UTS Hi seal
Description
Dynamic IP68/IP69K - Waterproof connec-
tors in mated and unmated condition
■
UTS Hi seal connector is a range of light-
weight industrial plastic circular connec-
tors compatible with MIL-DTL-26482
connectors. It offers
Dynamic IP68/IP69K
water protection
in both mated & unma-
ted conditions.
■
Available :
▪
in 5 shell sizes,
▪
up to 21 contact arrangements
▪
with multiple polarization options.
■
Connectors are standard supplied with
preassembled handsolder contacts. For
dispsolder or crimp contacts, please
consult factory.
Applications
UTS Hi seal
connector is suitable for a broad
range of applications, such as
• Wet & submerged environments
• Instrumentation
• Meteorological measurement system
• Traffic control
• Videosurveillance
• Tunnel fans
•
Water measurement
and there is more.
Benefits
Protection of electronics inside the
equipments/boxes in case of maintenance,
unmated conditions or cable damage
Fully intermateable and interchangeable
with existing solutions
•
Design based on MIL-DTL-26482
connectors or equivalents such as : BS 9522
F001 NFC93422, HE301B, VG 95328.
7,
Ideal for indoor / outdoor applications
•
Dynamic IP68/69K water protection
(during vibration and cable mouvements)
•
Corrosion resistance
Operational safety - ESD
•
Plastic shells
Rapid and secure locking system
•
Bayonet connector
Suitable for overmoulding
•
Sealed insulator and contacts
Respect for environment
•
RoHS compliant
Visual identification
•
Coloured rings
UTS Hi seal
Technical characteristics
Mechanical
• Durability
• Vibration resistance
• Thermal shock
250 matings & unmatings
Per CEI 6051
2-4
Per MIL-STD1
344 method 1003
Environmental
• Operating temperature
• Sealing (mated/unmated)
-40°C to + 105°C
Dynamic IP68 - under water for 1
week, 1 bar
Dynamic IP69K per DIN 40050
• Salt spray
500 hours
• UV resistance
1000 hours per ISO4892
• RoHS compliant & conform to the Chinese standard SJ/T1
166-
2006 (Chinese RoHS equivalent)
Electrical
• Current per contact
• Insulation resistance
• Test potential
• Operating voltage
Size 16: 1
3A
Size 20: 7.5A
≥
5000 MΩ under 500Vcc at 25°C
500 V between contacts size 20
2300 V between contacts size 16
1
500 Veff between contacts size 20
2300 Veff between contacts size 16
according to MIL-DTL-26482
Material
• Housing + Backshell
• Insert
• Contacts
Thermoplastic UL94-V0
Elastomer
Copper alloy - gold plated
Other platings on request
Contacts arrangements
Size 8
2
3
3A/98
4
33
6
Size 1
0
7
98
Contacts :
2 Ø 1 (#20)
Contacts :
3 Ø 1 (#20)
Contacts :
3 Ø 1 (#20)
Contacts :
4 Ø 1 (#20)
Contacts :
3 Ø 1 (#20)
Contacts :
6 Ø 1 (#20)
Contacts :
7 Ø 1 (#20)
Contacts :
6 Ø 1 (#20)
Size 1
2
2
3
8
1
0
1
4
Contacts :
2 Ø 1 (#1
.6
6)
Contacts :
3 Ø 1 (#1
.6
6)
Contacts :
8 Ø 1 (#20)
Contacts :
1 Ø 1 (#20)
0
Contacts :
1 Ø 1 (#20)
4
Size 1
4
5
1
2
15
1
8
1
9
1
1
Size 1
8*
32
30
Contacts :
5 Ø 1 (#1
.6
6)
Contacts :
8 Ø 1 (#20)
4 Ø 1 (#1
.6
6)
Contacts :
1 Ø 1 (#20)
4
1 Ø 1 (#1
.6
6)
Contacts :
1 Ø 1 (#20)
8
Contacts :
1 Ø 1 (#20)
9
Contacts :
1 Ø 1 (#1
1
.6
6)
Contacts :
32 Ø 1 (#20)
Contacts :
29 Ø 1 (#20)
1 Ø 1 (#1
.6
6)
* Please consult factory
UTS Hi seal
How to order
Connector family
Body variation
6 =
cable plug + backshell /
7 =
jam nut receptacle
/ 0 =
square flange receptacle
Backshell : JC =
backshell (only for plug)
Shell size :
8, 10, 1 1 18
2, 4,
Contact type
E
= Handsolder contacts /
R
= Crimp contacts* /
D
= PC tail contacts*
