Wirewound
Audio Attenuators
Presents constant impedance to source (Amplifier). Used in audio circuits where output
(Speaker) impedance is not critical
1.375 Approx.
1.219
3/8-32
Thd.
1.625
Dia.
1.562
.250 Dia.
* Shaft length on L8A is 1.500"
2.375
1.125
4 Watts
15 Watts
Mounting plate to terminals,
high pot test for 1 minute
@ 900 VAC
Insulation Resistance:
1000 megohms minimum
(50% relative humidity @ 25gC)
Operating Temperature: -55gC to +105gC
Operating Life:
10,000 cycles standard
Mechanical Rotation:
294g 5g
Bushing Information:
Thread: 3/8-32 NEF-2A
Contact Arm:
Insulated from case
Terminals:
Solder Lug
Power Rating:
Continuous Audio:
Dielectric Strength:
Ohms
Rating
Catalog Number
4
8
8
15
50
600
2000
L4
L8
L8A *
L15
L50
L600
L2000
MGL Pad Attenuator
Amp
Spkr
O
LE
Two L pads in tandem for Stereo Level Control
Power Rating:
Continuous Audio:
Dielectric Strength:
1.625
Dia.
2.250
12.5 Watts
50 Watts
Mounting plate to terminals,
high pot test for 1 minute
@ 900 VAC
Insulation Resistance:
1000 megohms minimum
(50% relative humidity @ 25gC)
Operating Temperature: -55gC to +250gC
Operating Life:
10,000 cycles standard
Mechanical Rotation:
294g 5g
Bushing Information:
Thread: 3/8-32 NEF-2A
Contact Arm:
Insulated from case
Terminals:
Solder Lug
Power Rating:
Continuous Audio:
Dielectric Strength:
TE
Ohms
Rating
Same as L Pad but with glass element for higher wattage
Catalog Number
8
16
MGL8
MGL16
LL Pad Attenuator
1.375 Approx.
1.219
1.562
3/8-32
Thd.
O
BS
.250 Dia.
2.375
4 Watts
15 Watts
Mounting plate to terminals,
high pot test for 1 minute
@ 900 VAC
Insulation Resistance:
1000 megohms minimum
(50% relative humidity @ 25gC)
Operating Temperature: -55gC to +105gC
Operating Life:
10,000 cycles standard
Mechanical Rotation:
294g 5g
Bushing Information:
Thread: 3/8-32 NEF-2A
Contact Arm:
Insulated from case
Terminals:
Solder Lug
Ohms
Rating
Catalog Number
4
8
16
LL4
LL8
LL16
MGLL Pad Attenuator
Same as LL Pad but with glass element for higher wattage
Power Rating:
Continuous Audio:
Dielectric Strength:
Amp
#1
Spkr
#1
#2
#2
12.5 Watts
50 Watts
Mounting plate to terminals,
high pot test for 1 minute
@ 900 VAC
Insulation Resistance:
1000 megohms minimum
(50% relative humidity @ 25gC)
Operating Temperature: -55gC to +105gC
Operating Life:
10,000 cycles standard
Mechanical Rotation:
294g 5g
Bushing Information:
Thread: 3/8-32 NEF-2A
Contact Arm:
Insulated from case
Terminals:
Solder Lug
Ohms
Rating
Catalog Number
8
MGLL8
All Audio Attenuators are supplied with palnut and dial plate.
Dial Plate 395 for Mono and Dial Plate 495 for Stereo.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Wirewound
Audio Attenuators
T Pad Attenuator
1.375 Approx.
Presents constant impedance to both source (Amplifier) and output (Speaker)
Power Rating:
Continuous Audio:
Dielectric Strength:
1.625
Dia.
.250 Dia.
1.219
1.562
3/8-32
Thd.
2.375
1.687
Amp
Spkr
22.5
g
22.5
g
O
LE
Power Rating:
Continuous Audio:
Dielectric Strength:
1.889
Presents constant impedance to both source (Amplifier) and output (Speaker)
.725
1.015
3/8-32
Thd.
.250
Dia
1.328
1.500
3 Watts
10 Watts
Mounting plate to terminals,
high pot test for 1 minute
@ 900 VAC
Insulation Resistance:
1000 megohms minimum
(50% relative humidity @ 25gC)
Operating Temperature: -30gC to +105gC
Operating Life:
10,000 cycles standard
Mechanical Rotation:
300g 5g
Bushing Information:
Thread: 3/8-32 NEF-2A
Contact Arm:
Insulated from case
Terminals:
Solder Lug
TE
RT Pad Attenuator
Ohms
Rating
4 Watts
15 Watts
Mounting plate to terminals,
high pot test for 1 minute
@ 900 VAC
Insulation Resistance:
1000 megohms minimum.
(50% relative humidity @ 25gC)
Operating Temperature: -55gC to +105gC
Operating Life:
10,000 cycles standard.
Mechanical Rotation:
294g 5g
Bushing Information:
Thread: 3/8-32 NEF-2A
Contact Arm:
Insulated from case
Terminals:
Solder Lug
Ohms
Rating
Catalog Number
8
50
600
T8
T50
T600
Catalog Number
8
RT8
Amp
O
BS
Spkr
22.5
g
22.5
g
Stereo Level Control
50 Ohm tandem dual level control for lower priced 4 and 8 Ohm stereo speakers
3 Watts
10 Watts
Mounting plate to terminals,
high pot test for 1 minute
@ 900 VAC
Insulation Resistance:
1000 megohms minimum
(50% relative humidity @ 25gC.)
Operating Temperature: -30gC to +105gC.
Operating Life:
10,000 cycles standard
Mechanical Rotation:
300g 5g
Bushing Information:
Thread: 3/8-32 NEF-2A
Insulated from case
Contact Arm:
Terminals:
Solder Lug
Power Rating:
Continuous Audio:
Dielectric Strength:
.725
1.015
3/8-32
Thd.
Ohms
Rating
Catalog Number
50
RR50
.250
Dia
1.328
1.500
1.256
Amp
Spkr
#1
#2
#1
#2
All Audio Attenuators are supplied with palnut and dial plate.
Dial Plate 395 for Mono and Dial Plate 495 for Stereo.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
