Sparkle Power Inc.
A Leading Power Supply
Manufacturer
www.sparklepower.com
R-FSP700-80ETN
700 Watts ATX12V V2.3 EPS12V V2.92 Switching
Power Supply (Meet 2013 ErP)
Features
(80PLUS Platinum, RoHS Compliant)
•
•
•
•
•
•
•
•
•
•
•
•
•
Complied with ATX12V V2.3 EPS12V V2.92 standard
Active Power Factor Correction (PFC) meet EN61000-3-2
High efficiency and reliability
Compatible with European Union Directive 2002/95/EC (Restriction
on Hazardous Substances).
Remote ON/OFF function
Internal 12V DC fan included
Noise Killer (thermal fan speed control function)
Low noise and ripple
Output over voltage, short circuit, and over current protection
100% Hi-pot, ATE, and burn-in tested
Re-settable power shut down
Complies with FCC part 15 subpart J class B 115Vac operation, and
CISPR 22 class B at 230Vac operation
Approved by CUL/UL60950-1, TUV EN60950-1,CB 60950-1 report,
FCC,EMC.
Specification
•
•
•
•
•
•
•
•
•
Temperature Range:
Operating: +0°C ~ +40°C on full load
Storage & Shipping: -40°C ~ +70°C
Humidity:
5-85% on operating, 5-95% on storage
Efficiency:
89%
minimum, typical up to
92%
Rise time:
15ms maximum
Hold-up Time:
17ms minimum at nominal input voltage
Power Good Signal:
Power on delay time 100 ~ 500ms, off delay
1ms minimum (TTL and CMOS compatible)
Leakage Current:
Less than 3.5mA at 264Vac, 50Hz
MTBF:
100,000 hours on maximum load at +25°C
Dimensions (LxWxH):140x150x85.8mm
/ 5.5x5.9x3.4inch
Input Characteristics
Input Range:
90 ~ 264Vac, Full Range Input
Frequency:
47 ~ 63Hz
Input Current:
10Amp (maximum) at 100-127Vrms/ 60 Hz
5Amp (maximum) at 200-240 Vrms/ 50 Hz.
Inrush Current:
No damage.
Output Characteristics
MINIMUM
LOAD
NORMAL
LOAD
MAXIMUM
LOAD
LOAD
REG.
LINE
REG.
RIPPLE & NOISE
+3.3V
+5V
+12V1
+12V2
+12V3
+12V4
-12V
+5Vsb
0.1A
0.2A
0.1A
0A
0A
0A
0A
0A
10A
9A
9A
9A
9A
9A
0.15A
1.5A
20/3A
6.8/20A
18A
18A
18A
18A
0.3A
3A
±5%
±5%
±5%
±5%
±5%
±5%
±10%
±5%
±1%
±1%
±1%
±1%
±1%
±1%
±2%
±1%
50mV P-P
50mV P-P
120mV P-P
120mV P-P
120mV P-P
120mV P-P
200mV P-P
50mV P-P
(1) +3.3V & +5V total output not exceed 110W.
When +5V is load to 20A, the +3.3V maximum load is 3A.
When +3.3V is load to 20A, the +5V maximum load is 8.8A.
(2) +12V1 & +12V2 & +12V3 & +12V4 total output not exceed 648W(54A).
(3) All outputs shall be safety-isolated from the AC mains and share a
common
return. This common return must be connected to supply chassis.
(4) Voltages and ripple are measured at the load side of mating connectors
with a
0.1uF monolithic ceramic capacitor paralleled by a 10uF electrolytic
capacitor
