1.96
0.121
0.090
ECEC1VP392BA
ECOS1VP392BA
3.12
0.094
0.070
ECEC1VP472BA
ECOS1VP472BA
3.75
0.078
0.058
ECEC1VP472CA
ECOS1VP472CA
3.75
0.078
0.058
ECEC1VP472DL
ECOS1VP472DL
2.30
0.088
0.066
ECEC1VP562BA
ECOS1VP562BA
3.86
0.080
0.060
ECOS1VP562CA
ECEC1VP562CA
3.86
0.080
0.060
ECOS1VP682BA
ECEC1VP682BA
4.23
0.066
0.049
ECOS1VP682CA
ECEC1VP682CA
4.23
0.066
0.049
ECOS1VP682EL
ECEC1VP682EL
2.76
0.071
0.053
ECEC1VP822BA
ECOS1VP822BA
4.60
0.057
0.042
ECOS1VP822CA
ECEC1VP822CA
4.60
0.057
0.042
ECOS1VP103BA
ECEC1VP103BA
5.08
0.050
0.037
ECOS1VP103CA
ECEC1VP103CA
5.08
0.050
0.037
ECOS1VP103DA
ECEC1VP103DA
5.08
0.050
0.037
ECOS1VP103EA
ECEC1VP103EA
5.08
0.050
0.037
ECOS1VP123CA
ECEC1VP123CA
5.81
0.044
0.033
ECOS1VP123DA
ECEC1VP123DA
5.81
0.044
0.033
ECOS1VP123EA
ECEC1VP123EA
5.81
0.044
0.033
ECEC1VP153CA
ECOS1VP153CA
6.41
0.036
0.027
ECOS1VP153DA
ECEC1VP153DA
6.41
0.036
0.027
ECOS1VP153EA
ECEC1VP153EA
6.41
0.036
0.027
ECOS1VP183DA
ECEC1VP183DA
6.53
0.030
0.023
ECOS1VP183EA
ECEC1VP183EA
6.53
0.030
0.023
ECOS1VP223DA
ECEC1VP223DA
7.02
0.026
0.020
ECOS1VP223EA
ECEC1VP223EA
7.02
0.026
0.020
ECEC1VP273EA
ECOS1VP273EA
7.87
0.021
0.017
ECOS1VP333EA
ECEC1VP333EA
8.22
0.018
0.014
50 VDC Working,
63 VDC Surge
ECEC1HP152BL
ECOS1HP152BL
1.38
0.254
0.191
ECOS1HP152BA
ECEC1HP152BA
1.43
0.221
0.166
ECOS1HP222BA
ECEC1HP222BA
2.09
0.151
0.113
ECOS1HP222CL
ECEC1HP222CL
1.61
0.173
0.130
ECOS1HP272BA
ECEC1HP272BA
2.56
0.123
0.092
ECEC1HP332BA
ECOS1HP332BA
3.14
0.100
0.075
ECOS1HP332CA
ECEC1HP332CA
3.14
0.100
0.075
ECOS1HP332DL
ECEC1HP332DL
1.96
0.116
0.087
ECOS1HP392BA
ECEC1HP392BA
3.16
0.085
0.064
ECOS1HP392CA
ECEC1HP392CA
3.16
0.085
0.064
ECOS1HP472BA
ECEC1HP472BA
3.48
0.071
0.053
ECOS1HP472CA
ECEC1HP472CA
3.48
0.071
0.053
ECOS1HP472DA
ECEC1HP472DA
3.48
0.071
0.053
ECOS1HP472EL
ECEC1HP472EL
2.42
0.081
0.061
ECOS1HP562BA
ECEC1HP562BA
3.93
0.059
0.044
ECOS1HP562CA
ECEC1HP562CA
3.93
0.059
0.044
ECOS1HP562DA
ECEC1HP562DA
3.93
0.059
0.044
ECOS1HP682BA
ECEC1HP682BA
4.43
0.049
0.037
ECOS1HP682CA
ECEC1HP682CA
4.43
0.049
0.037
ECOS1HP682DA
ECEC1HP682DA
4.43
0.049
0.037
ECOS1HP822CA
ECEC1HP822CA
5.07
0.040
0.030
ECOS1HP822DA
ECEC1HP822DA
5.07
0.040
0.030
ECOS1HP103CA
ECEC1HP103CA
5.72
0.036
0.027
ECOS1HP103DA
ECEC1HP103DA
5.72
0.036
