DF 030..., DWA 045...
Vishay Draloric
Feed-Through Capacitors, Tag Mounting
DF 030070 7 KV
P
DF 030090 7 KV
P
DF 030110 7 KV
P
18
+ 1
(0.709
+ 0.04)
ø 5.2
+ 0.2
Holes
(0.205
+ 0.008
)
12 x 0.5
(0.472 x 0.02)
DWA 045120 8 KV
P
to 16 KV
P
DWA 045150 8 KV
P
to 16 KV
P
12 x 0.7
(0.472 x 0.028)
20
- 1
(0.787
- 0.04)
=
0.8
(0.031)
ø 45
(1.772 DIA)
L
=
ø
30
(1.181 DIA)
0.8
(0.031)
=
ø 65
(2.559 DIA)
ø 6
+ 0.3
(0.236
+ 0.012
)
ø 45
(1.772 DIA)
ø 4.3
+ 0.3
(0.169
+ 0.012
)
Holes
ø 5.2
+ 0.2
(0.205
+ 0.008
) Holes
60
±
1.5
(2.362
±
0.020)
42.5
±
0.3
(1.637
±
0.020)
120
±
0.5
(4.724
±
0.02)
42.5
±
1.5
(1.673
±
0.059)
60
±
1.5
2.362
±
0.059
110
±
0.5
(4.331
±
0.02)
=
60°
L
Holes
• Dimensions in millimeters (inches)
MODEL
Length L
DF 030070
70 (2.756)
DF 030090
93 (3.661)
DF 030110
110 (4.331)
MODEL
Length L
DWA 045120
120 (4.724)
DWA 045150
150 (5.906)
MATERIAL:
Capacitor elements made from Class 1 ceramic dielectric
with noble metal electrodes.
Connection Terminals: Copper/brass, silver plated.
MARKING:
Type designator, Capacitance value and tolerance, Rated
voltage (peak value), Production date code, Ceramic
material code, DRALORIC Logo.
FINISH:
Noble metal electrodes completely lacquered. Contoured
rims glazed.
ORDERING INFORMATION
DF 030090
MODEL
www.vishay.com
1
7 KVp
RATED VOLTAGE
1200 pF
CAPACITANCE VALUE
± 10 %
TOLERANCE
R
85
CERAMIC
Document Number: 22102
Revision: 21-Nov-01
