FEATURES AND SPECIFICATIONS
Features and Benefits
n
n
n
n
Sizes 6 to 72 circuits
Holds wires for secure, reliable contact
Modular construction reduces inventory
High flammability rating
Electrical
Voltage: 300 V
Maximum Current: 13.5 Amp
Insulation Resistance: >5,000 Megaohms
5.0mm (.197”) Pitch
Beau Eurostyle®
Low Profile, Three Level
Terminal Block
39890
Modular
Mechanical
Max. Tightening Torque: 5 in. lbs, .56 Nm
Operating Temperature: 110
o
C
Wire Strip Length: 1/4” or 6mm
Reference Information
UL :
CSA:
File No. E48521
Guide No. XCFR2
File No. 025562
Physical
Insulator: Polyamide, UL94 V-0, Black
Screws: Bronze
Screw Plating: Nickel
Contacts: Copper Alloy
Contact Plating: Tin
Pressure Clamp: Brass
Pressure Clamp Plating: Nickel
Wire Range: 14 to 26 AWG, 1.5 to 0.2mm
2
24.4
.961”
CATALOG DRAWING (FOR REFERENCE ONLY)
C
2.5
.098”
5.0
.197”
14.7
.579”
0.60
.023”
28.0
1.10”
19.0
.748”
10.0
.394” 1.60
.063”
0.5
.019”
2.5
.098”
0.90
.035”
4.1
.161”
10.0
.394”
28.2
1.11”
10.0
.394”
4.1
.161”
10.0
.394”
10.0
.394”
19.0
.748”
Diameter
1.10
.043”
10.0
.394”
5.0
.197”
2.5
.098”
3.5
.138”
A
ORDERING INFORMATION AND DIMENSIONS
Order # (Engineering #)
Replace XX with # of circuits, 06-72
Tin Plated
39890-08XX (8931XX)
# of
Circuits
4
6
8
10
12
14
16
18
20
22
24
26
A
in
.20
.39
.59
.79
.98
1.18
1.38
1.57
1.77
1.97
2.16
2.36
mm
5.0
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
in
.39
.59
.79
.98
1.18
1.38
1.57
1.77
1.97
2.16
2.36
2.56
C
mm
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
# of
Circuits
28
30
32
34
36
38
40
42
44
46
48
A
in
2.56
2.76
2.95
3.15
3.35
3.54
3.74
3.94
4.13
4.33
4.53
mm
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
105.0
110.0
115.0
in
2.76
2.95
3.15
3.35
3.54
3.74
3.94
4.13
4.33
4.53
4.72
C
mm
70.0
75.0
80.0
85.0
90.0
95.0
100.0
105.0
110.0
115.0
120.0
*Consult facotry for sequential numbering option
