The MINMAX MIHW1000 series is a range of high performance DC/DC converter modules with a reinforced insulation system .The I/O- isolation voltage is
specified for 4000VACrms.The product comes in a small DIP-24 package. All 20 models features wide 2:1 input voltage range and fully regulated output
voltage.
The MIHW1000 DC/DC converters offer an economical solution for demanding applications in industrial and medical instrumentation requesting a certified
supplementary or reinforced insulation system to comply with relative industrial or medical safety standards.
Model Selection Guide
Model
Number
Input
Voltage
(Range)
VDC
MIHW1002
MIHW1003
MIHW1008
MIHW1006
MIHW1007
MIHW1012
MIHW1013
MIHW1018
MIHW1016
MIHW1017
MIHW1022
MIHW1023
MIHW1028
MIHW1026
MIHW1027
MIHW1032
MIHW1033
MIHW1038
MIHW1036
MIHW1037
VDC
5
12
24
±12
±15
5
12
24
±12
±15
5
12
24
±12
±15
5
12
24
±12
±15
Output
Voltage
Max.
mA
600
250
125
±125
±100
600
250
125
±125
±100
600
250
125
±125
±100
600
250
125
±125
±100
Min.
mA
90
37.5
18.8
±18.8
±15
90
37.5
18.8
±18.8
±15
90
37.5
18.8
±18.8
±15
90
37.5
18.8
±18.8
±15
@Max. Load
mA(typ.)
857
800
800
800
800
338
313
313
313
313
160
151
151
151
151
80
75
75
75
75
@No Load
mA(typ.)
Output Current
Input Current
Reflected
Ripple
Current
mA (typ.)
uF
1000
470
470
220#
220#
1000
470
470
220#
220#
1000
470
470
220#
220#
1000
470
470
220#
220#
# For each output
Max. capacitive
Load
Efficiency
(typ.)
@Max. Load
%
70
75
76
75
75
74
80
81
80
80
78
83
84
83
83
78
83
84
83
83
5
(4.5 ~ 9)
40
60
12
(9 ~ 18)
30
30
24
(18 ~ 36)
20
15
48
(36 ~ 75)
10
10
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2011/09/22 REV:3
Page 1 of 4
®
Input Specifications
Parameter
Model
5V Input Models
Input Surge Voltage (1 sec. max.)
12V Input Models
24V Input Models
48V Input Models
5V Input Models
12V Input Models
24V Input Models
48V Input Models
5V Input Models
12V Input Models
24V Input Models
48V Input Models
Min.
-0.7
-0.7
-0.7
-0.7
Typ.
---
---
---
---
MIHW1000 SERIES
DC/DC CONVERTER 3W,
Reinforced Insulation, Medical Safety
Max.
11
25
50
100
Unit
Start-Up Voltage
Under Voltage Shutdown
Reverse Polarity Input Current
Short Circuit Input Power
Internal Power Dissipation
Conducted EMI
All Models
3.7
4
4.5
8
8.5
9
VDC
15
17
18
30
33
36
---
---
4
---
---
8.5
---
---
17
---
---
34
---
---
0.3
A
---
---
2000
mW
---
---
2500
mW
Compliance to EN 55022,class A and FCC part 15,class A
Output Specifications
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Transient Recovery Time
Transient Response Deviation
Temperature Coefficient
Over Load Protection
Short Circuit Protection
Conditions
Dual Output, Balanced Loads
Vin=Min. to Max.
Io=25% to 100%
5V Output Models
Other Output Models
Over Line, Load & Temp.
25% Load Step Change
Foldback
Min.
---
---
---
---
---
---
---
---
---
---
---
120
Continuous
Typ.
±0.5
±0.5
±0.3
±0.5
75
100
---
---
150
±3
±0.02
150
Max.
±1.0
±2.0
±0.5
±1.0
100
150
180
15
500
±6
±0.05
---
Unit
%
%
%
%
mV
P-P
mV
P-P
mV
P-P
mV rms
uS
%
%/℃
%
Isolation, Safety Standards
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Test Voltage
Leakage Current
I/O Isolation Resistance
I/O Isolation Capacitance
Safety Standards
Conditions
60 Seconds
Flash tested for 1 Second
240VAC, 60Hz
500 VDC
100KHz, 1V
Min.
Typ.
4000
---
6000
---
---
---
10
---
---
7
cUL/UL60950-1, CSA C22.2 No. 60950-1-03
UL60601-1,CSA C22.2 No.601-1
IEC/EN 60950-1, IEC/EN 60601-1
IEC60950-1 CB report, cUL/UL 60950-1 certificate
UL60601-1 UL certificate
Max.
---
---
2
---
13
Unit
VACrms
V
PK
uA
GΩ
pF
Approvals
General Specifications
Parameter
Switching Frequency
MTBF(calculated)
MIL-HDBK-217F@25℃, Ground Benign
Conditions
Min.
---
1,000,000
Typ.
150
---
Max.
---
---
Unit
KHz
Hours
Input Fuse
5V Input Models
2000mA Slow-Blow Type
12V Input Models
1000mA Slow-Blow Type
24V Input Models
500mA Slow-Blow Type
48V Input Models
250mA Slow-Blow Type
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2011/09/22 REV:3
Page 2 of 4
®
Environmental Specifications
Parameter
Operating Temperature Range (with Derating)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature (1.5mm from case for 10Sec.)
Conditions
Ambient
Min.
