Standard Gain Horns
SMA & 2.92mm
Female Connectors
Product Features
•
•
•
•
Standard WaveguideSizes
1.70-40 GHZ
Gain 10, 15, & 20 dB
15 Octave bands
Specifications
(1)
Parameter
Impedance
Minimum Frequency
Maximum Frequency
Polarization
VSWR
Body
Flanges
Connector
Value
50
1.70
40
Linear
1.25
Aluminum
STD UG Flanges
SMA Female
2.92mm Female
Units
Ohms
GHz
GHz
Description
Stainless Steel, 1.7 to 18 GHz
Stainless Steel, 18 GHz to 40 GHz
(1) Pasternack reserves the right to change specifications or information without notice.
(2) All Specifications “typical”
www.pasternack.com
PO Box 16759. Irvine, CA 92623-6759
Toll Free: (866) 727-8376
Direct: +1 (949) 261-1920
Fax: +1 (949) 261-7451
Email:
sales@pasternack.com
Standard Gain Horns
SMA & 2.92mm
Female Connectors
Specifications
SMA/2.92mm
CONNECTOR
MODEL NO.
PE9850/2F-10
PE9850/2F-15
PE9850/2F-20
PE9851/2F-10
PE9851/2F-15
PE9851/2F-20
PE9852/2F-10
PE9852/2F-15
PE9852/2F-20
PE9853/SF-10
PE9853/SF-15
PE9853/SF-20
PE9854/SF-10
PE9854/SF-15
PE9854/SF-20
PE9855/SF-10
PE9855/SF-15
PE9855/SF-20
PE9856/SF-10
PE9856/SF-15
PE9856/SF-20
PE9857/SF-10
PE9857/SF-15
PE9857/SF-20
PE9858/SF-10
PE9858/SF-15
PE9858/SF-20
PE9859/SF-10
PE9859/SF-15
PE9859/SF-20
PE9860/SF-10
PE9860/SF-15
PE9860/SF-20
PE9861/SF-10
PE9861/SF-15
PE9861/SF-20
PE9862/SF-10
PE9862/SF-15
PE9862/SF-20
PE9863/SF-10
PE9863/SF-15
PE9863/SF-20
PE9864/SF-10
PE9864/SF-15
PE9864/SF-20
(1)
& Ordering Information
Description
WAVEGUIDE
SIZE
WR28
FREQUENCY
RANGE
(DC TO GHz)
26.50-40.00
3 dB Width
GAIN
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
10 dB
15 dB
20 dB
E-Plane
54.2°
32.1°
16.7°
54.1°
23.1°
17.0°
58.0°
31.3°
17.5°
55.1°
32.0°
16.9°
55.3°
30.1°
18.8°
50.2°
35.4°
16.3°
48.5°
29.3°
16.1°
55.5°
29.6°
17.0°
56.8°
32.4°
19.3°
55.1°
33.7°
18.7°
59.8°
31.3°
14.3°
55.0°
33.8°
18.9°
58.6°
32.7°
17.1°
50.8°
31.0°
17.2°
64.8°
33.1°
17.3°
H-Plane
54.4°
31.3°
18.3°
53.2°
40.8°
17.4°
57.0°
31.5°
17.8°
54.2°
31.8°
18.0°
50.9°
31.2°
18.9°
49.2°
28.5°
17.2°
47.4°
29.0°
16.5°
54.1°
29.3°
16.7°
55.2°
32.0°
19.3°
54.2°
33.2°
18.8°
48.3°
30.8°
16.9°
54.1°
33.3°
19.2°
51.9°
32.4°
16.7°
54.1°
30.6°
16.5°
45.4°
32.0°
17.4°
A
1.56
2.44
3.69
1.68
2.67
4.13
1.94
3.06
4.72
2.07
8.30
5.65
2.00
3.48
6.80
2.88
5.70
8.85
2.82
6.45
11.06
4.13
7.28
12.28
4.02
7.79
12.27
4.41
7.80
13.45
6.04
9.66
13.38
17.51
11.28
16.88
17.98
7.05
25.63
9.90
23.15
32.15
14.00
26.6
44.00
Dimensions
B
0.50
0.84
1.45
0.65
1.07
1.86
0.69
1.22
2.26
0.89
1.60
2.60
1.15
1.88
3.00
1.39
2.36
4.00
1.70
2.80
5.00
1.69
2.40
5.68
1.75
3.05
5.10
2.15
3.53
6.45
2.80
4.43
10.00
3.29
4.98
9.08
3.71
6.63
12.40
4.40
9.00
15.70
8.15
11.85
22.25
C
0.40
0.62
1.10
0.50
0.82
1.40
0.52
0.92
1.77
0.70
1.16
2.04
0.82
1.47
2.24
1.04
1.45
3.10
1.27
2.05
3.70
1.27
3.15
4.04
1.30
2.25
3.77
1.60
2.60
4.65
1.70
3.27
7.80
2.19
3.67
6.70
2.73
6.00
8.75
3.58
5.60
10.80
4.14
8.50
16.20
WR28 Standard Gain Horn with 2.92mm
Female Connector 10, 15 & 20 dB Gain
WR34 Standard Gain Horn with 2.92mm
Female Connector 10, 15 & 20 dB Gain
WR42 Standard Gain Horn with 2.92mm
Female Connector 10, 15 & 20 dB Gain
WR51 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR62 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR75 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR90 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR102 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR112 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR137 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR159 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR187 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR229 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR284 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR430 Standard Gain Horn with SMA
Female Connector 10, 15 & 20 dB Gain
WR34
22.00-33.00
WR42
18.00-26.50
WR51
15.00-22.00
WR62
12.40-18.00
WR75
10.00-15.00
WR90
8.20-12.40
WR102
7.00-11.00
WR112
7.05-10.00
WR137
5.85-8.20
WR159
4.90-7.05
WR187
3.95-5.85
WR229
3.30-4.90
WR284
2.60-3.95
WR430
1.70-2.60
(1) Pasternack reserves the right to change specifications or information without notice.
(2) All Specifications “typical”
www.pasternack.com
