MIC2295BD5TR

Description
Switching Regulator, Current-mode, 2.5A, 1350kHz Switching Freq-Max, PDSO5, TSOT-23, 5 PIN
CategoryPower/power management    The power supply circuit
File Size403KB,12 Pages
ManufacturerMicrel ( Microchip )
Websitehttps://www.microchip.com
Download Datasheet Parametric Compare View All

MIC2295BD5TR Overview

Switching Regulator, Current-mode, 2.5A, 1350kHz Switching Freq-Max, PDSO5, TSOT-23, 5 PIN

MIC2295BD5TR Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMicrel ( Microchip )
Parts packaging codeSOT-23
package instructionTSOT-23, 5 PIN
Contacts5
Reach Compliance Codenot_compliant
ECCN codeEAR99
Other featuresALSO HAS OUTPUT VOLTAGE ADJUSTABLE TO 34V
Analog Integrated Circuits - Other TypesSWITCHING REGULATOR
control modeCURRENT-MODE
Control TechnologyPULSE WIDTH MODULATION
Maximum input voltage10 V
Minimum input voltage2.5 V
Nominal input voltage3.6 V
JESD-30 codeR-PDSO-G5
JESD-609 codee0
length2.9 mm
Humidity sensitivity level1
Number of functions1
Number of terminals5
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Maximum output current2.5 A
Package body materialPLASTIC/EPOXY
encapsulated codeHVSSOP
Package shapeRECTANGULAR
Package formSMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE, SHRINK PITCH
Certification statusNot Qualified
Maximum seat height1 mm
surface mountYES
Switch configurationBOOST
Maximum switching frequency1350 kHz
Temperature levelAUTOMOTIVE
Terminal surfaceTin/Lead (Sn85Pb15)
Terminal formGULL WING
Terminal pitch0.95 mm
Terminal locationDUAL
width1.6 mm
MIC2295
High Power Density 1.2A
Boost Regulator
General Description
The MIC2295 is a 1.2Mhz, PWM dc/dc boost switching
regulator available in low profile Thin SOT23 and 2mm x
2mm MLF™ package options. High power density is
achieved with the MIC2295’s internal 34V / 1.2A switch,
allowing it to power large loads in a tiny footprint.
The MIC2295 implements constant frequency 1.2MHz
PWM current mode control. The MIC2295 offers internal
compensation that offers excellent transient response and
output regulation performance.
The high frequency
operation saves board space by allowing small, low-profile
external components. The fixed frequency PWM scheme
also reduces spurious switching noise and ripple to the
input power source.
The MIC2295 is available in a low-profile Thin SOT23 5-
lead package and a 2mm x2mm 8-lead MLF™ leadless
package. The 2mm x 2mm MLF™ package option has an
output over-voltage protection feature.
The MIC2295 has an operating junction temperature range
of –40°C to +125°C
Features
2.5V to 10V input voltage range
Output voltage adjustable to 34V
1.2A switch current
1.2MHz PWM operation
Stable with small size ceramic capacitors
High efficiency
Low input and output ripple
<1µA shutdown current
UVLO
Output over-voltage protection (MIC2295BML)
Over temperature shutdown
Thin SOT23-5 package option
2mm x 2mm leadless 8-lead MLF™ package option
–40
o
C to +125
o
C junction temperature range
Applications
Organic EL power supplies
3.3V to 5V/500mA conversion
TFT-LCD bias supplies
Flash LED drivers
Positive and negative output regulators
SEPIC converters
Positive to negative Cuk converters
12V supply for DSL applications
Multi-output dc/dc converters
10µH
V
OUT
15V/100mA
L1
10µH
V
OUT
5V/500mA
V
IN
1-Cell
Li Ion
3V to 4.2V
MIC2295BML
SW
VIN
OVP
FB
EN
C1
2.2µF
AGND
PGND
R2
4.53K
MIC2295 BD5
R1
49.9k
2.2µF
VIN
V
IN
1-Cell
Li Ion
EN
C1
2.2µF
SW
FB
R1
10k
10µF
R2
3.3k
GND
MLF and
MicroLeadFrame
is a trademark of Amkor Technology
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1 (
408
) 944-0800 • fax + 1 (408) 474-1000 • http://www.micrel.com
April 2005
M9999-042605
(408) 955-1690

MIC2295BD5TR Related Products

MIC2295BD5TR MIC2295YD5TR MIC2295BMLTR
Description Switching Regulator, Current-mode, 2.5A, 1350kHz Switching Freq-Max, PDSO5, TSOT-23, 5 PIN 2.5A SWITCHING REGULATOR, 1350kHz SWITCHING FREQ-MAX, PDSO5, LEAD FREE, TSOT-23, 5 PIN Switching Regulator, Current-mode, 2.5A, 1350kHz Switching Freq-Max, PDSO8, 2 X 2 MM, MLF-8
Is it Rohs certified? incompatible conform to incompatible
Maker Micrel ( Microchip ) Micrel ( Microchip ) Micrel ( Microchip )
Parts packaging code SOT-23 SOT-23 DFN
package instruction TSOT-23, 5 PIN VSSOP, 2 X 2 MM, MLF-8
Contacts 5 5 8
Reach Compliance Code not_compliant compliant not_compliant
ECCN code EAR99 EAR99 EAR99
Other features ALSO HAS OUTPUT VOLTAGE ADJUSTABLE TO 34V ALSO HAS OUTPUT VOLTAGE ADJUSTABLE TO 34V ALSO HAS OUTPUT VOLTAGE ADJUSTABLE TO 34V
Analog Integrated Circuits - Other Types SWITCHING REGULATOR SWITCHING REGULATOR SWITCHING REGULATOR
control mode CURRENT-MODE CURRENT-MODE CURRENT-MODE
Control Technology PULSE WIDTH MODULATION PULSE WIDTH MODULATION PULSE WIDTH MODULATION
Maximum input voltage 10 V 10 V 10 V
Minimum input voltage 2.5 V 2.5 V 2.5 V
Nominal input voltage 3.6 V 3.6 V 3.6 V
JESD-30 code R-PDSO-G5 R-PDSO-G5 S-PDSO-N8
JESD-609 code e0 e4 e0
length 2.9 mm 2.9 mm 2 mm
Humidity sensitivity level 1 1 1
Number of functions 1 1 1
Number of terminals 5 5 8
Maximum operating temperature 125 °C 125 °C 125 °C
Minimum operating temperature -40 °C -40 °C -40 °C
Maximum output current 2.5 A 2.5 A 2.5 A
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
encapsulated code HVSSOP VSSOP HVSON
Package shape RECTANGULAR RECTANGULAR SQUARE
Package form SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE, SHRINK PITCH SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
Certification status Not Qualified Not Qualified Not Qualified
Maximum seat height 1 mm 1 mm 0.95 mm
surface mount YES YES YES
Switch configuration BOOST BOOST BOOST
Maximum switching frequency 1350 kHz 1350 kHz 1350 kHz
Temperature level AUTOMOTIVE AUTOMOTIVE AUTOMOTIVE
Terminal surface Tin/Lead (Sn85Pb15) Nickel/Palladium/Gold (Ni/Pd/Au) Tin/Lead (Sn80Pb20)
Terminal form GULL WING GULL WING NO LEAD
Terminal pitch 0.95 mm 0.95 mm 0.5 mm
Terminal location DUAL DUAL DUAL
width 1.6 mm 1.6 mm 2 mm
