UPD78320GF-3B9 Overview

Microcontroller, 16-Bit, 16MHz, MOS, PQFP80, 14 X 20 MM, PLASTIC, QFP-80

UPD78320GF-3B9 Parametric

Parameter Name	Attribute value
Maker	NEC Electronics
Parts packaging code	QFP
package instruction	14 X 20 MM, PLASTIC, QFP-80
Contacts	80
Reach Compliance Code	unknown
Has ADC	YES
Address bus width	16
bit size	16
maximum clock frequency	16 MHz
DAC channel	NO
DMA channel	NO
External data bus width	8
JESD-30 code	R-PQFP-G80
length	20 mm
Number of I/O lines	21
Number of terminals	80
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
PWM channel	NO
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Package shape	RECTANGULAR
Package form	FLATPACK
Certification status	Not Qualified
Maximum seat height	2.7 mm
speed	16 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	MOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
width	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

DATA SHEET

MOS INTEGRATED CIRCUIT

PD78320,78322

16/8-BIT SINGLE-CHIP MICROCONTROLLER

DESCRIPTION

The

PD78322 is a 16-/8-bit single-chip microcontroller that incorporates a high-performance 16-bit CPU. The

PD78322

is one of 78K/III series.

A realtime pulse unit for realtime pulse control required in motor control, an A/D converter, a ROM, and a RAM have been

integrated into one chip.

The

PD78322 incorporates 16K-byte mask ROM and 640-byte RAM.

The

PD78320 is provided as a ROM-less product of the

PD78322. Also, the

PD78P322 is provided as an on-chip

PROM product.

Detailed information about product features and specifications can be found in the following document.

PD78322 User’s Manual : IEU-1248

FEATURES

•

Internal 16-bit architecture and external 8-bit data bus

•

High-speed processing by pipeline control and instruction prefetch

• Minimum instruction execution time: 250 ns (with 16 MHz external clock in operation)

•

Instruction set suitable for control operations (

PD78312 upward compatible)

• Multiplication/division instruction (16 bits

16 bits, 32 bits

16 bits)

• Bit manipulation instruction

• String instruction, etc.

•

On-chip high-function interrupt controller

• 3-level priority specifiable

• 3-type interrupt servicing mode selectable

(Vectored interrupt function, context switching function, and macro service function)

•

Variety of peripheral hardware

• Realtime pulse unit

• 8-channel, 10-bit A/D converter

• Watchdog timer

•

Powerful serial interface (with an on-chip dedicated baud rate generator)

• UART

····· 1 channel

• SBI (NEC Standard Serial Bus Interface)

• 3-wire serial I/O

····· 1 channel

APPLICATIONS

•

Motor control devices

Unless there are any particular notices, the

PD78322 is described as the representative model in this document.

The information in this document is subject to change without notice.

Document No. U10455EJ7V0DS00 (7th edition)

(Previous No. IC-2354)

Date Published November 1995 P

Printed in Japan

The mark

shows major revised points.

1989
