WKP
Vishay Draloric
Ceramic AC Capacitors
Class X1, 760 V
AC
/Class Y1, 500 V
AC
D Max.
S Max.
DESIGN
Disc capacitors with epoxy coating
3 Max.
RATED VOLTAGE U
R
(X1):
(Y1):
760 V
AC
, 50 Hz (IEC 60384-14.2)
500 V
AC
, 50 Hz (IEC 60384-14.2)
250 V
AC
, 60 Hz (UL1414, CSA C22.2)
F
±
1.0
L = 30
- 3
or
L = 10
±
1
DIELECTRIC STRENGTH BETWEEN LEADS
V
±
0.5
Component test:
4000 V
AC
, 50 Hz, 2 s
As repeated test admissible only once with:
3600 V
AC
, 50 Hz, 2 s
Random sampling test (destructive test):
4000 V
AC
, 50 Hz, 60 s
Ø d
±
0.005
Dimensions in mm
Note
Impedance (Z) as a function of frequency (f) at T
a
= 20 °C (average).
Measurement with lead length 6 mm.
Z [Ω]
10
1
DIELECTRIC STRENGTH OF BODY
INSULATION
4000 V
AC
, 50 Hz, 60 s (destructive test)
10
0
4700 pF
3900
3300
2200
1500
1000
680
470
330
220
150
100
68
47
33 pF
DISSIPATION FACTOR tan
δ
≤
25 x 10
-3
INSULATION RESISTANCE R
IS
≥
10 x 10
9
Ω
10
-1
CATEGORY TEMPERATURE RANGE
ϑ
A
(- 40 to + 125) °C
CLIMATIC CATEGORY ACC. TO EN60068-1
10
-2
1
I = f (U
R
) (typ.)
I~ [µA]
800
10
f
100
300
[MHz]
40/125/21
COATING
Epoxy dipped, insulating, flame retarding acc. to UL 94V-0
4.7 nF
700
600
500
400
300
200
100
470 pF
0
1
50
100 150
200
250
300
350 400
U
R
[V~]
1.0 nF
2.2 nF
3.3 nF
TAPING AND SPECIAL LEAD
CONFIGURATIONS
On request
MARKING
WKP
760 ~ X1
500 ~ Y1
47p M
WKP
3n3 M
IEC 384-14/2
760 500 250
~
X1 Y1
WKP 33 pF to 1.5 nF
Note
WKP 2.2 nF to 4.7 nF
• All approval marks are also shown on the label.
Document Number: 22206
Revision: 08-Feb-10
For technical questions, contact:
slcap@vishay.com
www.vishay.com
1
WKP
Vishay Draloric
Ceramic AC Capacitors
Class X1, 760 V
AC
/Class Y1, 500 V
AC
ORDERING INFORMATION, CERAMIC X1/Y1 CAPACITORS WKP
CAPACITANCE
(2)
TOL.
Dxs
F ± 1
(1)
d ± 0.05
(1)
V ± 0.5
(1)
ORDERING CODE
(pF)
(%)
(mm)
(mm)
(mm)
(mm)
CLASS 1 N 750
33
± 10 , ± 20
8.0 x 6.0
12.5
0.6
1.9
WKP330 CP
KR
CLASS 2 K 1200
47
WKP470 CP
KR
± 10 , ± 20
8.0 x 6.0
12.5
0.6
2.3
68
WKP680 CP
KR
CLASS 2 K 1500
100
± 10 , ± 20
8.0 x 6.0
12.5
0.6
2.3
WKP101 CP
KR
CLASS 2 K 2000
150
WKP151 CP
KR
± 10 , ± 20
8.0 x 6.0
12.5
0.6
2.3
220
WKP221 CP
KR
CLASS 2 K 4000
330
WKP331 CP
KR
8.0 x 6.0
0.6
2.5
470
WKP471 CP
KR
680
9.0 x 6.0
WKP681 CP
KR
1000
10.0 x 6.0
WKP102 CP
KR
± 10 , ± 20
12.5
1500
12.0 x 6.0
WKP152 CP
KR
2200
13.0 x 6.0
WKP222 CP
KR
0.8
2.7
3300
15.0 x 6.0
WKP332 CP
KR
3900
16.0 x 6.0
WKP392 CP
KR
4700
18.0 x 6.0
WKP472 CP
KR
Notes
(1)
Standard lead configuration, other lead spacing and diameter available on request.
(2)
Capacitance values from 470 pF to 4700 pF: The alternative usage of smaller VKP series is recommended for new application.
ORDERING CODE
7
th
digit
R
10
th
to 12
th
digit
14
th
digit
Capacitance Tolerance:
Lead Configuration (see General Information)
RoHS Compliant Component
± 10 % = K
± 20 % = M
APPROVALS
IEC 60384 - 14 / 2
nd
Issue (1993) incl. Am. 1 (1995) - Safety Tests
EN 132 400 (1994) - Safety Tests
THAT APPROVAL TOGETHER WITH THE CB TEST CERTIFICATE SUBSTITUTES THE NATIONAL APPROVAL OF THE FOLLOWING
Belgium
France
Italy
Austria
China
Japan
Spain
Denmark
Greece
Luxembourg
Portugal
Singapore
Poland
United
Germany
Ireland
Netherlands
Sweden
Slovenia
Hungaria
Czech Republic
Finland
Iceland
Norway
Switzerland
Korea
Israel
Y1 - Capacitor: CB-Test Certificate:
DE-1-11002-A1
X1 - Capacitor: CB-Test Certificate:
DE-1-11002-A1
Minimum thickness of insulation: 0.4 mm
UNDERWRITERS LABORATORIES INC.
UL 1414
Across-the-line, Antenna-coupling and Line-by-pass component.
Agency Files / Licences
E 183 844 V1 S1
33 pF ... 4.7 nF
250 V
AC
33 pF ... 4.7 nF
250 V
AC
33 pF ... 4.7 nF
33 pF ... 4.7 nF
500 V
AC
760 V
AC
CANADIAN STANDARDS ASSOCIATION
CSA C22.2
NO 1-98
Across-the-line, antenna-coupling and line-by-pass component
Agency Files / Licences
E 183 844 V1 S1
ORDERING INFORMATION
WKP
SERIES
221
CAP. VALUE
M
TOLERANCE
CP
RATED
VOLTAGE
ED0
LEAD
CONFIGURATION
K
INTERNAL
CODE
R
ROHS
COMPLIANT
www.vishay.com
2
For technical questions, contact:
slcap@vishay.com
Document Number: 22206
Revision: 08-Feb-10