Insert arrangement -
see previous page
Contact gender
:
P
= Pin contacts /
S =
Socket contacts
Insert rotatioon : No digit =
Normal /
W, X, Y, Z =
Different orientations - see below
* Please consult factory
UTS
UTS
7
6
-
JC
8
8
E
E
2
2
P
S
-
-
Insert orientation*
(viewed from front face of male insert)
Normal
W
X
Y
Z
Shell sizes
Angle
in
degree
2
W
X
Y
Z
58°
1
22°
-
-
3
60°
210°
-
-
8
Layouts
3A (98)*
1
0
Layouts
4
45°
-
-
-
33
90°
-
-
-
6
90°
-
-
-
7*
90°
-
-
-
98
90°
180°
240°
1
2
Layouts
3
-
-
180°
1
4
Layouts
2
-
-
-
-
1
4*
45
-
-
-
5
40°
92°
184°
273°
1
2
43°
90°
-
-
1
5
1
7°
1
10°
1
55°
234°
18
1
5°
90°
180°
270°
19
30°
165°
31
5°
-
1
1
62°
1
19°
241°
340°
1
8
Layouts
32
85°
1
38°
222°
265°
30
180°
193°
285°
350°
8
90°
1 2°
1
203°
292°
10
60°
1
55°
270°
295°
60°
210°
-
-
270°
-
* 8-98 layout, W and X non standard ortientations / 10-7 & 1 4 layouts, X non standard orientation
2-1
Range presentation
Square flange receptacle with handsolder contacts
C
4 holes ØG
±0.1
Panel Cut out
ØG
±0.1
J
E
±0.25
F
±0.25
E
±0.25
H
Shell
ØD
±0.15
I
B
A
E
±0.25
E
±0.25
F
±0.25
Part numbers
Male contact
UTS0 8E - - P
UTS0 10E - - P
UTS0 1 - - P
2E
UTS0 1 - - P
4E
UTS0 18E - - P*
Female contact
UTS0 8E - - S
UTS0 10E - - S
UTS0 1 - - S
2E
UTS0 1 - - S
4E
UTS0 18E - - S*
Shell
size
8
10
1
2
1
4
18
A
max.
21.50
21.50
21.50
21.50
21.50
B
2.30
2.30
2.30
2.30
2.50
C
max.
1
1.70
1
1.50
1
1.50
1
1.50
1
1.50
ØD
1
1.92
1
4.93
19.00
22.1
7
28.52
E
1
5.10
18.30
20.60
23.00
27.00
F
20.55
23.80
26.20
28.60
33.30
G
3.20
3.20
3.20
3.20
3.20
H
10.67
1
4.30
1
7.50
20.70
27.00
ØI
1
4.50
1
7.80
22.20
25.50
31.80
ØJ
1
1.50
1
5.10
18.20
21.4
27.80
Note : all dimensions are in mm / * Please consult factory
UTS Hi seal
Jam nut receptacle with handsolder contacts
B max.
C max.
D
±0.25
E
±0.3
Panel Cut out
G
±0.20
Thread
O’Ring
Insert
(see tightening torque)
Nut
Part numbers
Male contact
UTS7 8E - - P
UTS7 10E - - P
UTS7 1 - - P
2E
UTS7 1 - - P
4E
UTS7 18E - - P*
Female contact
UTS7 8E - - S
UTS7 10E - - S
UTS7 1 - - S
2E
UTS7 1 - - S
4E
UTS7 18E - - S*
Shell
size
8
10
1
2
1
4
18
ØA
1
2.00
1
4.90
19.00
22.20
28.50
B max.
19.30
19.30
19.30
19.30
19.30
C max.
3.20
3.20
3.20
3.20
3.20
D
24.00
27.00
31.80
34.90
41.30
E
19.30
22.20
27.00
30.20
36.60
F
1
3.75
16.50
21.20
24.30
30.60
ØG
1
4.60
1
7.70
22.50
25.70
32.00
Tightening
torque
2 Nm
3 Nm
4 Nm
5 Nm
5 Nm
Cable plug with handsolder contacts
B
Coupling nut
Capacity C
Backshell body
Backshell
nut
Insert
Plug
Backshell
Hexagon
Part numbers
Male contact
UTS6 JC 8E - - P
UTS6 JC 10E - - P
UTS6 JC 1 - - P
2E
UTS6 JC 1 - - P
4E
UTS6 JC 18E - - P*
Female contact
UTS6 JC 8E - - S
UTS6 JC 10E - - S
UTS6 JC 1 - - S
2E
UTS6 JC 1 - - S
4E
UTS6 JC 18E - - S*
Shell size
8
10
1
2
1
4
18
Ø A max.
22.50
26.70
30.1
5
35.10
42.00
B min.
50.00
63.20
66.70
71.50
81.30
Capacity C
Standard seal
2.5 / 6.5
2.5 / 8
5/1
2
7/1
4
9 / 18
Capacity C
Reducing seal
1.5 / 5
1.5 / 5
3/9
5/1
2
7 / 16
Hexagon
16
18.5
24
26
33
Several accessories are available, please refer to the UTS catalogue.
For further information, visit our website
www.souriau-industrial.com
or contact us at
contactindustry@souriau.com
Note : all dimensions are in mm / * Please consult factory
INDUTSHSFL01EN © Copyright SOURIAU - All information in this publication presents only general particulars and shall not form part of any contract. All rights reserved to SOURIAU for changes without prior notification or public announcement.
