10Watts DC-DC Dual Output
Q
ualtek
P
P C
Electronics Corporation
QPDD10-48D Series
Features:
Approved to IEC/EN60950, UL60950 Safety Standards
Wide Input Voltage: 36VDC - 75VDC
Dual Outputs: ±5VDC, ±12VDC, ±15VDC
Remote Control
No Minimum Load Requirement
Model
DC Output
Rated Current
Current Range
Efficiency (Typical)
Ripple and Noise (max)
Voltage Accuracy
Line Regulation (max)
Load Regulation (max)
Temperature Coefficient
QPDD10-48D05
±5V
1A
0~1A
81%
50mVpp
±1.0%
0.2%
0.5%
±0.02%/°C
36VDC~75VDC
48VDC
Postive Logic
Negative Logic
Positive Logic
Negative Logic
QPDD10-48D12
±12V
0.42A
0~0.42A
83%
QPDD10-48D15
±15V
0.33A
0~0.33A
84%
Output Characteristics
Input Characteristics
Voltage Range
Normal Voltage
Remote Control
Control
Voltage
Control
Current
HIGH=ON (3.5VDC to 10VDC); LOW=OFF (-0.7VDC to 0.8VDC)
LOW=ON (-0.7VDC to 0.8VDC); HIGH=OFF (3.5VDC to 10VDC)
2mA max.
4mA max.
Continuous, auto recovery (±5V)
-40°C~55°C
-40°C~100°C
-55°C~125°C
IEC/EN60950, UL60950
Input-Output: 1500VDC. Input-Case: 1500VDC. Output-Case: 1500VDC
More than 2,000,000Hrs
50.8x25.4x10.16mm (2”x1”x0.4”)
50.8 [2.000]
20.32 [0.800]
4
1
2
3
5
20.32 [0.800]
25.4 [1.000]
5.08 [0.200]
Protection
Over Current
Operating Amb. Temp.
Operating Case Temp.
Storage Temp.
Safety Standards
Isolation Voltage (one minute)
MTBF
Dimension (LxWxH)
Environmental Characteristics
General Characteristics
Pin Assignment
Pin No.
1
2
3
4
5
6
Output
+Vin
-Vin
CNT
+Vout
COM
-Vout
6
+0.05
6- 1.0 -0.10
36 [1.417]
1.2 [0.047]
0.5 [0.020]
10.16 [0.400]
Pin Length: 3.8mm
TOLERANCES: X.Xmm = ±0.5mm
X.XXmm = ±0.25mm
Page 1 of 1
L
Unit: mm[inch]
