WRA_SP-2W Series
WIDE INPUT ISOLATED & REGULATED
2W OUTPUT DUAL OUTPUT
DIP PACKAGE
FEATURES
●
Wide (2:1) Input Range
●
Efficiency Up To 82%
●
Operating Temperature:
-40°C~+85°C
●
1.5KVDC Isolation
●
Single Output
●
Metal Shielding Package
●
No Heat Sink Required
●
Industry Standard Pin out
●
MTBF>1,000,000 hours
●
RoHS
Compliance
RoHS
multi-country patent protection
PRODUCT PROGRAM
Part
Number
WRA0505SP-2W
WRA0509SP-2W
WRA0512SP-2W
WRA0515SP-2W
WRA1205SP-2W
WRA1209SP-2W
WRA1212SP-2W
WRA1215SP-2W
WRA1505SP-2W
WRA1509SP-2W
WRA1512SP-2W
WRA1515SP-2W
WRA2405SP-2W
WRA2409SP-2W
WRA2412SP-2W
WRA2415SP-2W
WRA4805SP-2W
WRA4809SP-2W
WRA4812SP-2W
WRA4815SP-2W
Input
Output
Voltage (VDC)
Voltage Current (mA)
Nominal
Range
Max* (VDC) Max
Min
5
5
5
5
12
12
12
12
15
15
15
15
24
24
24
24
48
48
48
48
4.5~9VDC
4.5~9VDC
4.5~9VDC
4.5~9VDC
9~18VDC
9~18VDC
9~18VDC
9~18VDC
12~24VDC
12~24VDC
12~24VDC
12~24VDC
18~36VDC
18~36VDC
18~36VDC
18~36VDC
36~72VDC
36~72VDC
36~72VDC
36~72VDC
11
11
11
11
22
22
22
22
30
30
30
30
40
40
40
40
80
80
80
80
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±200
±110
±83
±66
±200
±110
±83
±66
±200
±110
±83
±66
±200
±110
±83
±66
±200
±110
±83
±66
±20
±11
±8
±6
±20
±11
±8
±6
±20
±11
±8
±6
±20
±11
±8
±6
±20
±11
±8
±6
Efficiency
(%, Typ)
67
68
70
72
72
73
77
79
75
79
80
81
78
80
81
82
76
81
81
82
Package
Style
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
APPLICATIONS
The WRA_SP-2W Series are specially
designed for applications where a wide
range input voltage power supplies are
isolated from the input power supply in a
distributed power supply system on a circuit
board.
These products apply to:
1) Where the voltage of the input power
supply is wide range (voltage range: 2:1);
2) Where isolation is necessary between
input and output
(Isolation Voltage =1500VDC);
3) Where the regulation of the output
voltage and the output ripple noise are
demanded.
ISOLATION SPECIFICATIONS
MODEL SELECTION
WRA0512SP-2W
Rated Power
Package Style
Output Voltage
Input Voltage
Product Series
Item
Isolation voltage
Isolation resistance
Test conditions
Flash tested for 60 seconds
Test at 500VDC
Min
1500
1000
Typ
Max
Units
VDC
MΩ
OUTPUT SPECIFICATIONS
Item
2W Output Power
Positive Voltage Accuracy
Negative Voltage Accuracy
Load Regulation
Line Regulation
Temperature Drift(Vout)
Ripple
Noise
Switching Frequency
Test Conditions
See Below Products Program
Refer To Recommended Circuit
Refer To Recommended Circuit
From 10% To 100% Load
Input Voltage From Low To High
Refer To Recommended Circuit
20Hz-300KHz Bandwidth
DC-20MHz Bandwidth
100% Load, Nominal Input Voltage
10% Load, Nominal Input Voltage
Min
0.2
Typ
±1
±3
±0.5
±0.2
30
80
80
250
Max Units
2
W
±3
±5
%
±1
±0.5
0.03 %/
°C
60
mVp-p
150
200
KHz
600
MORNSUN Science& Technology Ltd.
