Power Splitter/Combiner
2 Way-180°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
1W max.
0.125W max.
Coaxial
ZFSCJ-2-1+
BNC version shown
50Ω
1 to 500 MHz
Features
• wideband, 1 to 500 MHz
• high isolation, 30 dB typ.
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 1 deg. typ.
• rugged shielded case
CASE STYLE: K18
Connectors Model
BNC
ZFSCJ-2-1
SMA
ZFSCJ-2-1-S+
N-TYPE
ZFSCJ-2-1-N
BRACKET (OPTION"B")
Price
$59.95
$64.95
$64.95
$5.00
Qty.
(1-9)
(1-9)
(1-9)
(1+)
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT(S)
PORT 1
PORT 2
3
1
2
Applications
• VHF/UHF
• signal processing
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Electrical Specifications
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
L
f
L
-f
U
1-500
Typ.
30
Min
20
Typ.
33
M
Min
25
Typ.
30
U
Min
18
INSERTION LOSS (dB)
ABOVE 3.0 dB
L
M
U
PHASE
UNBALANCE
(Degrees)
L
Max.
2
M
Max.
4
U
Max.
7
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.5
M
Max.
0.2
U
Max.
0.5
Outline Drawing
Typ. Max. Typ. Max. Typ. Max.
1.0
1.5
1.0
1.5
1.0
1.5
L = low range [f
L
to 10 f
L
]
M = mid range [10 f
L
to f
U
/2]
U= upper range [f
U
/2 to f
U
]
Typical Performance Data
Frequency
(MHz)
Total Loss
1
(dB)
S-1
1.00
20.96
40.92
80.84
120.76
160.68
200.60
240.52
280.44
320.36
H
1.000
25.40
S-2
3.95
3.65
3.70
3.76
3.78
3.80
3.84
3.94
3.95
3.94
3.99
4.11
4.13
4.13
4.17
Amplitude
Unbalance
(dB)
0.02
0.00
0.00
0.00
0.02
0.03
0.02
0.01
0.02
0.05
0.05
0.03
0.00
0.01
0.03
Isolation
(dB)
Phase
Unbalance
(deg.)
179.94
180.23
180.39
181.09
181.43
181.76
181.71
181.79
181.93
181.89
181.49
180.85
180.17
179.57
179.34
VSWR
S
VSWR
1
VSWR
2
3.97
3.65
3.70
3.77
3.76
3.77
3.82
3.94
3.93
3.89
3.94
4.09
4.13
4.14
4.19
30.26
37.10
40.24
32.16
29.60
29.99
27.58
26.07
25.65
24.22
23.37
22.87
22.19
22.33
22.51
1.27
1.03
1.03
1.09
1.06
1.04
1.06
1.15
1.17
1.11
1.11
1.21
1.24
1.19
1.19
ZFSCJ-2-1+
ISOLATION
1.34
1.18
1.17
1.17
1.18
1.16
1.14
1.13
1.11
1.13
1.15
1.19
1.24
1.28
1.31
1.34
1.18
1.18
1.18
1.20
1.18
1.17
1.17
1.16
1.14
1.14
1.13
1.12
1.12
1.11
Outline Dimensions (
inch
)
mm
A
1.25
31.75
J
--
--
B
1.25
31.75
K
--
--
C
.75
19.05
L
.125
3.18
D
.63
16.00
M
1.688
42.88
E
.38
9.65
N
2.18
55.37
F
1.00
25.40
P
.75
19.05
G
.125
3.18
360.28
400.20
440.12
480.04
500.00
Q
wt
.07 grams
1.78
70.0
1. Total Loss = Insertion Loss + 3dB splitter theoretical loss.
ZFSCJ-2-1+
TOTAL LOSS
5.0
S-1(dB)
TOTAL LOSS (dB)
4.5
4.0
3.5
3.0
2.5
0
100
200
300
400
500
FREQUENCY (MHz)
ZFSCJ-2-1+
VSWR
1.40
#S-VSWR
1.30
VSWR
1.20
1.10
1.00
0
100
200
300
400
500
®
For bracket version, Option B dimension "C" changes from
0.75 to 0.94 inch when connectors are Type N.
45
S-2(dB)
ISOLATION (dB)
40
35
30
25
20
0
100
200
300
400
500
FREQUENCY (MHz)
#1-VSWR
#2-VSWR
electrical schematic
FREQUENCY (MHz)
