8350-132X00 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> socket> 8350-132X00

8350-132X00: DescriptionIC Socket, PGA132, 132 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder; CategoryThe connector socket; File Size97KB，1 Pages; ManufacturerLeoco USA Corp; Websitehttp://www.leoco.com.tw

Download Datasheet Parametric Compare View All

8350-132X00 Overview

IC Socket, PGA132, 132 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder

8350-132X00 Parametric

Parameter Name	Attribute value
Maker	Leoco USA Corp
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	ANTI SOLDER WICKING
body width	1.402 inch
body length	1.402 inch
Contact structure	14X14
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN OVER NICKEL
Contact material	BRASS
Contact style	RND PIN-SKT
current rating	2 A
Device slot type	IC SOCKET
Type of equipment used	PGA132
Dielectric withstand voltage	1000VAC V
Shell material	POLYPHENYLENE SULFIDE
Insulation resistance	500000000 Ω
Manufacturer's serial number	8350
Plug contact pitch	0.1 inch
Installation method	STRAIGHT
Number of contacts	132
Maximum operating temperature	105 °C
Minimum operating temperature	-25 °C
PCB contact pattern	RECTANGULAR
PCB contact row spacing	0.1 mm
Terminal pitch	2.54 mm
Termination type	SOLDER

Preview

Download Datasheet

View All

8350-132X00 Related Products

	8350-132X00	RBR55L20802AP	8350-084X00	8350-068X00	8350-239X00	8350-168X00	8350-191X00	8350-121X00	8350-144X00	8350-169X00
Description	IC Socket, PGA132, 132 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder	RESISTOR, WIRE WOUND, 0.15W, 0.05%, 10ppm, 208000ohm, THROUGH HOLE MOUNT, AXIAL LEADED	IC Socket, PGA84, 84 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder	IC Socket, PGA68, 68 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder	IC Socket, PGA239, 239 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder	IC Socket, PGA168, 168 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder	IC Socket, PGA191, 191 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder	IC Socket, PGA121, 121 Contact(s)	IC Socket, PGA144, 144 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder	IC Socket, PGA169, 169 Contact(s), 2.54mm Term Pitch, 0.1inch Row Spacing, Solder
Reach Compliance Code	unknown	compliant	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Maker	Leoco USA Corp	-	Leoco USA Corp	Leoco USA Corp	Leoco USA Corp	Leoco USA Corp	Leoco USA Corp	Leoco USA Corp	Leoco USA Corp	Leoco USA Corp
Other features	ANTI SOLDER WICKING	ULTRA PRECISION	ANTI SOLDER WICKING	ANTI SOLDER WICKING	ANTI SOLDER WICKING	ANTI SOLDER WICKING	ANTI SOLDER WICKING	-	ANTI SOLDER WICKING	ANTI SOLDER WICKING
body width	1.402 inch	-	1.327 inch	1.126 inch	1.925 inch	1.701 inch	1.9 inch	-	1.5 inch	1.701 inch
body length	1.402 inch	-	1.327 inch	1.126 inch	1.925 inch	1.701 inch	1.9 inch	-	1.5 inch	1.701 inch
Contact structure	14X14	-	13X13	11X11	19X19	17X17	17X17	-	15X15	17X17
Contact to complete cooperation	AU ON NI	-	AU ON NI	AU ON NI	AU ON NI	AU ON NI	AU ON NI	-	AU ON NI	AU ON NI
Contact completed and terminated	TIN OVER NICKEL	-	TIN OVER NICKEL	TIN OVER NICKEL	TIN OVER NICKEL	TIN OVER NICKEL	TIN OVER NICKEL	-	TIN OVER NICKEL	TIN OVER NICKEL
Contact material	BRASS	-	BRASS	BRASS	BRASS	BRASS	BRASS	-	BRASS	BRASS
Contact style	RND PIN-SKT	-	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	-	RND PIN-SKT	RND PIN-SKT
current rating	2 A	-	2 A	2 A	2 A	2 A	2 A	-	2 A	2 A
Device slot type	IC SOCKET	-	IC SOCKET	IC SOCKET	IC SOCKET	IC SOCKET	IC SOCKET	IC SOCKET	IC SOCKET	IC SOCKET
Type of equipment used	PGA132	-	PGA84	PGA68	PGA239	PGA168	PGA191	PGA121	PGA144	PGA169
Dielectric withstand voltage	1000VAC V	-	1000VAC V	1000VAC V	1000VAC V	1000VAC V	1000VAC V	-	1000VAC V	1000VAC V
Shell material	POLYPHENYLENE SULFIDE	-	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE
Insulation resistance	500000000 Ω	-	500000000 Ω	500000000 Ω	500000000 Ω	500000000 Ω	500000000 Ω	-	500000000 Ω	500000000 Ω
Manufacturer's serial number	8350	RBR	8350	8350	8350	8350	8350	-	8350	8350
Plug contact pitch	0.1 inch	-	0.1 inch	0.1 inch	0.1 inch	0.1 inch	0.1 inch	-	0.1 inch	0.1 inch
Installation method	STRAIGHT	-	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	-	STRAIGHT	STRAIGHT
Number of contacts	132	-	84	68	239	168	191	121	144	169
Maximum operating temperature	105 °C	145 °C	105 °C	105 °C	105 °C	105 °C	105 °C	-	105 °C	105 °C
Minimum operating temperature	-25 °C	-65 °C	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C	-	-25 °C	-25 °C
PCB contact pattern	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	RECTANGULAR	RECTANGULAR
PCB contact row spacing	0.1 mm	-	0.1 mm	0.1 mm	0.1 mm	0.1 mm	0.1 mm	-	0.1 mm	0.1 mm
Terminal pitch	2.54 mm	-	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	-	2.54 mm	2.54 mm
Termination type	SOLDER	-	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	-	SOLDER	SOLDER