-40
---
-50
---
Free-Air convection
---
MIHW1000 SERIES
DC/DC CONVERTER 3W,
Reinforced Insulation, Medical Safety
Max.
+85
+95
+125
95
260
Unit
℃
℃
℃
% rel. H
℃
Power Derating Curve
100
80
Natural
convection
100LFM
60
200LFM
400LFM
40
20
0
-40
~
0
20
40
60
80
100 110
Ambient Temperature
]
Notes
1
2
3
4
5
6
7
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Transient recovery time is measured to within 1% error band for a step change in output load of 75% to 100%.
Ripple & Noise measurement bandwidth is 0-20 MHz.
These power converters require a minimum output loading to maintain specified regulation, operation under no-load conditions will not damage these modules;
however, they may not meet all specifications listed.
All DC/DC converters should be externally fused at the front end for protection.
Other input and output voltage may be available, please contact factory.
Specifications subject to change without notice.
Package Specifications
Mechanical Dimensions
3.9 10.5 [0.41]
[0.15]
0.2 [0.008]
Pin Connections
Pin
1
11
12
13
15
23
1
11
12
Single Output
+Vin
No Pin
-Vout
+Vout
No Pin
-Vin
-Vin
Dual Output
+Vin
Common
No Pin
-Vout
+Vout
-Vin
-Vin
0.60 [0.024]
24
15.22 [0.60]
20.3 [0.80]
Bottom View
24
23
15
13
2.54
[0.10]
20.32 [0.80]
31.8 [1.25]
5.08
[0.20]
2.0
[0.08]
2.54
[0.10]
►
All
dimensions in mm (inches)
(X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
►
Tolerance: X.X±0.25
►
Pin
diameter
0.6 ±0.05 (0.024±0.002)
Physical Characteristics
Case Size
Case Material
Weight
:
:
:
31.8x20.3x10.5mm (1.25x0.8x0.41 Inches)
Non-Conductive Black Plastic (flammability to UL 94V-0 rated)
16.2g
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2011/09/22 REV:3
Page 3 of 4
®
MIHW1000 SERIES
DC/DC CONVERTER 3W,
Reinforced Insulation, Medical Safety
Test Configurations
Input Reflected-Ripple Current Test Setup
Input reflected-ripple current is measured with a inductor Lin (4.7uH) and Cin (220uF, ESR < 1.0Ω at 100 KHz) to simulate source impedance. Capacitor Cin, offsets
possible battery impedance. Current ripple is measured at the input terminals of the module, measurement bandwidth is 0-500 KHz.
To Oscilloscope
+
Battery
+
Lin
+Vin
Current
Probe
+Out
Load
DC / DC
Converter
-Vin
-Out
Cin
Peak-to-Peak Output Noise Measurement Test
Use a Cout 0.47uF ceramic capacitor. Scope measurement should be made by using a BNC socket, measurement bandwidth is 0-20 MHz. Position the load
between 50 mm and 75 mm from the DC/DC Converter.
+Vin
Single Output
DC / DC
Converter
-Vin
-Out
+Out
Copper Strip
Cout
Copper Strip
Resistive
Scope
Load
+Vin
Dual Output
DC / DC
Converter
-Vin
+Out
Com.
-Out
Copper Strip
Cout
Copper Strip
Cout
Copper Strip
Scope
Scope
Resistive
Load
Design & Feature Considerations
Overcurrent Protection
To provide protection in a fault (output overload) condition, the unit is equipped with internal current limiting circuitry and can endure current limiting for an unlimited
duration. At the point of current-limit inception, the unit shifts from voltage control to current control. The unit operates normally once the output current is brought back
into its specified range.
Input Source Impedance
The power module should be connected to a low ac-impedance input source. Highly inductive source impedances can affect the stability of the power module. In
applications where power is supplied over long lines and output loading is high, it may be necessary to use a capacitor on the input to insure startup. Capacitor
mounted close to the power module helps ensure stability of the unit, it is recommended to use a good quality low Equivalent Series Resistance (ESR < 1.0Ω at 100
kHz) capacitor of a 10uF for the 5V input devices and a 4.7uF for the 12V input devices and 2.2uF for the 24V and 48V devices.
+
DC Power
Source
-
+
Cin
-Vin
-Out
+Vin
DC / DC
Converter
+Out
Load
Output Ripple Reduction
A good quality low ESR capacitor placed as close as practicable across the load will give the best ripple and noise performance. To reduce output ripple, it is
recommended to use 3.3uF capacitors at the output.
+
DC Power
Source
-
-Vin
+Vin
Single Output
DC / DC
Converter
-Out
+Out
+
DC Power
Source
-
-Vin
+Vin
+Out
Dual Output
DC / DC
Com.
Converter
-Out
Cout
Cout
Load
Load
Cout
Load
Maximum Capacitive Load
The MIHW1000 series has limitation of maximum connected capacitance on the output. The power module may operate in current limiting mode during start-up,
affecting the ramp-up and the startup time. Connect capacitors at the point of load for best performance. The maximum capacitance can be found in the data
sheet.
Thermal Considerations
Many conditions affect the thermal performance of the power module, such as orientation, airflow over the module and board spacing. To avoid exceeding the
maximum temperature rating of the components inside the power module, the case temperature must be kept below 95℃. The derating curves are determined
from measurements obtained in a test setup.
Position of air velocity
probe and thermocouple
15mm / 0.6in
50mm / 2in
Air Flow
DUT
18, Sin Sin Road, An-Ping Industrial District, Tainan 702, Taiwan