Address: 8th floor 8th building, Huangzhou
Industrial District, Guangzhou, China
Tel: 86-20-38601850
Fax: 86-20-38601272
Http://www.mornsun-power.com
Note:
1.All specifications measured at T
A
=25°C, humidity<75%, nominal input voltage and rated output load unless otherwise
specified.
2.See below recommended circuits for more details.
MORNSUN reserves the copyright
Edition: A
NOV-2005
Page 1 of 2
COMMON SPECIFICATION
Output Short Circuit Protection
Temperature Rise at Full Load
Cooling
No-load Power Consumption
Operating Temperature Range
Storage Temperature Range
Lead Temperature***
Storage Humidity Range
Case Material
MTBF
Continuous
30
°
C (TYP)
Free Air Convection
100mW (typical)
-40°C~+85°C
-55°C ~+125°C
300°C (1.5mm from case for 10 seconds)
≤
95%
Vo+
0V
Vo-
Metal
>1,000,000 hours
Input Current(A)
Ip
***Lead Temperature 1.5mm from case for 10 seconds.
TYPICAL CHARECTERISTICS
Temperature Derating Graph
Input Voltage
Range
Input Voltage (V)
supply and the rippled voltage do not exceed
the module standard. Input current of power
supply should afford the startup current of this
kind of DC/DC module. (See figure 2)
External Capacitor
Although this series of DC/DC converter can
work without external capacitor, in order to keep
an optimum performance, however, it needs
external capacitor. (See Table 1)
Operating Temp.(
C
)
Requirement on Output Load
To ensure this module operate efficiently and
reliably, a minimum load is specified for this kind
of DC/DC converter in addition to a maximum
load (namely full load). During operation, make
sure the specified range of input voltage is not
exceeded, the minimum out put load is not less
than
10%
Of the full load, and that this product
FOOTPRINT DETAILS
Bottom View
2
1
3
4
5
Pin
1
2
3
4
5
Vin
GND
-Vo
0V
+Vo
should never be operated under no
load!!!
If the actual load is less below the
specified minimum load, the output ripple of this
type of DC/DC converter will increase
drastically and at the same time efficiency &
reliability of the circuit will decrease deeply .If
the actual output power from the load in your
circuit is very small, please connect a resistor
with proper resistance at the output end to in
parallel to increase the load, or use our
company’s other products with a lower rated
output power.
OUTLINE DIMENSIONS & RECOMMENDED FOOTPRINT
32.0
9.65
3
4
5
8.5
0.8
12.7
3.6
20.0
6.35
2
1
The products cannot be used in
parallel and in plug and play.
External Capacitor Table
(See Table 1)
Vin
5V
&
12V
24V
&
48V
C
in
100uF
10uF
C
out
(0+70°C)
100uF
(electrolytic
capacitor)
C
out
(-40+85°C)
47uF
(tantalum
capacitor)
5.2
21.59
4.00
Bottom View
APPLICATION NOTE
Recommended Circuit
Side View
Note: All Pins on a 2.54mm pitch; All Pin diameters are 0.50 mm(Tolerance:±0.15);
All the WRA_SP-2W Series have been tested according to the following recommended testing circuit
before leaving factory. This series should be tested under load. Never be tested under no load (See
Figure 1 & 2). If you want to further decrease the input/output ripple, you can increase capacitance
properly or choose capacitors with low ESR. However, the capacitance should not be too high.(See
table 1).If you want to use the products in high EMI, please choose our metal packaged products.
MORNSUN Science& Technology Ltd.
Input Current
When it is used in unregulated power supply, be sure that the fluctuating range of the power
Address: 8th Floor 8th Building, Huangzhou
Industrial District, Guangzhou, China
Tel :86-20-38601850
Fax:86-20-38601272
Http:// www.mornsun-power.com
MORNSUN reserves the copyright
Edition: A
NOV-2005
Page 2 of 2