0.027
ECOS1HP103EA
ECEC1HP103EA
5.72
0.036
0.027
ECOS1HP123DA
ECEC1HP123DA
6.42
0.032
0.024
ECOS1HP123EA
ECEC1HP123EA
6.42
0.032
0.024
ECOS1HP153DA
ECEC1HP153DA
7.41
0.028
0.021
ECOS1HP153EA
ECEC1HP153EA
7.41
0.028
0.021
ECOS1HP183EA
ECEC1HP183EA
7.98
0.023
0.018
ECOS1HP223EA
ECEC1HP223EA
8.71
0.021
0.017
63 VDC Working,
79 VDC Surge
ECEC1JP102BL
ECOS1JP102BL
1.38
0.381
0.286
16
Design and specifications are subject to change without notice.
Contact the factory or your sales representative for technical specifications before purchase and/or use.
When safety concerns arise, please contact Panasonic immediately for technical consultation.
Panasonic Industrial Company
TS-UP Standard Ratings (continued)
Cap.
(µF)
1000
1500
1800
2200
Size (mm)
DxL
22
22
25
22
22
25
30
22
25
22
25
30
35
22
25
30
22
25
30
35
25
30
35
25
30
35
30
35
35
35
22
22
22
25
22
22
25
30
22
25
22
25
30
35
22
25
30
22
25
30
25
30
25
30
30
35
30
35
35
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
25
25
20
25
30
25
20
35
30
40
30
25
20
45
35
30
50
40
30
25
45
35
30
50
40
30
45
35
40
50
20
25
25
20
25
30
25
20
35
30
40
30
25
20
45
35
30
50
40
30
45
35
50
40
45
35
50
40
50
Aluminum Electrolytic Capacitors
2700
3300
3900
4700
5600
6800
8200
10000
12000
680
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
Part numbers shown with 2 pins
Max 85°C R.C. (A
rms
)
20°C ESR ( , max.)
Panasonic Part Number (By Terminal Length)
6.3mm Length Terminal
120Hz
10kHz~
120Hz
20kHz
4.0mm Length Terminal
63 VDC Working,
79 VDC Surge (continued)
ECOS1JP102BA
ECEC1JP102BA
1.20
1.38
0.332
0.249
ECOS1JP152BA
ECEC1JP152BA
1.72
1.98
0.221
0.166
ECEC1JP152CL
ECOS1JP152CL
1.30
1.50
0.254
0.191
ECOS1JP182BA
ECEC1JP182BA
2.06
2.37
0.184
0.138
ECEC1JP222BA
ECOS1JP222BA
2.52
2.90
0.151
0.113
ECEC1JP222CA
ECOS1JP222CA
2.52
2.90
0.151
0.113
ECEC1JP222DL
ECOS1JP222DL
1.50
1.73
0.173
0.130
ECEC1JP272BA
ECOS1JP272BA
3.73
4.29
0.123
0.092
ECEC1JP272CA
ECOS1JP272CA
3.73
4.29
0.123
0.092
ECOS1JP332BA
ECEC1JP332BA
4.10
4.72
0.105
0.079
ECOS1JP332CA
ECEC1JP332CA
4.10
4.72
0.105
0.079
ECOS1JP332DA
ECEC1JP332DA
4.10
4.72
0.105
0.079
ECEC1JP332EL
ECOS1JP332EL
1.70
1.96
0.126
0.094
ECEC1JP392BA
ECOS1JP392BA
4.44
5.11
0.098
0.073
ECEC1JP392CA
ECOS1JP392CA
4.44
5.11
