1314742

Description
1 ELEMENT, 2.2 uH, COMPOSITE-CORE, GENERAL PURPOSE INDUCTOR, SMD
CategoryThe sensor
File Size44KB,1 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

1314742 Overview

1 ELEMENT, 2.2 uH, COMPOSITE-CORE, GENERAL PURPOSE INDUCTOR, SMD

1314742 Parametric

Parameter NameAttribute value
Number of functions1
Number of terminals2
Maximum operating temperature125 Cel
Minimum operating temperature-55 Cel
Rated inductance2.2 uH
Processing package descriptionchip, 2020, green
Lead-freeYes
EU RoHS regulationsYes
stateACTIVE
isolationYes
core materialsynthesis
DC Resistance0.0501 ohm
surface mountYes
Terminal shapeWRAPAROUND
Terminal layoutDouble ENDED
Manufacturer SeriesIHLP-2020BZ-01
Inductor applicationsHigh current inductor
Shape and size descriptionRectangular PACKAGE
deviation20 %
Inductor typeUniversal inductor
1Rated value test frequency0.1000 MHz
Maximum rated current4.2 A
Product Group:
Vishay Dale/May
3, 2011/PCN-DI-120-2011 Rev 0
IHLP-2020BZ-01 data change
DESCRIPTION OF CHANGE:
The data sheet is being changed to reflect the correct data. The
Saturation Current for the 2.2µH value is changing to 9.5 Amps.
CLASSIFICATION OF CHANGE:
Assembly Process/Structure
REASON FOR CHANGE:
To correct error on the data sheet.
EXPECTED INFLUENCE ON QUALITY/RELIABILTY/PERFORMANCE:
None.
PRODUCT CATAGORY:
Inductors
PART NUMBERS/SERIES/FAMILIES AFFECTED:
IHLP2020BZER2R2M01
VISHAY BRAND(s):
Vishay Dale
TIME SCHEDULE:
Start Shipment Date: July 6, 2011
Last Time Buy Date: July 6, 2011
Last Time Shipment Date: September 2, 2011
SAMPLE AVAILABILITY:
Samples are available through normal sample process.
PRODUCT IDENTIFICATION:
Date code, 1127.
QUALIFICATION DATA:
N/A
ISSUED BY:
Doug Lillie, Product Marketing Manager
For further information, please contact your regional Vishay office.
CONTACT INFORMATION:
The Americas
Vishay Intertechnology, Inc
1505 East Highway 50
P. O. Box 180
Yankton, South Dakota 57078
Ph: 1 605-665-9301
Fax: 1 605-665-1627
doug.lillie@vishay.com
Europe
Vishay Electronic GmbH
Geheimrat-Rosenthal-Str. 100
95100 Selb
Germany
Ph: 49-9287-71-2282
Fax: 49-9287-71-2496
jens.walther@vishay.com
Asia
Vishay Asia Pte Ltd.
25 Tampines Street 92
Keppel Building #02-00
Singapore 528877
Ph: +65-788-6668
Fax: +65-788-3383
victor.goh@vishay.com
