Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
0.125W max.
Coaxial
ZN2PD-920
50Ω
800 to 920 MHz
Features
• low insertion loss, 0.15 dB typ.
• high isolation, 30 dB typ.
• up to 10W power input as a splitter
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 0.5 deg. typ.
• excellent VSWR, 1.05:1 typ.
• rugged shielded case
CASE STYLE: VVV180
Connectors Model
SMA
ZN2PD-920-S
Price
$59.95
Qty.
(1-9)
Coaxial Connections
SUMPORT
PORT 1
PORT 2
S
1
2
Applications
• UHF
• cellular
• communications systems
• instrumentations
FREQ.
RANGE
(MHz)
f
L
-f
U
800-920
Splitter Electrical Specifications
INSERTION LOSS (dB)
PHASE
AMPLITUDE
ABOVE 3.0 dB
UNBALANCE UNBALANCE
(Degrees)
(dB)
S
Typ.
0.15
Max.
0.4
Max.
2
Max.
0.2
Outline Drawing
ISOLATION
(dB)
VSWR
(:1)
OUT
1.2
1.04
1.2
Typ. Min.
30
20
Typ. Max. Typ. Max.
1.10
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
800.00
806.00
812.00
818.00
827.00
3.10
3.10
3.11
3.11
3.14
3.15
3.11
3.06
3.07
3.10
3.12
3.07
3.07
3.12
3.16
Amplitude
Unbalance
(dB)
0.01
0.02
0.02
0.01
0.01
0.02
0.01
0.01
0.01
0.01
0.02
0.01
0.02
0.01
0.01
Isolation
(dB)
Phase
Unbalance
(deg.)
0.46
0.36
0.39
0.43
0.45
0.43
0.43
0.42
0.41
0.50
0.45
0.44
0.47
0.49
0.41
VSWR
S
VSWR
1
VSWR
2
S-2
3.09
3.09
3.09
3.11
3.13
3.13
3.10
3.05
3.06
3.08
3.10
3.06
3.06
3.11
3.14
27.34
28.19
29.09
30.15
31.96
34.22
37.23
41.65
45.76
48.47
40.73
35.58
32.26
30.40
28.92
1.06
1.05
1.04
1.04
1.02
1.01
1.01
1.01
1.02
1.03
1.04
1.06
1.08
1.09
1.10
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.01
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
1.02
Outline Dimensions (
A
B
C
1.80
1.75
.66
45.72 44.45 16.76
H
1.625
41.28
D
E
.125 1.675
3.18 42.55
inch
mm
)
G
.125
3.18
wt
grams
34
F
.125
3.18
836.00
845.00
854.00
860.00
866.00
878.00
890.00
902.00
911.00
920.00
J
K
L
M
.31
.63
1.13
.88
7.87 16.00 28.70 22.35
ZN2PD-920
INSERTION LOSS
3.25
INSERTION LOSS (dB)
S-1(dB)
S-2(dB)
ZN2PD-920
ISOLATION
60
ISOLATION (dB)
50
40
30
20
10
800
3.20
3.15
3.10
3.05
3.00
800
820
840
860
880
900
920
820
840
860
880
900
920
FREQUENCY (MHz)
FREQUENCY (MHz)
ZN2PD-920
VSWR
1.15
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
1.12
VSWR
1.09
1.06
1.03
1.00
800
820
840
860
880
900
920
FREQUENCY (MHz)
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. OR
M94665
ZN2PD-920
HY/TD/CP
060829
Mini-Circuits
ISO 9001 & ISO 14001
Certified