0.098
0.073
ECEC1JP392DA
ECOS1JP392DA
4.44
5.11
0.098
0.073
ECEC1JP472BA
ECOS1JP472BA
4.86
5.59
0.081
0.061
ECOS1JP472CA
ECEC1JP472CA
4.86
5.59
0.081
0.061
ECOS1JP472DA
ECEC1JP472DA
4.86
5.59
0.081
0.061
ECEC1JP472EA
ECOS1JP472EA
4.86
5.59
0.081
0.061
ECEC1JP562CA
ECOS1JP562CA
5.36
6.16
0.068
0.051
ECEC1JP562DA
ECOS1JP562DA
5.36
6.16
0.068
0.051
ECEC1JP562EA
ECOS1JP562EA
5.36
6.16
0.068
0.051
ECOS1JP682CA
ECEC1JP682CA
5.84
6.72
0.061
0.046
ECOS1JP682DA
ECEC1JP682DA
5.84
6.72
0.061
0.046
ECEC1JP682EA
ECOS1JP682EA
5.84
6.72
0.061
0.046
ECEC1JP822DA
ECOS1JP822DA
6.00
6.90
0.051
0.038
ECOS1JP822EA
ECEC1JP822EA
6.00
6.90
0.051
0.038
ECOS1JP103EA
ECEC1JP103EA
6.52
7.50
0.041
0.033
ECOS1JP123EA
ECEC1JP123EA
7.15
8.22
0.035
0.028
80 VDC Working,
105 VDC Surge (continued)
ECEC1KP681BL
ECOS1KP681BL
1.00
1.15
0.439
0.329
ECEC1KP681BA
ECOS1KP681BA
1.02
1.17
0.390
0.293
ECOS1KP102BA
ECEC1KP102BA
1.51
1.74
0.265
0.199
ECOS1KP102CL
ECEC1KP102CL
1.20
1.38
0.298
0.224
ECEC1KP122BA
ECOS1KP122BA
1.81
2.08
0.221
0.166
ECEC1KP152BA
ECOS1KP152BA
2.26
2.60
0.177
0.133
ECOS1KP152CA
ECEC1KP152CA
2.26
2.60
0.177
0.133
ECOS1KP152DL
ECEC1KP152DL
1.40
1.61
0.199
0.149
ECOS1KP182BA
ECEC1KP182BA
2.52
2.90
0.147
0.111
ECEC1KP182CA
ECOS1KP182CA
2.52
2.90
0.147
0.111
ECOS1KP222BA
ECEC1KP222BA
2.73
3.14
0.121
0.090
ECOS1KP222CA
ECEC1KP222CA
2.73
3.14
0.121
0.090
ECOS1KP222DA
ECEC1KP222DA
2.73
3.14
0.121
0.090
ECOS1KP222EL
ECEC1KP222EL
1.70
1.96
0.136
0.102
ECOS1KP272BA
ECEC1KP272BA
2.78
3.20
0.098
0.074
ECEC1KP272CA
ECOS1KP272CA
2.78
3.20
0.098
0.074
ECEC1KP272DA
ECOS1KP272DA
2.78
3.20
0.098
0.074
ECEC1KP332BA
ECOS1KP332BA
3.21
3.69
0.085
0.064
ECEC1KP332CA
ECOS1KP332CA
3.21
3.69
0.085
0.064
ECOS1KP332DA
ECEC1KP332DA
3.21
3.69
0.085
0.064
ECOS1KP392CA
ECEC1KP392CA
3.59
4.13
0.077
0.057
ECEC1KP392DA
ECOS1KP392DA
3.59
4.13
0.077
0.057
ECOS1KP472CA
ECEC1KP472CA
4.09
4.70
0.063
0.048
ECOS1KP472DA
ECEC1KP472DA
4.09
4.70
0.063
0.048
ECOS1KP562DA
ECEC1KP562DA
4.55
5.23
0.056
0.042
ECEC1KP562EA
ECOS1KP562EA
4.55
5.23
0.056
0.042
ECOS1KP682DA
ECEC1KP682DA
5.16
5.93
0.046
0.035
ECOS1KP682EA
ECEC1KP682EA
5.16
5.93
0.046
0.035
ECOS1KP822EA
ECEC1KP822EA
5.83
6.70
0.038
0.029
Design and specifications are subject to change without notice.
