50 Ohm 0.5 Watts Brass TNC Male RF Load Up To 1,000 MHz
TECHNICAL DATA SHEET
50 Ohm 0.5 Watts Brass TNC Male RF Load Up To 1,000 MHz
Configuration
Connector
TNC Male
PE6011-50
Electrical Specifications
Frequency Range, MHz
Impedance, Ohms
Maximum Input Power, Watts
DC to 1,000
50
+27
Mechanical Specifications
Temperature
Size
Length, in [mm]
Width/Dia., in [mm]
.
1.17 [29.72]
0.59 [14.99]
Connector
Type
Inner Conductor Material and Plating
Outer Conductor Material and Plating
Body Material and Plating
Dielectric Type
TNC Male
Gold
Brass, Nickel
Brass, Nickel
PTFE
Compliance Certifications
(visit www.Pasternack.com for current document)
RoHS Compliant
Yes
Plotted and Other Data
Notes:
Values at 25 °C, sea level
URL:
http://www.pasternack.com/0.5-watts-tnc-male-rf-load-up-to-1-ghz-pe6011-50-p.aspx
50 Ohm 0.5 Watts Brass TNC Male RF Load Up To 1,000 MHz from Pasternack Enterprises has same day shipment for
domestic and International orders. Our RF, microwave and fiber optic products maintain a 99% availability and are part of the
broadest selection in the industry.
PE6011-50 REV
1
PE6011-50
CAD Drawing
50 Ohm 0.5 Watts Brass TNC Male RF Load Up To 1,000 MHz
© 2012 Pasternack Enterprises All Rights Reserved
PE6011-50 REV
2
