RADIAL CONFORMAL COATED INDUCTORS
ARCC SERIES
*RoHS COMPLIANT
Size Varies
| | | | | | | | | | | | | | |
STANDARD SPECIFICATIONS:
Part
Number
L
( H)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
Q
L
SRF DCR
I
DC
(mA)
(MAX)
(MIN) Test
(MIN)
(MHz) (MHz) (MAX)
-0405,-0606,-0607,-0810,-0909
-0405,-0606,-0607,-0810,-0909
Part
Number
L
( H)
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
Q
(MIN)
L
SRF DCR
I
DC
(mA)
(MAX)
Test (MIN)
(MHz) (MHz) (MAX)
ARCC-XXX-100K
ARCC-XXX-120K
ARCC-XXX-150K
ARCC-XXX-180K
ARCC-XXX-220K
ARCC-XXX-270K
ARCC-XXX-330K
ARCC-XXX-390K
ARCC-XXX-470K
ARCC-XXX-560K
ARCC-XXX-680K
ARCC-XXX-820K
ARCC-XXX-101K
ARCC-XXX-121K
ARCC-XXX-151K
ARCC-XXX-181K
ARCC-XXX-221K
ARCC-XXX-271K
ARCC-XXX-331K
ARCC-XXX-391K
20
20
20
20
20
20
20
20
20
20
15
15
25
25
25
30
30
30
35
35
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
17.0
14.0
12.0
10.5
10.0
9.5
8.5
8.0
7.0
6.8
6.5
6.3
6.0
5.4
4.75
4.0
3.85
3.6
3.3
3.0
0.19
0.22
0.24
0.26
0.29
0.32
0.34
0.42
0.47
0.52
0.58
0.64
0.85
1.00
1.20
1.50
1.65
2.15
2.90
3.25
780
730
650
610
540
480
440
440
375
340
320
285
260
240
215
195
180
160
145
135
ARCC-XXX-471K
ARCC-XXX-561K
ARCC-XXX--681K
ARCC-XXX-821K
ARCC-XXX-120K
ARCC-XXX-122K
ARCC-XXX-152K
ARCC-XXX-182K
ARCC-XXX-222K
ARCC-XXX-272K
ARCC-XXX-332K
ARCC-XXX-392K
ARCC-XXX-472K
ARCC-XXX-562K
ARCC-XXX-682K
ARCC-XXX-822K
ARCC-XXX-103K
ARCC-XXX-123K
ARCC-XXX-153K
35
40
40
40
45
45
45
45
45
40
40
40
40
40
40
40
25
25
20
0.796
0.796
0.796
0.796
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.0796
0.0796
0.0796
2.8
2.4
2.2
2.0
1.8
1.7
1.5
1.3
1.2
0.8
0.7
0.7
0.6
0.5
0.4
0.4
0.3
0.2
0.1
4.05
4.45
5.85
6.60
8.90
10.5
11.9
16.5
19.0
32.0
34.0
38.0
56.0
63.0
70.0
77.0
95.0
110
160
125
115
105
95
85
75
69
60
58
52
48
45
40
37
34
31
28
25
21
TECHNICAL INFORMATION:
•
Inductance (L) tolerance: J = 5%, K = 10%, M = 20%
•
Letter suffix indicates standard tolerance
•
Current rating at which inductance (L) drops 10%
•
Operating temperature -40
o
C to 85
o
C
•
Dimensions: inches / mm; see spec sheet for tolerance limits
•
Specifications subject to change without notice
Note:
All specifications subject to change
without notice.
PHYSICAL CHARACTERISTICS:
A
B
C
0.6
5.5+0.1
A
5
ARCC-0405
ARCC-0606
ARCC-0607
ARCC-0810
ARCC-0909
0.213 (5,4)
0.252 (6,4)
0.292 (7,4)
0.394 (10,0)
0.370 (9,4)
B
5
0.173 (4,4)
0.236 (6,0)
0.244 (6,2)
0.315 (8,0)
0.354 (9,0)
C
5
0.276 (7,0)
0.394 (10,0)
0.394 (10,0)
0.394 (10,0)
0.532 (13,5)
5.0+0.1
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Revised: 12.18.06
