MBR20150CT/FCT/CR/CG
Power Schottky Rectifier - 20Amp 150Volt
□
Features
-Plastic package has Underwriters Laboratory Flammability Classifications 94V-0
-High Junction Temperature Capability
-Low forward voltage, high current capability
-High surge capacity
-Low power loss, high efficiency
-ESD performance human body mode > 6 KV
□
Application
-AC/DC Switching Adaptor and other Switching Power Supply
-TFT-LCD and DVD Power Supply
□
Absolute maximum ratings
Symbol
Ratings
20
150
150
0.69
-50 to +175
Unit
A
V
A
V
ºC
Conditions
Average Forward Current
Repetitive Peak Reverse Voltage
Peak Forward Surge Current
Forward Voltage Drop
Operating and Storage Temperature
I
F(AV)
V
RRM
I
FSM
V
F
T
j,
T
stg
□
Electrical characteristics
Parameters
Symbol
Ratings
Conditions
Per Leg at
I
F
= 10A
Maximum Instantaneous Forward Voltage
V
F
0.88V
0.69V
Tc = 25ºC
Tc = 125ºC
Per Leg at
V
R
= 150V
Maximum Reverse Leakage Current
I
R
0.05mA
10mA
Tc = 25ºC
Tc = 125ºC
Per Leg
TO-220AB / TO-262/ TO-263
ITO-220AB
Typical Thermal Resistance,Junction to Case
R
θ
(j-c)
2.2
ºC/W
4.5
ºC/W
June 2012 / Rev.6.8
http:// www.sirectsemi.com
1
MBR20150CT/FCT/CR/CG
AVERAGE FORWARD CURRENT
AMPERES
8
PEAK FORWARD SURGE CURRENT
AMPERES
10
150
120
6
90
4
60
2
30
8.3ms Single Half-Sine-Wave
(JEDEC METHOD)
0
25
50
75
100
125
150
175
0
1
2
5
10
20
50
100
AMBIENT TEMPERATURE (ºC)
NUMBER OF CYCLES AT 60Hz
Figure 1. Forward Current Derating Curve
Figure 2. Maximum Non-repetitive Surge Current
100
100
INSTANTANEOUS REVERSE CURRENT, (mA)
10
INSTANTANEOUS FORWARD CURRENT, (A)
10
12
5º
C
=
T
J
T
J
=
75
ºC
1
T
J
= 125ºC
0.1
T
J
= 75ºC
1.0
0.01
T
J
= 25ºC
0.001
0
20
40
60
80
100
0.1
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
Figure 3. Typical Reverse Characteristics
1000
Figure 4. Typical Forward Characteristics
CAPACITANCE, (pF)
100
T
J
= 25ºC
f = 1MHz
10
0.1
1
4
10
100
REVERSE VOLTAGE, VOLTS
Figure 5. Typical Junction Capacitance
Sirectifier Global Corp., Delaware, U.S.A.
U.S.A.:
sgc@sirectsemi.com
France:
ss@sirectsemi.com
Taiwan:
se@sirectsemi.com
Hong Kong:
hk@sirectsemi.com
China:
st@sirectsemi.com
…Thailand:
th@sirectsemi.com
Philippines:
aiac@sirectsemi.com
Belize:
belize@sirectsemi.com
T
J
=
25
ºC
http:// www.sirectsemi.com
2
