Amphenol
Miniature Box Interconnects
G869H
Materials
Housing
Contacts
Finish
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– Gold Flash/75 Cycles
– 3A
– 250 VAC/rms 60Hz
2.54mm Crimp SIL Latch Socket Housing
Related Information
Pin Headers
Auto-termination
– G888 see below
– Consult representative
Highly reliable Crimp contact System for mass termination. Polarized with a locking mechanism.
Related Information
Electrical
Current
Voltage
Part Number System:
G869H XX X X
2.54mm SIL Housing
Polarized/Latched
NUMBER OF POSITIONS
02 to 12 Position
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
COLOUR OF INSULATOR
2: Black
G869C124
4
7.62
10.16
Contacts
22~24AWG
Positions
A
Dim
B
Part Number:
2
2.54
5.08
Gold Flash Finish, Left Hand Feed, 10K Reel
6
12.70
15.24
3
5.08
7.62
5
10.16
12.70
7
15.24
17.78
8
17.78
20.32
9
20.32
22.86
10
22.86
25.40
11
25.40
27.94
12
27.94
30.48
Dimensions in mm
SKT-G869CXXX-16 Rev. B/
SKT-G869HXXX-16 Rev. B
G888
Materials
Housing
Contacts
2.54mm SIL Protected Header for G869H
Durability
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– 3A
– 250 VAC/rms 60Hz
Gold Flash
10µ” Gold
30µ” Gold
– 75 cycles
– 150 cycles
– 250 cycles
– G869H see above
Straight PCB Mount
Electrical
Current
Voltage
Mating Half
Receptacles
Part Number System:
G888 X XX 0 X1 X
2.54mm Protected Header
Through-hole type
CONNECTOR STYLE
0: Right Angle type
1: Straight type
NUMBER OF POSITIONS
02 to 12 Positions
No. of Positions
A
Dim
B
C
2
7.62
5.59
2.54
FACTORY CODE
Blank: Standard
H: High Temperature
CONTACT FINISH
0: Gold flash
1: 10µ” Gold
2: 30µ” Gold
Suffix may be added
to Part Number.
This Suffix is for
Internal use mainly.
Additional Suffix ‘EU’
or ‘LF’ may be
added for RoHS
compliant product.
Dimensions in mm
Right Angle PCB Mount
3
10.16
8.13
5.08
4
12.70
10.67
7.62
5
15.24
13.21
10.16
6
17.78
15.75
12.70
7
20.32
18.29
15.24
8
22.86
20.83
17.78
9
25.40
23.37
20.32
10
27.94
25.91
22.86
11
30.48
28.45
25.40
12
33.02
30.99
27.94
PNS-8881 Rev. B
PHD-G8881XXXX2-15 Rev. A/PHD-G8880XX0X2Y-15 Rev. AX1
G55H
Materials
Housing
Contacts
Finish
2.54mm Crimp Socket Housing and Contact
Circuit sizes
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– Gold Flash/75 Cycles
– G-17/18/19
2 to 80 circuits
Electrical
Current
Voltage
– 3A
– 250 VAC/rms 60Hz
Mating Half
Pin Headers
Part Number System:
G55H X XX X X
2.54mm Housing
Crimp Socket type
CONNECTOR STYLE
1: Single row
2: Double row
NUMBER OF POSITIONS
02 to 40: Single row
04 to 80: Double row
FACTORY CODE
A: Standard
B: With polarizing key
COLOUR OF INSULATOR
1: White
Suffix may be added
to Part Number.
2: Black
This Suffix is for
Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
Contacts
22~28AWG
Calculating
Dimensions
AMTA
Part Number:
G55C1224
Gold Flash Finish, Left Hand Feed, 10K Reel
Dimensions in mm
SIL DIM ‘A’ Positions x 2.54-2.54 (mm), DIM ‘B’ Positions x 2.54 (mm)
DIL DIM ‘A’ Positions/2 x 2.54-2.54 (mm), DIM ‘B’ Positions/2 x 2.54 (mm)
PNS-55HC Rev. A/SKT-G55HCXXA-16 Rev. A
G-23
