DBF 050166, DBF 050180
Vishay Draloric
Feed-Through Capacitors with Conductor Rod
DBF 050166 25 KV
P
5/16-18 UNC Thread (Both ends)
DBF 050180 30 KV
P
SW 17
(0.669 HEX)
M10 Thread (Both ends)
22
±
2
(0.87
±
0.08)
84
±
2
(3.31
±
0.08)
2
(0.08)
=
210
±
5 (8.27
±
0.20)
Ø 96
(3.780 DIA)
Ø 96
(3.780 DIA)
=
Ø 50
(1.969 DIA)
Ø 50
(1.969 DIA)
130
±
0.5
(5.118
±
0.02)
110
±
0.5
(4.331
±
0.02)
130
±
0.5
(5.118
±
0.02)
110
±
0.5
(4.331
±
0.02)
45°
45°
45°
45°
6.3
+ 0.3
+ 0.012
6.3
+ 0.3
Holes
(0.248
+ 0.012
)
• Dimensions in millimeters (inches)
MATERIAL:
Capacitor elements made from Class 1 ceramic dielectric
with noble metal electrodes.Connection terminals: Copper/
brass, silver plated.
MARKING:
Type designator, Capacitance value and tolerance, Rated
voltage (peak value), Production date code, Ceramic
material code, DRALORIC Logo.
FINISH:
Noble metal electrodes completely lacquered. Contoured
rims glazed and has additional moisture protection (silicone
rubber).
ACCESSORIES ADDED:
Hex. nuts/screws and washers.
ORDERING INFORMATION
DBF 050180
MODEL
30
KV
P
RATED VOLTAGE
2000 pF
CAPACITANCE VALUE
± 20 %
TOLERANCE
R 230
CERAMIC
www.vishay.com
1
For technical questions contact: powcap@vishay.com
Document Number: 22108
Revision: 24-Jan-02
180
±
2 (7.087
±
0.08)
225
±
2 (8.858
±
0.08)
166
±
3 (6.54
±
0.12)
2
(0.08)
