20 dB Fixed Attenuator, SMA Female To SMA Male
Directional Rated To 50 Watts Up To 18 GHz
TECHNICAL DATA SHEET
Configuration
Design
Connector 1
Connector 2
Body Material and Plating
Fixed, Directional Attenuator
SMA Female
SMA Male
Aluminum Heatsink, Black Anodized
PE7330-20
20 dB Fixed Attenuator, SMA Female To SMA Male Directional Rated To 50 Watts Up To 18 GHz
Electrical Specifications
Frequency Range, GHz
Impedance, Ohms
Attenuation Value, dB
Maximum Input Power, Watts
Maximum VSWR
Frequency 1
Range, GHz
VSWR
Attenuation Accuracy, dB
Frequency 2
Range, GHz
VSWR
Attenuation Accuracy, dB
Frequency 3
Range, GHz
VSWR
Attenuation Accuracy, dB
DC to 18
50
20
50
1.6:1
DC to 6
1.3:1
0.75
6 to 12.4
1.45:1
0.75
12.4 to 18
1.6:1
1.25
Mechanical Specifications
Temperature
Operating Range, deg C
Size
Length, in [mm]
Width, in [mm]
Height, in [mm]
.
-55 to +125
4.01 [101.85]
3 [76.2]
3 [76.2]
1.796 [814.65]
Weight, lbs [g]
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications:
20 dB Fixed Attenuator, SMA Female To SMA Male Directional Rated To 50 Watts Up To 18
GHz PE7330-20
PE7330-20 REV NC
1
20 dB Fixed Attenuator, SMA Female To SMA Male
Directional Rated To 50 Watts Up To 18 GHz
TECHNICAL DATA SHEET
Connector 1
Type
Contact Material and Plating
Coupling Nut Material and Plating
Coupling Nut Plating Specification
Hex Size, In.
Body Material and Plating
SMA Female
Beryllium Copper, Gold
Stainless Steel, Passivated
Stainless Steel
11/16
Stainless Steel, Passivated
PE7330-20
Connector 2
Type
Contact Material and Plating
Outer Conductor Material and Plating
Hex Size, In.
Body Material and Plating
SMA Male
Beryllium Copper, Gold
Stainless Steel, Passivated
11/16
Stainless Steel, Passivated
Compliance Certifications
(visit www.Pasternack.com for current document)
RoHS Compliant
Yes
Plotted and Other Data
Values at 25 °C, sea level
OUTPUT PORT HANDLES 5 WATTS MAX POWER
URL:
http://www.pasternack.com/20db-fixed-sma-female-sma-male-50-watts-attenuator-pe7330-20-p.aspx
20 dB Fixed Attenuator, SMA Female To SMA Male Directional Rated To 50 Watts Up To 18 GHz from Pasternack Enterprises
has same day shipment for domestic and International orders. Our RF, microwave and fiber optic products maintain a 99%
availability and are part of the broadest selection in the industry.
Notes:
PE7330-20 REV NC
2
PE7330-20
CAD Drawing
20 dB Fixed Attenuator, SMA Female To SMA Male
Directional Rated To 50 Watts Up To 18 GHz
© 2012 Pasternack Enterprises All Rights Reserved
PE7330-20 REV NC
3
