Z-Power LED X10490
Technical Data Sheet
Binning and Labeling
The Acrich series of LEDs are designed
for AC operation and high flux output
applications. Acrich LEDs are
an environmentally friendly semiconductor
lighting source that can be directly
connected to an AC power source
without any DC conversion required.
Acrich’s thermal management performance exceeds other
power LED solutions by incorporating state-of-the-art SMD
design and use of specialized thermal emission material.
Acrich is an ideal light source for general purpose
illumination applications
This application note provides binning and labeling
information of Acrich series. It includes the Acrich bins for
luminous flux,
wavelength (or x,y coordinates), correlated color
temperature
(CCT) for white.
AX32X0
Features
•
Connect directly in AC
•
Power Saving
•
Long Life Time
•
Simple BOM
•
Miniaturization
• Low thermal resistance
• SMT solderbility
• Lead Free product
• RoHS compliant
Applications
• Architectural lighting
• Task lighting
• Decorative /
Pathway lighting
• Household appliances
Rev. 05
August 2012
www.ACRICH.com
Document No. : SSC-QP-7-07-24 (Rev.00)
Z-Power LED X10490
Z-Power LED X10490
Technical Data Sheet
Full Code of Acriche Series
Full code form : AX
1
X
2
X
3
X
4
X
5
– X
6
X
7
– X
8
X
9
X
10
X
11
X
12
1. Part Number
- A : Acrich
- X
1
: Color
- X
2
: Acrich series number
- X
3
: LENS type
- X
4
: Operating voltage
- X
5
: Type of PCB
2. Internal Number
- X
6
- X
7
3. Code Labeling
- X
8
X
9
: Luminous flux (or Radiant flux for royal blue)
- X
10
X
11
: Dominant wavelength (or x,y coordinates rank code)
- X
12
: Operating voltage (emitter only)
4. Sticker Diagram on Reel & Aluminum Vinyl Bag
PART NO. :
A X
1
X
2
X
3
X
4
X
5
– X
6
X
7
QUANTITY : # # #
LOT NUMBER : # # # # # # # # # #
BIN CODE :
X
8
X
9
X
10
X
11
X
12
Rev. 05
August 2012
2
www.ACRICH.com
Document No. : SSC-QP-7-07-24 (Rev.00)
Z-Power LED X10490
Z-Power LED X10490
Technical Data Sheet
Code Labeling
1. Luminous Flux Bins
- Luminous flux bin structure for pure white, warm white
Example
BIN CODE :
X2B0C
Luminous Flux bin
Bin Code
S
T
U
V
V1
V2
W
W1
W2
X
X1
X2
Y
Z
Luminous Flux [lm]
54.0 ~ 70.0
70.0 ~ 91.0
91.0 ~ 118.5
118.5 ~ 136.0
136.0 ~ 154.0
154.0 ~ 177.0
177.0 ~ 200.0
200.0 ~ 230.0
230.0 ~ 260.0
260.0 ~ 340.0
340.0 ~ 440.0
The list explains the photometric luminous flux bins for Acriche aeries. Acriche series
are tested and binned by photometric luminous flux. Not all bins are available in all
colors.
Tolerance :
±10%
of Luminous flux value
Rev. 05
August 2012
5
www.ACRICH.com
Document No. : SSC-QP-7-07-24 (Rev.00)
