CSF-210
TEST
P
R
OB
E
®
SFLTP–08–12.00–QTS
SFLTP, SFLTL SERIES
PATENT PENDING
TEST PROBE CABLE ASSEMBLIES
SPECIFICATIONS
For complete specifications
see www.samtec.com?SFLTP
or www.samtec.com?SFLTL
Cable:
30 AWG twinax (-QTS),
42 AWG coax (-A40A),
38 AWG coax (-A90A)
Signal Routing:
100Ω Differential ±5Ω (-QTS),
90Ω Single-Ended (-A40A),
75Ω Single-Ended (-A90A)
Operating Range:
DC to 1.25GHz (2.5Gbps)
RoHS Compliant:
Yes
Enables High
Speed serial
protocol testing
COMPATIBLE
INSTRUMENT
PROBING TECHNOLOGY
TYPE
MODEL
DESCRIPTION
–QTS
General Purpose General Purpose
1680, 1690,
16910, 16911
Agilent 40-pin
logic analyzer
*
–A40A
16950, 16951,
Agilent 90-pin
–A90A
16760, 16962
logic analyzer
*
*
For a complete list of compatible logic analyzer modules
see our Spirit
®
eBrochure at www.samtec.com.
Twinax or coax ribbon
cable depending on
instrument type option.
Bandwidth of 3.125 Gbps
at 0.5 meter length
FLEX TIPS
TYPE
S
G
Picks up differential signals not conveniently
grouped or routed to connectors
S
NO. OF
PAIRS
ASSEMBLY LENGTH
INSTRUMENT
TYPE OPTION
HDR–135965–01
Flex Tips (Case of 20),
-QTS only. Call Samtec.
SCF-136032-01-DA
Flex Tips (Case of 20)
compatible with Agilent
E5381 and E2678A probes.
SFLTP
= Protocol Analysis
(-QTS)
–08
(SFLTP only)
–12.00, –24.00, –36.00
= Assembly Length in inches
–17
(SFLTL only)
= Q Strip
®
,
Protocol analysis
(Mates with QSS)
–QTS
SFLTL
= Logic Analysis
(-A40A, -A90A)
–A40A
= 40-pin
(2,54mm) .100"
pitch SQ post header,
Logic analysis
ASSEMBLY LENGTH
APPLICATIONS
Standard header
(TSW Series)
DUT
–A90A
= 90-pin
(1,27mm) .050"
pitch SQ post header,
Logic analysis
SFLTL Logic Analysis
(-A40A, -A90A)
(
)
DUT
Flex Tip
(HDR)
(59,99)
2.362
SPIRIT
®
FLYING LEAD
DUT END INTERFACE
INSTRUMENT END
(–QTS SHOWN)
SFLTP Protocol Analysis
Prot
(-QTS)
(-Q
WWW.SAMTEC.COM
