The MINMAX MKW40 series is a new generation of high performance dc-dc converter modules setting a new standard concerning power density. The
product offers fully 40W in an encapsulated, shielded metal package with dimensions of just 2.0”x1.0”x0.4”. All models provide wide 2:1 input voltage range
and precisely regulated output voltages.
Advanced circuit topology provides a very high efficiency up to 92% which allows an operating temperature range of -40°C to +80°C. Further features
include remote On/Off, trimmable output voltage, under-voltage shutdown as well as overload and over-temperature protection.
Typical applications for these converters are battery operated equipment, instrumentation,distributed power architectures in communication and industrial
electronics and many other space critical applications.
Model Selection Guide
Model
Number
Input
Voltage
(Range)
VDC
MKW40-12S033
MKW40-12S05
MKW40-12S12
MKW40-12S15
MKW40-12S24
MKW40-12D12
MKW40-12D15
MKW40-24S033
MKW40-24S05
MKW40-24S12
MKW40-24S15
MKW40-24S24
MKW40-24D12
MKW40-24D15
MKW40-48S033
MKW40-48S05
MKW40-48S12
MKW40-48S15
MKW40-48S24
MKW40-48D12
MKW40-48D15
VDC
3.3
5
12
15
24
±12
±15
3.3
5
12
15
24
±12
±15
3.3
5
12
15
24
±12
±15
Output
Voltage
Max.
mA
8000
8000
3330
2670
1670
±1670
±1330
8000
8000
3330
2670
1670
±1670
±1330
8000
8000
3330
2670
1670
±1670
±1330
Min.
mA
0
0
0
0
0
±145
±110
0
0
0
0
0
±145
±110
0
0
0
0
0
±145
±110
@Max. Load
mA(typ.)
2470
3750
3750
3700
3790
3790
3790
1220
1830
1830
1830
1850
1870
1870
610
920
910
910
920
940
940
@No Load
mA(typ.)
120
160
160
150
160
70
60
75
80
85
75
85
50
45
40
50
50
50
50
65
65
Output Current
Input Current
Reflected
Ripple
Current
mA (typ.)
Over
Voltage
Protection
VDC
3.9
6.2
15
18
30
±15
±18
3.9
6.2
15
18
30
±15
±18
3.9
6.2
15
18
30
±15
±18
μF
21000
13600
2400
1500
600
1200#
750#
21000
13600
2400
1500
600
1200#
750#
21000
13600
2400
1500
600
1200#
750#
# For each output
Max. capacitive
Load
Efficiency
(typ.)
@Max. Load
%
89
89
89
90
88
88
88
90
91
91
91
90
89
89
90
91
92
92
90
89
89
12
(9 ~ 18)
50
24
(18 ~ 36)
30
48
(36 ~ 75)
20
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2012/07/16 REV:13
Page 1 of 9
®
Input Specifications
Parameter
Input Surge Voltage (1 sec. max.)
Model
12V Input Models
24V Input Models
48V Input Models
12V Input Models
24V Input Models
48V Input Models
12V Input Models
24V Input Models
48V Input Models
Min.
-0.7
-0.7
-0.7
Typ.
---
---
---
---
---
---
8.3
16.5
33
MKW40 SERIES
DC/DC CONVERTER 40W,
Highest Power Density
Max.
25
50
100
Unit
Start-Up Threshold Voltage
Under Voltage Lockout
Input Polarity Protection
Start Up Time
Internal Filter Type
Short Circuit Current
Power Up
Remote On/Off
---
9
VDC
---
18
---
36
---
---
---
---
---
---
None
---
---
30
ms
Nominal Vin and Constant Resistive Load
---
---
30
ms
All Models
LC Filter (for EN55022,Class A compliance see page 8)
--- (Hiccup Mode 1.5 Hz typ.)
Output Specifications
Parameter
Output Voltage Setting Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Load Cross Regulation (Dual Output)
Minimum Load
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Transient Recovery Time
Temperature Coefficient
Over Load Protection
Short Circuit Protection
Over Voltage Protection
Conditions
At 50% Load and Nominal Vin
Dual Output, Balanced Loads
Vin=Min. to Max.
Single Output
Min. Load to Full Load
Dual Output
Asymmetrical Load 25%/100% Full Load
Min.
---
---
---
---
---
---
Typ.
---
---
---
---
---
---
Max.
±1.0
±2.0
±0.5
±0.5
±1.0
±5.0
Unit
%Vnom.
%
%
%
%
%
No Minimum Load Requirement for Single Output Models, for dual Output Models see Table
3.3V & 5V Output Models
---
100
---
mV
P-P
12V, 15V & 24V Models
---
150
---
mV
P-P
Dual Output Models
---
150
---
mV
P-P
25% Load Step Change
---
250
---
μsec
---
---
±0.02
%/℃
Current Limitation at 150% typ. of Iout max., Hiccup