Contact the factory or your sales representative for technical specifications before purchase and/or use.
When safety concerns arise, please contact Panasonic immediately for technical consultation.
17
Panasonic Industrial Company
TS-UP Standard Ratings (continued)
Cap.
(µF)
470
560
680
1000
Size (mm)
DxL
22
22
22
22
25
22
25
30
22
25
22
25
30
35
22
25
30
22
25
30
35
25
30
35
25
30
30
35
30
35
35
35
22
22
22
25
22
22
25
30
22
25
22
22
25
25
35
22
22
25
30
22
22
25
30
30
22
25
25
30
30
35
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
20
25
25
25
20
30
25
20
35
30
40
30
25
20
45
35
30
50
40
30
25
45
35
30
50
40
45
35
50
40
45
50
20
25
25
20
25
25
25
20
30
25
30
35
25
30
20
35
40
30
25
40
45
35
25
30
45
40
45
30
35
30
Aluminum Electrolytic Capacitors
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
220
270
330
390
470
560
680
820
1000
Part numbers shown with 2 pins
Max 85°C R.C. (A
rms
)
20°C ESR ( , max.)
Panasonic Part Number (By Terminal Length)
6.3mm Length Terminal
4.0mm Length Terminal
120Hz
10kHz~
120Hz
20kHz
100 VDC Working,
125 VDC Surge
ECOS2AP471BL
ECEC2AP471BL
1.00
1.15
0.459
0.298
ECEC2AP471BA
ECOS2AP471BA
1.11
1.28
0.459
0.298
ECEC2AP561BA
ECOS2AP561BA
1.32
1.52
0.385
0.250
ECEC2AP681BA
ECOS2AP681BA
1.61
1.85
0.317
0.206
ECEC2AP681CL
ECOS2AP681CL
1.10
1.27
0.366
0.238
ECEC2AP102BA
ECOS2AP102BA
1.96
2.25
0.216
0.140
ECEC2AP102CA
ECOS2AP102CA
1.96
2.25
0.216
0.140
ECOS2AP102DL
ECEC2AP102DL
1.20
1.38
0.249
0.162
ECOS2AP122BA
ECEC2AP122BA
2.31
2.66
0.193
0.126
ECOS2AP122CA
ECEC2AP122CA
2.31
2.66
0.180
0.117
ECOS2AP152BA
ECEC2AP152BA
2.57
2.96
0.155
0.101
ECEC2AP152CA
ECOS2AP152CA
2.57
2.96
0.155
0.101
ECOS2AP152DA
ECEC2AP152DA
2.57
2.96
0.155
0.101
ECOS2AP152EL
ECEC2AP152EL
1.50
1.73
0.177
0.115
ECOS2AP182BA
ECEC2AP182BA
2.84
3.27
0.129
0.084
ECOS2AP182CA
ECEC2AP182CA
2.84
3.27
0.138
0.090
ECOS2AP182DA
ECEC2AP182DA
2.84
3.27
0.138
0.090
ECEC2AP222BA
ECOS2AP222BA
3.14
3.61
0.121
0.078
ECOS2AP222CA
ECEC2AP222CA
3.14
3.61
0.121
0.078
ECOS2AP222DA
ECEC2AP222DA
3.14
3.61
0.121
0.078
ECOS2AP222EA
ECEC2AP222EA
3.14
3.61
0.121
0.078
ECOS2AP272CA
ECEC2AP272CA
3.71
4.27
0.104
0.068
ECEC2AP272DA
ECOS2AP272DA
3.71
4.27
0.104
0.068
ECEC2AP272EA
