1623804-3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 1623804-3

1623804-3: DescriptionRESISTOR, WIRE WOUND, 10W, 5%, 300ppm, 3.9ohm, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components The resistor; File Size117KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

1623804-3 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1623804-3	-	-	View	Buy Now

1623804-3 Overview

RESISTOR, WIRE WOUND, 10W, 5%, 300ppm, 3.9ohm, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT

1623804-3 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1646086443
package instruction	RADIAL LEADED, ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	14 weeks 2 days
YTEOL	7.05
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	250 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	BULK, BOX
physical size	48mm x 10mm x 10mm
Rated power dissipation(P)	10 W
resistance	3.9 Ω
Resistor type	FIXED RESISTOR
surface mount	NO
technology	WIRE WOUND
Temperature Coefficient	300 ppm/°C
Terminal shape	SNAP-IN
Tolerance	5%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

SQZW103R9J Product Details

Live Product Chat

Fixed Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

SQZW103R9J

(1623804-3)

T E I nternal N umber: 1 6 2 3 8 0 4 - 3

Product Highlights:

Resistor Type = Power Resistor

Resistance Selection = <1K ?

Resistance = 3.9 ?

Power Rating = 10.00 W

Tolerance = 5 %

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

High Power Resistors - Type SQ Series - Tyco Electro...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Resistor Type = Power Resistor

Resistance (?)

= 3.9

Element

= Wirewound

Termination Type

= Tinned C opper Leads

Electrical Characteristics:

Resistance Selection (?)

= <1K

Power Rating (W)

= 10.00

Tolerance (%)

= 5

Package Type

= Loose Piece - Box

Body Related Features:

Series

= SQ

Mount Style

= Radial Leaded

Package, C omponent Size

= 10 x 10 x 48

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= ?300

Operation/Application:

Application

= Power

Other:

Brand = C GS

Additional Information:

Product Line Information
