F.MM.2A5.25.25.010 datasheet, PDF

Datasheet> All Categories > The connector> The connector> F.MM.2A5.25.25.010

F.MM.2A5.25.25.010: DescriptionMains Power Connector, 2.5A, 250VAC, Male, Plug; CategoryThe connector The connector; File Size121KB，2 Pages; ManufacturerNissei Electric Co.,Ltd.

Download Datasheet Parametric View All

F.MM.2A5.25.25.010 Overview

Mains Power Connector, 2.5A, 250VAC, Male, Plug

F.MM.2A5.25.25.010 Parametric

Parameter Name	Attribute value
Maker	Nissei Electric Co.,Ltd.
Reach Compliance Code	unknown
Other features	STANDARD: IEC 60320, FASTON
Body/casing type	PLUG
Connector type	MAINS POWER CONNECTOR
Contact point gender	MALE
Coupling type	SNAP
DIN compliance	NO
IEC compliance	YES
MIL compliance	NO
Power Connector Ratings	2.5A, 250VAC
Manufacturer's serial number	F.MM
Installation type	PANEL
Options	GENERAL PURPOSE
Shell material	METAL
Total number of contacts	3

Preview

Download Datasheet

View All

IEC Inlet Filters

F.MH-F.MK-F.ML-F.MM-F.MP-F.MQ-F.MR-F.MS

series

With fuse holder, bipolar switch and voltage selector

This series gives a high level of suppression within a compact

enclosure. The IEC 60320 inlet power entry module combines 1 or 2

fuse holders for US and IEC fuses, with a bipolar rocker switch, earth

choke and input voltage selector.

Designed for use in business, consumer, test and medical equipment

for international markets.

•

Current ratings from 1A to 6A

•

Comprehensive range of filter performance options

•

Integral single or twin fuse holder

•

Optional voltage selector

•

Optional earth line choke

•

Horizontal or vertical mounting

•

Medical versions available

Mechanical Specifications

Manufacture:

metal case with built-in power line connector

according to IEC 60320,

fuse holder for 1 fuse (F.MH. - F.ML. - F.MP. - F.MR)

or 2 fuses (F.MK. - F.MM. - F.MQ. - F.MS)

5 x 20mm (IEC) or 6.3 x 32mm (US),

bipolar rocker switch,

voltage selector 110/220Vac (F.MH - F.MK - F.ML

- F.MM only); internal components sealed with

self-extinguishing resin.

Connections:

IEC 60320 - Standard plug (INPUT);

faston 6.3 x 0.8mm (OUTPUT);

ground terminal connected to case.

Mounting:

F.MH, F.MK, FML, FMM versions now available in

vertical mounting version - (F.**.***.**.**.010) with

no approvals.

■

▲

Filter Range

(example pt no. - F.MH.01A.20.25)

Code

20.- -

01A 24.- -

30.- -

34.- -

21.- -

2A5 25.- -

31.- -

35.- -

22.- -

04A 26.- -

32.- -

36.- -

23.- -

06A 27.- -

33.- -

37.- -

20.- -

01A 24.- -

30.- -

34.- -

21.- -

2A5 25.- -

31.- -

35.- -

22.- -

04A 26.- -

32.- -

36.- -

23.- -

06A 27.- -

33.- -

37.- -

(A) (mH)

2 x 10

2 x 22

2x2

2.5 2 x 2

2x8

2x1

2x8

2x1

2 x 2.5

2 x 10

2 x 22

2x2

2.5 2 x 2

2x8

2x1

2x8

2x1

2 x 2.5

■

(mH) (µF)

0.22

(µF)

0.1

(pF)

2 x 4700

F.MH.

F.MK.

F.MQ.

F.MS.

0.22

0.1

2 x 4700

0.22

0.1

2 x 4700

0.22

0.1

2 x 4700

●

2 x 4700

0.1

2 x 4700

0.65 0.22

●

2 x 4700

0.1

2 x 4700

Electrical Specifications

Rated voltage (V

max 250V, 50/60Hz

Rated current (I

Voltage test (2

.):

Climatic category:

Bipolar rocker

Switches:

referred to room temperature = 40°C

line to ground 3000Vdc or 1800Vac

line to line 1700Vdc

HPF (25/085/21);

Temperature range: -25°C to +85°C

10(4)A / 250Vac (Rated current),

50000 on-off operations;

values in ( ) relate to the inductive current;

inrush current test according to UL 1054 (35A).

Voltage selector:

110-220Vac (F.MH - F.MK - F.ML - F.MM only).

Leakage current (I

at 220V, 50Hz, max value

■

▲

F.ML.

F.MM.

F.MP.

F.MR.

0.65 0.22

●

2 x 4700

0.1

2 x 4700

0.65 0.22

●

2 x 4700

0.1

2 x 4700

2 x 0.003

0.65 0.22

(mA)

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

2 x 0.003

2 x 0.43

(MΩ)

0.33

▲

No approvals, Circuit Diagram D

No approvals, Circuit Diagram C

●

Not applicable to FMP,FMR

Approvals

.010 = Vertical mounting option (addition to standard pt no.)

25 = Rocker switch

26 = Illuminated rocker switch

Circuit Diagram:

H = 1 fuse

K = 2 fuses

L = 1 fuse + earth choke

M = 2 fuses + earth choke

P = 1 fuse, single pole switch (no voltage selector)

Q = 2 fuses, single pole switch (no voltage selector)

R = 1 fuse, double pole switch (no voltage selector)

S = 2 fuses, double pole switch (no voltage selector)
