LT1301CS8-12 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> LT1301CS8-12

LT1301CS8-12: DescriptionIC 1 A SWITCHING REGULATOR, PDSO8, 0.150 INCH, PLASTIC, SO-8, Switching Regulator or Controller; CategoryPower/power management The power supply circuit; File Size233KB，4 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html

Download Datasheet Parametric Compare View All

LT1301CS8-12 Overview

IC 1 A SWITCHING REGULATOR, PDSO8, 0.150 INCH, PLASTIC, SO-8, Switching Regulator or Controller

LT1301CS8-12 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Linear ( ADI )
Parts packaging code	SOIC
package instruction	0.150 INCH, PLASTIC, SO-8
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
Maximum input voltage	6 V
Minimum input voltage	2 V
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Number of functions	1
Number of terminals	8
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	Not Qualified
Maximum seat height	1.75 mm
surface mount	YES
Switch configuration	BOOST
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	3.9 mm

Preview

Download Datasheet

View All

LT1301CS8-12 Related Products

	LT1301CS8-12	LT1309CS8-12	LT1302CS8-12	LT1301CN8-5	LT1373CS8-12	LT1301CN8-12	LT1301CS8-5	LT1305CS8-12	LT1302CN8-12
Description	IC 1 A SWITCHING REGULATOR, PDSO8, 0.150 INCH, PLASTIC, SO-8, Switching Regulator or Controller	IC 0.5 A SWITCHING REGULATOR, PDSO8, 0.150 INCH, PLASTIC, SO-8, Switching Regulator or Controller	2 A SWITCHING REGULATOR, PDSO8	IC 1 A SWITCHING REGULATOR, PDIP8, PLASTIC, DIP-8, Switching Regulator or Controller	IC 0.25 A SWITCHING REGULATOR, PDSO8, 0.150 INCH, PLASTIC, SO-8, Switching Regulator or Controller	IC 1 A SWITCHING REGULATOR, PDIP8, PLASTIC, DIP-8, Switching Regulator or Controller	IC 1 A SWITCHING REGULATOR, PDSO8, 0.150 INCH, PLASTIC, SO-8, Switching Regulator or Controller	2 A SWITCHING REGULATOR, PDSO8	2 A SWITCHING REGULATOR, PDIP8
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
Maker	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )
package instruction	0.150 INCH, PLASTIC, SO-8	0.150 INCH, PLASTIC, SO-8	0.150 INCH, PLASTIC, SO-8	PLASTIC, DIP-8	0.150 INCH, PLASTIC, SO-8	PLASTIC, DIP-8	0.150 INCH, PLASTIC, SO-8	0.150 INCH, PLASTIC, SO-8	PLASTIC, DIP-8
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR
JESD-30 code	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDIP-T8	R-PDSO-G8	R-PDIP-T8	R-PDSO-G8	R-PDSO-G8	R-PDIP-T8
JESD-609 code	e0	e0	e0	e0	e0	e0	e0	e0	e0
Number of functions	1	1	1	1	1	1	1	1	1
Number of terminals	8	8	8	8	8	8	8	8	8
Maximum output current	1 A	0.5 A	2 A	1 A	0.25 A	1 A	1 A	2 A	2 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	SOP	SOP	DIP	SOP	DIP	SOP	SOP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE	SMALL OUTLINE	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.75 mm	1.75 mm	1.75 mm	4.445 mm	1.75 mm	4.445 mm	1.75 mm	1.75 mm	3.937 mm
surface mount	YES	YES	YES	NO	YES	NO	YES	YES	NO
Switch configuration	BOOST	BOOST	BOOST	BOOST	BOOST	BOOST	BOOST	BOOST	BOOST
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	GULL WING	GULL WING	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING	GULL WING	THROUGH-HOLE
Terminal pitch	1.27 mm	1.27 mm	1.27 mm	2.54 mm	1.27 mm	2.54 mm	1.27 mm	1.27 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
width	3.9 mm	3.9 mm	3.9 mm	7.62 mm	3.9 mm	7.62 mm	3.9 mm	3.9 mm	7.62 mm
Parts packaging code	SOIC	SOIC	-	DIP	SOIC	DIP	SOIC	-	-
Contacts	8	8	-	8	8	8	8	-	-
Maximum input voltage	6 V	5 V	10 V	6 V	-	6 V	6 V	6 V	10 V
Minimum input voltage	2 V	3.3 V	2 V	2 V	-	2 V	2 V	2 V	2 V
length	4.9 mm	4.9 mm	4.9 mm	9.78 mm	4.9 mm	9.78 mm	4.9 mm	4.9 mm	-
