LPE-3325-680UH20%B datasheet, PDF

Datasheet> All Categories > Passive components> inductor> LPE-3325-680UH20%B

LPE-3325-680UH20%B: DescriptionGeneral Fixed Inductor, 1 ELEMENT, 680 uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD; CategoryPassive components inductor; File Size49KB，2 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

LPE-3325-680UH20%B Overview

General Fixed Inductor, 1 ELEMENT, 680 uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD

LPE-3325-680UH20%B Parametric

Parameter Name	Attribute value
Maker	Vishay
Reach Compliance Code	unknown

Preview

Download Datasheet

View All

Model LPE-3325

Vishay Dale

Transformers/Inductors

Surface Mount, Gapped and Ungapped

Custom Configurations Available

ELECTRICAL SPECIFICATIONS

Inductance Range:

10µH to 3900µH, measured at 0.10V RMS @ 10kHz

without DC current, using an HP 4263A or HP 4284A impedance analyzer.

DC Resistance Range:

0.06 ohm to 18.0 ohm, measured at + 25°C

5°C.

Operating Temperature:

- 20°C to + 80°C.

Rated Current Range:

1.00 amps to .06 amps.

Dielectric Withstanding Voltage:

500V RMS, 60Hz, 5 seconds.

DIMENSIONAL CONFIGURATIONS

[Numbers in brackets indicate millimeters]

Pad Layout

0.056 [1.42]

Pad Dimensions Typical,

6 places

0.073 [1.85]

0.042

[1.07]

0.232

[5.89]

0.288

[7.32]

Reference

Only

Dimensional Outline

.268

[6.81]

.205 [5.21]

Max.

Clip Opening

Opposite Pin 1

.323 [8.20]

Max.

.028 [.71]

Foot print Diagram

.073 [1.85]

Typ.

.256 [6.50]

Max.

.028

[.71]

Typical

two

places

NOTE:

Pad layout guidelines per MIL-STD-275E (printed wiring for electronic equipment). Tolerances: xx

.01" [± 0.25mm]. xxx

.005" [± 0.12mm].

STANDARD ELECTRICAL SPECIFICATIONS

INDUCTANCE

(

100

150

220

330

470

680

1000

1500

2200

3300

3900

100

150

220

330

470

680

1000

INDUCTANCE

TOLERANCE

30%

20%

SCHEMATIC

LETTER

DCR

MAX.

(Ohms)

MAX. RATED*

DC CURRENT

(Amps)

SATURATING**

CURRENT

(Amps)

MODEL

Ungapped Models

LPE-3325-100NA

LPE-3325-150NA

LPE-3325-220NA

LPE-3325-330NA

LPE-3325-470NA

LPE-3325-680NA

LPE-3325-101NA

LPE-3325-151NA

LPE-3325-221NA

LPE-3525-331NA

LPE-3525-471NA

LPE-3325-681NA

LPE-3525-102NA

LPE-3325-152NA

LPE-3325-222NA

LPE-3325-332NA

LPE-3325-392NA

Gapped Models

LPE-3325-100MB

LPE-3325-150MB

LPE-3325-220MB

LPE-3325-330MB

LPE-3325-470MB

LPE-3325-680MB

LPE-3325-101MB

LPE-3325-151MB

LPE-3325-221MB

LPE-3325-331MB

LPE-3325-471MB

LPE-3325-681MB

LPE-3325-102MB

0.06

0.08

0.09

0.11

0.14

0.16

0.20

0.76

0.92

1.13

1.35

1.62

1.97

2.41

3.00

5.96

7.00

0.22

0.27

0.42

0.65

0.97

1.45

2.22

3.55

4.31

6.72

9.83

14.8

18.0

1.01

.91

.83

.75

.69

.63

.57

.29

.26

.24

.22

.20

.18

.16

.15

.10

.54

.48

.39

.31

.26

.21

.17

.13

.12

.10

.08

.07

.06

N/A

1.480

1.240

1.050

.872

.740

.622

.518

.426

.354

.290

.244

.204

.169

*DC current that will create a maximum temperature rise of 30°C when applied at + 25°C ambient. **DC current that will typically reduce the initial inductance by

20%.

UNGAPPED MODELS:

Highest possible inductance with the lowest DCR and highest Q capability. Beneficial in filter, impedance matching and line coupling

devices.

GAPPED MODELS:

Capable of handling large amounts of DC current, tighter inductance tolerance with better temperature stability than ungapped models.

Beneficial in DC to DC converters or other circuits carrying DC currents or requiring inductance stability over a temperature range.

www.vishay.com

Document Number 34063

Revision 27-Apr-99
