Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation (as a combiner)
-40°C to 85°C
-55°C to 100°C
1.5W max.
0.75W max.
Coaxial
ZX10-2-722+
50Ω
2800 to 7200 MHz
Features
• wide bandwidth, 2800 to 7200 MHz
• excellent amplitude unbalance, 0.05 dB typ.
• very good phase unbalance, 1 deg. typ.
• small size
• low cost
• protected under U.S. Patent 6,790,049
CASE STYLE: FL905
Connectors Model
SMA
ZX10-2-722-S+
Price
$35.95
Qty.
(1-24)
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
Applications
• WiMax
• radar
• ISM
• WLAN
• instrumentation
• Satellite communications
FREQ.
RANGE
(MHz)
f
L
-f
U
2800-7200
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Electrical Specifications
INSERTION LOSS (dB)
ABOVE 3.0 dB
PHASE
UNBALANCE
(Degrees)
Max.
10
Outline Drawing
ISOLATION
(dB)
AMPLITUDE
UNBALANCE
(dB)
Max.
0.4
Typ. Min.
22
11
Typ. Max.
0.8
1.6
Typical Performance Data
Frequency
(MHz)
Total Loss
1
(dB)
S-1
2800.0
3152.0
3504.0
3856.0
4208.0
4.17
3.88
3.90
3.90
3.80
3.72
3.69
3.72
3.79
3.87
3.89
3.90
3.90
3.92
3.90
S-2
4.17
3.89
3.91
3.91
3.83
3.76
3.72
3.77
3.89
3.96
3.93
3.94
3.93
3.94
3.94
Amplitude
Unbalance
(dB)
0.00
0.01
0.01
0.01
0.03
0.04
0.03
0.05
0.11
0.09
0.05
0.04
0.03
0.02
0.04
Isolation
(dB)
Phase
Unbalance
(deg.)
0.47
0.57
0.59
0.56
0.65
0.79
0.87
0.82
0.83
0.86
0.95
0.95
0.91
0.82
0.79
VSWR
S
VSWR
1
VSWR
2
18.58
25.93
21.32
20.11
21.38
23.90
28.26
35.61
26.01
21.65
18.13
16.66
15.63
14.46
14.08
1.35
1.22
1.45
1.49
1.38
1.22
1.05
1.14
1.31
1.41
1.43
1.43
1.40
1.31
1.26
1.29
1.24
1.28
1.27
1.20
1.12
1.09
1.14
1.19
1.17
1.13
1.11
1.13
1.25
1.34
1.28
1.23
1.27
1.26
1.18
1.10
1.07
1.11
1.16
1.15
1.10
1.09
1.10
1.22
1.32
Outline Dimensions (
A
.74
18.80
H
.37
9.40
B
.90
22.86
J
--
--
C
.54
13.72
K
.122
3.10
D
.50
12.70
L
.496
12.60
E
.04
1.02
M
.106
2.69
inch
mm
)
G
.29
7.37
F
.16
4.06
4560.0
4912.0
5264.0
5616.0
5968.0
6320.0
6496.0
6672.0
7024.0
7200.0
N
wt
.122 grams
3.10
20.0
1. Total Loss = Insertion Loss + 3dB splitter loss.
ZX10-2-722+
TOTAL LOSS
5.0
ZX10-2-722+
ISOLATION
40
S-2
S-1
TOTAL LOSS (dB)
ISOLATION (dB)
4.6
4.2
3.8
3.4
3.0
2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500
FREQUENCY (MHz)
35
30
25
20
15
10
2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500
FREQUENCY (MHz)
1.8
ZX10-2-722+
VSWR
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
1.6
VSWR
1.4
1.2
1.0
2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. A
M127604
ZX10-2-722+
ED-13246A/3
DY/CP
120130
