REVISION M
NOTE:
DO NOT
SCALE FROM
THIS PRINT
CRITICAL DIMENSION INSPECTION INSTRUCTION
TABLE
ASSEMBLY OPERATION IN-PROCESS INSPECTION
IN PROCESS 2
C3
TRIM STIFFENER
C1, C2, C4
1.
C
FJH-XX-X-XX.XX-X
No OF POSITIONS
-06, -10, -15, -20, -24,
-25, -30, -40, -43, 50
(SEE TABLE 1)
STYLE
*-S: SINGLE ENDED
-D: DOUBLE ENDED
-R: REVERSE STIFFENER
STRIP LENGTH
-4: 4MM (.15748")
REPRESENTS A CRITICAL DIMENSION.
LENGTH (SPECIFY IN -XX INCHES .125)
.0118 REF
LENGTH
-XX.XX INCHES 1/8 INCH
(-D & -R: 2.00" MINIMUM)
(-S: 2.50" MINIMUM)
"A" .003
C
(SEE TABLE 1)
"B" POS. -1 x .0197
* = AS OF 1/1/11, -S (SINGLE ENDED) AVAILABLE TO EXISTING
CUSTOMERS ONLY, ALL OTHERS WILL BE ASP`S.
FC-XX-0.5
.157±.015
.0126 REF
.0039 REF
.0138
- .004
(TO BE MEASURED AT
BASE OF EXPOSED LEAD)
C
+.006
.023 REF
.012±.002
.207 REF
FS-20
C
-S: SINGLE ENDED
(FJH-10-S-XX-ST2 SHOWN)
LENGTH (SPECIFY IN -XX INCHES .125)
.157±.015
.157±.015
FIG 1
FC-XX-0.5
FS-20
FOR -S: ("XX" LENGTH + .591) .050
FOR -D & -R: ("XX" LENGTH + 1.181) .050
-D: DOUBLE ENDED
(SAME AS FIG 1, UNLESS STATED)
(FIG 4 MAY BE SUBSTITUTED AT SAMTEC DISCRETION)
LENGTH (SPECIFY IN -XX INCHES .125)
.157±.015
FS-20
FIG 2
IN-PROCESS 1
FS-20
FC-XX-0.5
C
(FIG 5 MAY BE SUBSTITUTED AT SAMTEC DISCRETION)
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
(SAME AS FIG 1, UNLESS STATED)
-R: REVERSE STIFFENER
FIG 3
.157±.015
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
1.0225±.0075
.433±.100
.207±.005
.XX: .01
.XXX: .005
.XXXX: .0020
MATERIAL:
ANGLES
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
IN-PROCESS 2
FS-20
.787
(TYP ON BOTH ENDS FOR -D & -R STYLES, ONE END -S STYLE)
CONDUCTORS: TIN PLATED COPPER
SURFACE FINISH EITHER BRIGHT TIN (99.9% SN)
OR MATTE TIN (95.5% SN, 3.5% AG, 1% CU)
INSULATION & STIFFENER: POLYESTER
F:\DWG\MISC\MKTG\FJH-XX-X-XX.XX-X-MKT.SLDDRW
.5mm FLEX CABLE JUMPER
FJH-XX-X-XX.XX-X
6/28/00
SHEET
1
OF
2
BY:
KEVIN B
REVISION M
SHEET 2: MACHINE BUILT PRODUCT
LENGTH (SPECIFY IN -XX INCHES
.125)
.0118 REF
"A"
(SEE NOTE 2)
(SEE TABLE 1)
"B" -1 x .0197 .004
.157±.030
(2 PLCS)
TPW-03
JIF-XX
.138 .004
(SEE NOTE 3)
.004
.006 REF
FS-13
.080 MIN
(-D=DOUBLE ENDED) (MACHINE BUILT)
(FJH-10-D-XX.XX-4 SHOWN)
FIG 4
.012 .002
LENGTH (SPECIFY IN -XX INCHES
.125)
FIG 5
(-R= REVERSE STIFFENER) (MACHINE BUILT)
(SAME AS FIG 4 UNLESS STATED)
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
.5mm FLEX CABLE JUMPER
FJH-XX-X-XX.XX-X
6/28/00
SHEET
2
OF
2
F:\DWG\MISC\MKTG\FJH-XX-X-XX.XX-X-MKT.SLDDRW
BY:
KEVIN B