ECOS2AP272EA
3.71
4.27
0.104
0.068
ECEC2AP332CA
ECOS2AP332CA
4.06
4.67
0.090
0.059
ECEC2AP332DA
ECOS2AP332DA
4.06
4.67
0.090
0.059
ECOS2AP392DA
ECEC2AP392DA
4.54
5.22
0.077
0.050
ECOS2AP392EA
ECEC2AP392EA
4.54
5.22
0.081
0.052
ECOS2AP472DA
ECEC2AP472DA
5.13
5.90
0.071
0.049
ECOS2AP472EA
ECEC2AP472EA
5.13
5.90
0.071
0.049
ECOS2AP562EA
ECEC2AP562EA
5.75
6.61
0.059
0.041
ECOS2AP682EA
ECEC2AP682EA
6.60
7.59
0.049
0.037
160 VDC Working,
200 VDC Surge
ECOS2CP221BL
ECEC2CP221BL
0.75
1.05
0.980
0.490
ECOS2CP221BA
ECEC2CP221BA
0.91
1.27
0.829
0.414
ECOS2CP271BA
ECEC2CP271BA
1.19
1.67
0.675
0.338
ECOS2CP271CL
ECEC2CP271CL
0.87
1.22
0.798
0.399
ECOS2CP331BA
ECEC2CP331BA
1.45
2.03
0.553
0.276
ECOS2CP391BX
ECEC2CP391BX
1.62
2.27
0.468
0.234
ECOS2CP391CA
ECEC2CP391CA
1.62
2.27
0.468
0.234
ECOS2CP391DL
ECEC2CP391DL
1.10
1.54
0.595
0.298
ECOS2CP471BA
ECEC2CP471BA
2.11
2.95
0.423
0.212
ECOS2CP471CA
ECEC2CP471CA
2.11
2.95
0.423
0.212
ECOS2CP561BX
ECEC2CP561BX
2.25
3.15
0.355
0.178
ECOS2CP561BA
ECEC2CP561BA
2.25
3.15
0.355
0.178
ECOS2CP561CX
ECEC2CP561CX
2.25
3.15
0.355
0.178
ECOS2CP561CA
ECEC2CP561CA
2.25
3.15
0.355
0.178
ECOS2CP561EL
ECEC2CP561EL
1.30
1.82
0.414
0.207
ECOS2CP681BX
ECEC2CP681BX
2.50
3.50
0.293
0.146
ECOS2CP681BA
ECEC2CP681BA
2.50
3.50
0.293
0.146
ECOS2CP681CX
ECEC2CP681CX
2.50
3.50
0.293
0.146
ECOS2CP681DA
ECEC2CP681DA
2.50
3.50
0.293
0.146
ECOS2CP821BX
ECEC2CP821BX
2.50
3.50
0.243
0.121
ECOS2CP821BA
ECEC2CP821BA
2.75
3.85
0.263
0.131
ECOS2CP821CA
ECEC2CP821CA
2.75
3.85
0.263
0.131
ECOS2CP821DX
ECEC2CP821DX
2.75
3.85
0.263
0.131
ECOS2CP821DA
ECEC2CP821DA
2.75
3.85
0.263
0.131
ECOS2CP102BX
ECEC2CP102BX
3.00
4.20
0.216
0.108
ECOS2CP102CX
ECEC2CP102CX
3.00
4.20
0.216
0.108
ECOS2CP102CA
ECEC2CP102CA
3.00
4.20
0.232
0.128
ECOS2CP102DX
ECEC2CP102DX
3.00
4.20
0.232
0.128
ECOS2CP102DA
ECEC2CP102DA
3.00
4.20
0.232
0.128
ECOS2CP102EA
ECEC2CP102EA
3.00
4.20
0.232
0.128
18
Design and specifications are subject to change without notice.
Contact the factory or your sales representative for technical specifications before purchase and/or use.
When safety concerns arise, please contact Panasonic immediately for technical consultation.
Embedded System
京公网安备 11010802033920号
EEWORLD
