PE7342-40: Description40 dB Fixed Attenuator, SMA Female To TNC Male Directional Black Anodized Aluminum Heatsink Body Rated To 50 Watts Up To 18 GHz; CategoryThe connector; File Size347KB，3 Pages; ManufacturerPasternack Enterprises; Websitehttps://www.pasternack.com/

Download Datasheet View All

PE7342-40 Overview

40 dB Fixed Attenuator, SMA Female To TNC Male Directional Black Anodized Aluminum Heatsink Body Rated To 50 Watts Up To 18 GHz

Preview

Download Datasheet

View All

40 dB Fixed Attenuator, SMA Female To TNC Male

Directional Rated To 50 Watts Up To 18 GHz

TECHNICAL DATA SHEET

Configuration

Design

Connector 1

Connector 2

Body Material and Plating

Fixed, Directional Attenuator

SMA Female

TNC Male

Aluminum Heatsink, Black Anodized

PE7342-40

40 dB Fixed Attenuator, SMA Female To TNC Male Directional Rated To 50 Watts Up To 18 GHz

Electrical Specifications

Frequency Range, GHz

Impedance, Ohms

Attenuation Value, dB

Maximum Input Power, Watts

Maximum VSWR

Frequency 1

Range, GHz

VSWR

Attenuation Accuracy, dB

Frequency 2

Range, GHz

VSWR

Attenuation Accuracy, dB

Frequency 3

Range, GHz

VSWR

Attenuation Accuracy, dB

DC to 18

1.6:1

DC to 6

1.3:1

6 to 12.4

1.45:1

1.25

12.4 to 18

1.6:1

1.5

Mechanical Specifications

Temperature

Operating Range, deg C

Size

Length, in [mm]

Width, in [mm]

Height, in [mm]

-55 to +125

4.01 [101.85]

3 [76.2]

1.796 [814.65]

Weight, lbs [g]

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications:

40 dB Fixed Attenuator, SMA Female To TNC Male Directional Rated To 50 Watts Up To 18

GHz PE7342-40

PE7342-40 REV NC
