Power Splitter/Combiner
2 Way-90°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
-40°C to 85°C
-55°C to 100°C
20W* max.
SMA Connectorized
ZX10Q-2-12
50Ω
800 to 1250 MHz
Features
• low insertion loss, 0.4 dB typ.
• excellent amplitude unbalance
• very good phase unbalance
• small size
• low cost
• protected by U.S Patent 6,790,049
• additional patent pending
* Derate linearly to 7W at 100°C ambient.
CASE STYLE: GW1052
Connectors Model
SMA
ZX10Q-2-12-S
Price
$24.95
Qty.
(1-24)
Pin Connections
SUMPORT
PORT 1 (0°)
PORT 2 (+90°)
50 OHM TERM EXTERNAL**
1
3
2
4
Applications
• cellular
• GSM
• balanced amplifiers
• modulators
Splitter Electrical Specifications (T
AMB
=25°C)
FREQ.
RANGE
(MHz)
f
L
-f
U
800-1250
800-1000
1000-1250
ISOLATION
(dB)
Typ.
17
16
Min.
15
13
INSERTION LOSS (dB)
Avg. of Coupled Outputs
less 3 dB
Typ.
0.3
0.4
Max.
0.6
0.7
PHASE
UNBALANCE
(Degrees)
Typ.
2.5
1.0
Max.
5.0
3.0
AMPLITUDE
UNBALANCE
(dB)
Typ.
0.2
0.5
Max.
0.8
0.8
** Recommended external termination
Mini-Circuits Part. No. ANNE-50L
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
800.00
825.00
850.00
875.00
925.00
950.00
975.00
1000.00
1050.00
1075.00
1100.00
1150.00
1175.00
1225.00
1250.00
3.13
3.20
3.27
3.33
3.44
3.48
3.52
3.56
3.61
3.63
3.65
3.65
3.65
3.62
3.60
Amplitude
Unbalance
(dB)
0.46
0.31
0.18
0.05
0.16
0.25
0.32
0.39
0.48
0.50
0.52
0.51
0.49
0.40
0.34
Isolation
(dB)
Phase
Unbalance
(deg.)
87.58
87.64
87.73
87.82
87.99
88.10
88.21
88.35
88.65
88.81
88.98
89.40
89.65
90.21
90.53
VSWR
S
VSWR
1
VSWR
2
Outline Drawing
S-2
3.59
3.51
3.44
3.38
3.28
3.24
3.20
3.17
3.14
3.13
3.13
3.14
3.16
3.22
3.26
16.94
16.91
16.86
16.82
16.72
16.66
16.59
16.51
16.31
16.20
16.08
15.80
15.64
15.28
15.08
1.27
1.27
1.27
1.27
1.27
1.27
1.27
1.27
1.27
1.28
1.28
1.29
1.29
1.30
1.31
ISOLATION
17.5
ISOLATION (dB)
17.0
16.5
16.0
15.5
15.0
14.5
800
850
900
950 1000 1050 1100 1150 1200 1250
FREQUENCY (MHz)
1.20
1.20
1.19
1.18
1.16
1.15
1.14
1.13
1.10
1.09
1.07
1.05
1.03
1.01
1.03
1.11
1.10
1.10
1.09
1.08
1.07
1.07
1.07
1.07
1.07
1.07
1.09
1.10
1.12
1.14
INSERTION LOSS
4.5
INSERTION LOSS (dB)
S-1
S-2
4.0
3.5
3.0
2.5
2.0
800
Outline Dimensions (
inch
)
mm
A
1.04
26.42
B
.60
15.24
C
.75
19.05
D
.50
12.70
E
.10
2.54
F
.17
4.32
G
.25
6.35
H
.25
6.35
J
.50
12.70
K
.11
2.79
L
.820
20.83
M
.106
2.69
N
wt.
.12 grams
21.0
3.05
850
900
950 1000 1050 1100 1150 1200 1250
FREQUENCY (MHz)
PHASE UNBALANCE
95
PHASE UNBALANCE
(deg.)
93
91
89
87
85
800
electrical schematic
850
900
950 1000 1050 1100 1150 1200 1250
FREQUENCY (MHz)
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. OR
M100324
ZX10Q-2-12
AD/CP/AM
060914
Mini-Circuits
ISO 9001 & ISO 14001
Certified
