HDSP-G01x/G03x
10.16 mm (0.4 inch) Dual Digit General Purpose
Seven-Segment Display
Data Sheet
Description
This 10.16 mm (0.4 inch) LED dual digit seven-
segment display uses industry standard size package
and pinout. The device is available in either common
anode or common cathode. The choice of colors
includes High Efficiency Red (HER), Green, AlGaAs
Red, and Yellow. The gray face displays are suitable for
indoor use.
Applications
• Suitable for indoor use
• Not recommended for industrial application, i.e.,
operating temperature requirements exceeding +85˚C
or below –25˚C
[1]
• Extreme temperature cycling not recommended
Note:
1. For additional details, please contact your local Avago sales office or
an authorized distributor.
Features
• Industry standard size
• Industry standard pinout
10.16 mm (0.4 inch)
DIP lead on 2.54 mm
• Choice of colors
High Efficiency Red (HER), Green, AlGaAs Red and Yellow
• Excellent appearance
Evenly lighted segments gray package gives optimum
contrast
±
50° viewing angle
• Design flexibility
Common anode or common cathode
• Categorized for luminous intensity
Green and yellow categorized for color
Devices
HER
HDSP-G01E
HDSP-G03E
Green
HDSP-G01G
HDSP-G03G
AlGaAs Red
HDSP-G01A
HDSP-G03A
Yellow
HDSP-G01Y
HDSP-G03Y
Description
Common Anode
Common Cathode
Part Numbering System
5082 -X X X X-X X X X X
HDSP-X X X X-X X X X X
Mechanical Options
[1]
00: No Mechanical Option
Color Bin Options
[1,2]
0: No Color Bin Limitation
Maximum Intensity Bin
[1,2]
0: No Maximum Intensity Bin Limitation
Minimum Intensity Bin
[1,2]
0: No Minimum Intensity Bin Limitation
Device Configuration/Color
[1]
A: AlGaAs Red
E: High Efficiency Red
G: Green
Y: Yellow
Device Specific Configuration
[1]
Refer to Respective Datasheet
Package
[1]
G: 10 mm (0.4 inch) Dual Digit Seven Segment Display
Notes:
1. For codes not listed in the figure above, please refer to the respective datasheet or contact your nearest Avago
representative for details.
2. Bin options refer to shippable bins for a part number. Color and Intensity Bins are typically restricted to 1 bin per tube
(exceptions may apply). Please refer to respective datasheet for specific bin limit information.
2
Package Dimensions
FRONT VIEW
10.16
(0.400)
SIDE VIEW
4.16
(0.164)
8°
16.00
10.16
(0.630)
(0.400)
1.10
(0.043)
16.00
(0.630)
12.70
(0.500)
PIN 1
5.90
(0.232)
20.20
(0.795)
0.70
(0.028)
6.90
(0.272)
TOP END VIEW
20.20
(0.795)
DIG.1
A
F
E
D
COUNTRY OF ORIGIN
COLOR BINNING
(NOTE 3)
∅
0.51
(0.019)
G
B
C
F
E
DIG.2
A
G
B
C
D
DATE CODE
LUMINOUS
INTENSITY
CATEGORY
HDSP-XXXX
YWW XZ COO
NOTE: DECIMAL POINTS WILL NOT
BE LIGHTED UP
2.54 x 7
(0.100)
DIMENSIONS ARE IN MILLIMETERS (INCHES).
3
Internal Circuit Diagram
COMMON ANODE
4 COM
5 COM
A
15
B
13
C
1
D
3
E
2
F
14
G
16
A
10
B
12
C
8
D
6
E
7
F
11
G
9
HDSP-G01E/G01G/G01Y/G01A
PIN No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
CONNECTION
CATHODE C (DIGIT 1)
CATHODE E (DIGIT 1)
CATHODE D (DIGIT 1)
COMMON ANODE (DIGIT 1)
COMMON ANODE (DIGIT 2)
CATHODE D (DIGIT 2)
CATHODE E (DIGIT 2)
CATHODE C (DIGIT 2)
CATHODE G (DIGIT 2)
CATHODE A (DIGIT 2)
CATHODE F (DIGIT 2)
CATHODE B (DIGIT 2)
CATHODE B (DIGIT 1)
CATHODE F (DIGIT 1)
CATHODE A (DIGIT 1)
CATHODE G (DIGIT 1)
COMMON CATHODE
4 COM
5 COM
A
15
B
13
C
1
D
3
E
2
F
14
G
16
A
10
B
12
C
8
D
6
E
7
F
11
G
9
HDSP-G03E/G03G/G03Y/G03A
PIN No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
CONNECTION
ANODE C (DIGIT 1)
ANODE E (DIGIT 1)
ANODE D (DIGIT 1)
COMMON CATHODE (DIGIT 1)
COMMON CATHODE (DIGIT 2)
ANODE D (DIGIT 2)
ANODE E (DIGIT 2)
ANODE C (DIGIT 2)
ANODE G (DIGIT 2)
ANODE A (DIGIT 2)
ANODE F (DIGIT 2)
ANODE B (DIGIT 2)
ANODE B (DIGIT 1)
ANODE F (DIGIT 1)
ANODE A (DIGIT 1)
ANODE G (DIGIT 1)
4
Absolute Maximum Ratings at T
A
= 25˚C
Description
Power Dissipation Segment
Forward Current Segment
Peak Forward Current per Segment
(1/10 Duty Factor at 10 KHz)
Operating Temperature Range
Storage Temperature Range
Reverse Voltage per Segment or DP
Wave Soldering Temperature for 3 seconds
(at 2 mm Distance from the Body)
Notes:
1. Derate above 25˚C at 0.33 mA/˚C.
2. Derate above 25˚C at 0.33 mA/˚C.
3. Derate above 25˚C at 0.2 mA/˚C.
4. Derate above 25˚C at 0.27 mA/˚C.
HER
HDSP-G0xE
65
25
[1]
100
–35 to +85
–35 to +85
5
250
Green
HDSP-G0xG
65
25
[2]
100
–35 to +85
–35 to +85
5
250
AlGaAs Red
HDSP-G0xA
30
15
[3]
80
–35 to +85
–35 to +85
5
250
Yellow
HDSP-G0xY
52
20
[4]
80
–35 to +85
–35 to +85
5
250
Units
mW
mA
mA
˚C
˚C
V
˚C
Electrical/Optical Characteristics at T
A
= 25˚C
High Efficiency Red (HER)
Device
HDSP-
G01E
G03E
Parameter
Luminous Intensity/Segment
Forward Voltage
Peak Wavelength
Dominant Wavelength
Reverse Voltage
Symbol
I
V
V
F
λ
PEAK
λ
d
VR
Min.
1.25
Typ.
1.19
2.60
2.05
635
620
5
Max.
Units
mcd
mcd
V
nm
nm
V
Test Conditions
I
F
= 5 mA
I
F
= 10 mA
I
F
= 20 mA
2.40
I
R
= 100
µA
Green
Device
HDSP-
G01G
G03G
Parameter
Luminous Intensity/Segment
Forward Voltage
Peak Wavelength
Dominant Wavelength
Reverse Voltage
Symbol
I
V
V
F
1.80
λ
PEAK
λ
d
VR
Min.
1.25
Typ.
3.20
2.05
2.25
568
573
Max.
Units
mcd
V
V
nm
nm
V
Test Conditions
I
F
= 10 mA
I
F
= 10 mA
I
F
= 20 mA
2.60
5
I
R
= 100
µA
5
