F-213-1
MMTDT–02–24–F–03.00–S
(2,54 mm) .100"
MMTD, MMTDT, MMTS, MMTST, IPM1, T1M74 SERIES
MMTD–10–20–L–03.25–D–TDS
DISCRETE WIRE JUMPER CABLE
Mates with:
MMSD(T), MMSS(T)
–TXS Mates with:
IPL1
TYPE
PINS PER
ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLY
LENGTH
END
OPTION
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?MMTD,
www.samtec.com?MMTDT,
www.samtec.com?MMTS or
www.samtec.com?MMTST
Insulator Material:
Nylon, White
Contact Material:
Phosphor Bronze
Wire:
20 to 30 AWG
Plating:
Au over 50µ" (1,27 µm) Ni
Operating Temp Range:
-35°C to +105°C (20-26 AWG)
-35°C to +80°C (28-30 AWG)
-55°C to +125°C (*Teflon
®
)
Voltage Rating:
600 VAC
RoHS Compliant:
Yes
MMTD
= Double Row
PVC Cable
MMTDT
= Double Row
*Teflon
®
Cable
(24, 28 & 30 Wire
Gauge only)
–02,
–05, –10,
–15, –16,
–20, –25
MMTD(T)
(7,62)
.300
–20
–22
–24
–24C
= Color
Coded
Cable
–“XX.XX”
–S
= Single
End
–F
= Gold flash
on contact
–L
= 10µ" (0,25 µm)
Gold on contact
= Assembly
Length in
Inches
–S= (76,2 mm)
03.00" min.
–D= (82,6 mm)
03.25" min.
(2,54)
01
.100
(Only available
with –D)
–D
= Double
End
–TUS
= Socket
on End 2,
latch up
MMTS
= Single Row
PVC Cable
(8,89)
.350
–26
–28
–30
No. of positions x (2,54) .100
+ (1,78) .070
–TDS
10
= Socket
on End 2,
latch down
11
MMTST
= Single Row
Length
*Teflon
®
Cable
± (3,18)
(24, 28 & 30 Wire
.125
Gauge only)
Assembly
(7,62)
.300
(2,54)
.100
20
(17,53)
.690
APPLICATION
SPECIFIC OPTION
• Different pin counts and
wiring configurations.
• Other color coded cables.
• Other Gold platings
• Panel Mount options.
• Guide Post options.
Call Samtec.
(5,08)
.200
MMTS(T)
CURRENT RATING (PER CONTACT)
WIRE GAUGE MMTD/MMTDT/MMTS/MMTST
20 AWG
3.8A
26 AWG
2.6A
28 AWG
2.2A
6 CONTACTS
–TUS OPTION
• Individually
shrouded contacts
• Metal latches
APPLICATION
–24C CABLE
COLOR CODING
(PVC CABLE ONLY)
PIN
COLOR
1
2
3
4
5
6
7
8
9
10
ETC
BROWN
RED
ORANGE
YELLOW
GREEN
BLUE
VIOLET
GRAY
WHITE
BLACK
REPEAT
TYPE
POSITIONS
PER ROW
ROW
OPTION
TYPE
WIRE
GAUGE
PLATING
OPTION
IPM1
= Body,
Loose
–02,
–05, –10,
–15, –16,
–20, –25
(5,08)
.200
–S
= Single
Row
–01
T1M74-L
= Contact,
Loose
= 26 to 30 AWG
–F
= Gold flash
on contact
–D
= Double
Row
–02
= 20 to 24 AWG
–L
= 10µ" (0,25 µm)
Gold on contact
T1M74-R
= Contact,
Full Reel
(15,300 Parts
per Reel)
(19,33)
.761
(1,57)
.062
DIA
(3,81)
.150
(3,17)
.125
(7,62)
.300
*DuPont
™
Teflon
®
is a
registered trademark of the
E.I. du Pont de Nemours
and Company or its affiliates.
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
–D
(17,53)
.690
HAND TOOLS
20 to 24 AWG:
CAT-HT-174-2024-11
26 to 30 AWG:
CAT-HT-174-2630-11
–S
(1,91)
