Taping Fuse Clip
Features
1. These parts can be mounted automatically using a
conventional automatic parts mounter.
2. Dual contact construction provides improved contact
reliability.
3. These products comply with EIAJ standard RC-1008B.
Products Variation
Product Packing Style/Part Number
Applicable Radial
Taping Part Insert
Rating and
Applicable Fuse
Zig-Zag Fold
Reel Winding(A)
Reel Winding(B)
Separately
AC250V 7.5A
DC250V 7.5A
ø5.2X20
PFC5000-0202
PFC5000-0102
PFC5000-0112
FUSE HOLDERS
Panasert
Avisert
etc.
PFC5000-0301
AC250V 10A
DC250V 10A
ø6.35X31.8
ø6.4X30
AC250V 7.5A
DC250V 7.5A
ø5.2X20
PFC6000-0202
PFC6000-0102
PFC6000-0112
PFC6000-0301
Avisert
PFC5000-1001
Taping Fuse Clip / PFC5000,PFC6000 Series
Product Forms
Zig-Zag Fold Type
PFC5000-0202
PFC6000-0202
B
325 max.
340 max.
A
Stopper
(Rear in relation to draw out direction)
B
55 max.
A
Stopper
(Forward in relation to draw out direction)
Draw out direction
Draw out direction
Reel Winding Type
FUSE HOLDERS
PFC5000-01 2
PFC6000-01 2
56 max.
t5
ø350
Draw out direction
ø30
Draw out direction
Stopper typeA
(Forward in
relation to
draw out
direction)
Stopper
(Product
direction
typeA)
Stopper
(Product
direction
typeB)
Stopper typeB
(Rear in
relation to
draw out
direction)
Product
No.
Product
Direction
0
1
A
B
Single Piece Type
PFC5000-0301
PFC6000-0301
5.2
2.8
4.5
0.6
5.85
3.4
4.5
0.6
6.8
8
5.64
4.8
4
5.2
5
5.9
5
4
7.6
9
Taping Fuse Clip
Taping Forms
PFC5000 Series
Applicable Fuse ø5.2X20(m/m)
(Recommended P.W.Board Dimension)
19.8
5.2
2.8
1.0 max.
4.8
Fuse stopper
6.8
8
4.5
12.7
0.6
5
5
4-ø1.05
1.5 max.
18
9
6
0.5
5.2
18
ø4
5
6.35
P 12.7
Hole Form
ø1.05
FUSE HOLDERS
PFC6000 Series
PFC6000 (Recommended Dimension)
Applicable Fuse ø6.35X31.8(m/m)ø6.4X30(m/m)
L Dimension
31.1
Applicable Fuse
ø6.35X31.8
ø6.4X30
5.85
3.4
1.0 max.
5.64
Fuse stopper
4.5
12.7
0.6
7.6
9
30.3
(Recommended P.W.Board Dimension)
1.5 max.
0.5
5.9
18
9
6
L
5
5
6.35
P 12.7
18
5
ø4
4-ø1.05
Hole Form
ø1.05
Specifications
1. Rating Voltage
2. Current
3.
4.
5.
6.
7.
Contact Resistance
Singular Insertion Force
Singular Pull Out Force
Taping Dimension
Applicable Fuse
250V AC 250V DC
7.5A(Applicable fuse ø5.2X20)
10A(Applicable fuse ø6.4X30)
30mΩ max.
8N max.
1~8N
EIAJ RC-1008B
ø5.2X20mm(PFC5000)
ø6.35X31.8mm, ø6.4X30mm
(PFC6000)
Taping Fuse Clip For Avisert Machine
Product Forms
PFC5000-1001
B
325 max.
340 max.
A
Stopper
(Rear in relation to draw out direction)
B
55 max.
Stopper
(Forward in relation to draw out direction)
A
Draw out direction
Draw out direction
Taping Forms
Applicable Fuse ø5.2X20(m/m)
5.2
4.8
2.5
7.8
4.1
12.7
2.0 max.
(0.2)
5.7
4.5
1.7
1.3
22
ø0.7
Fuse stopper
4-ø1.0
t 0.3
4.7
(0.5)
6
9
18
5.2
1.0 max.
5
5
(Recommended P.W.Board Dimension)
Hole Form
ø1.0
18
ø4
3.85
5
12.7
Specification
1. Rating Voltage
2. Current
3. Contact Resistance
4. Singular Insertion Force
5. Singular Pull Out Force
6. Taping Dimension
7. Applicable Fuse
250V AC 250V DC
7.5A
30mΩ max.
10N max.
1~10N
EIAJ RC-1008B
ø5.2X20mm
FUSE HOLDERS
