PW117
ITE 6-12 WATT SERIES
PW117 SWITCH-MODE
P O W E R S U P P LY
•
•
•
•
•
•
•
•
•
•
•
PW117
Ault Part No.
Voltage
DC
Max
Amps
Max
Watts
100-240 VAC Universal Input
Desktop Style
Single Output to 6-12W
Regulated Output With Low Ripple
Meets Safety Agency Requirements
Complies With EMI/RFI Regulations
CE Compliant
Impact Resistant Polycarbonate Enclosure
Private Label Marking Available
3 Year Warranty
Modified and Custom Designs
Also Available
PW117XA0303_01
PW117XA0503_01
PW117XA0803_01
PW117XA0903_01
PW117XA1203_01
PW117XA1503_01
PW117XA1803_01
PW117XA2403_01
PW117XA4803_01
3V
5V
7.8V
9V
12V
15V
18V
24V
48V
2.00
2.00
1.28
1.10
0.85
0.70
0.60
0.45
0.25
6.0
10.0
10.0
10.0
10.2
10.5
10.8
10.8
12.0
Ault Part No. Key
Ault Part No. Key
PW117 X
Product
Family
Name
Manufacturing
Location
(volume
dependent)
A
Design
Revision
Changes
05
Voltage
DC
03
Connector
__
Input
Configuration/
Model Type
(see pg. 2)
01
Standard (no
modifications,
special artwork
or special
packaging)
A U LT I N C O R P O R AT E D
7105 Northland Terrace
|
Minneapolis, Minnesota 55428
|
USATEL (1) 763-592-1900
FAX (1) 763-592-1911
|
E-MAIL info@aultinc.com
|
WEB www.aultinc.com
© Copyright 2002 Ault Inc.
PW117
ITE 6-12 WATT SERIES
Input
Voltage
Line Frequency
Current
Protection
100-240 VAC -10%, +6%
47-63 Hz
0.3A max. at 90 VAC input
Internal primary current fuse,
Inrush limiting
Electrical
Topology
Leakage Current
Efficiency
EMI
CE
MTBF
Output
Combined Line and Load
Voltage Regulation
Ripple
Transient Response
Holdup Time
Protection
Cord and Connector
±1% excluding cord
Environmental
1% V p-p max for output current
of >0.175A
0.5 msec. for 50% load change typical
12 msec min. @ 120VAC,
60 msec min. @ 240VAC
Foldback overcurrent protection.
6 ft, 2 conductor, 20 AWG, Ault
#3 connector. Other connectors are
also available.
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
Cooling
0º to 40º C with no derating
-30º to +85º C
5% to 95% non-condensing
0-10,000 feet
Convectional-non vented case
Switching-fixed frequency flyback
Less than 750 uA
Min 65%
Complies with EMC Directives
CE Compliant
100,000 Calculated Hours
Mechanical
Case and Dimensions
3.35L x 1.81W x 1.30H (in)
85.0L x 46.0W x 33.0H (mm)
94V0 polycarbonate; black is standard
color; other colors available - extra
charges may apply
4.80 ounces, 136 grams
Safety Approvals
Agency Listings
cULus 60950, TUV/IEC EN60950,
Australian, Japanese certification
available – extra fees apply
Case Material
Weight
Input Configuration
Connector
IEC320
w/ground
C14
(F)
Shaver
C8
(N)
Specify the Input Configuration Code in your order.
Pinout Code
Description
Suggested Mating
Center contact: positive
Switchcraft 760 plug or equivalent
Switchcraft 712A jack or equivalent
Other Connectors are available by special order
A U LT I N C O R P O R AT E D
7105 Northland Terrace
|
Minneapolis, Minnesota 55428
|
USATEL (1) 763-592-1900
FAX (1) 763-592-1911
|
E-MAIL info@aultinc.com
|
WEB www.aultinc.com
© Copyright 2002 Ault Inc.
