1260 COUPLED INDUCTORS
High Reliability Coupled Inductors
MS590PND
The MS590PND series of shielded coupled inductors was
designed specifically for high temperature applications –
up to 155°C. Tin-lead (Sn-Pb) terminations are used for
the best possible board adhesion.
The excellent coupling coefficient (k
≥
0.98) makes it ideal
for use in SEPIC applications. In SEPIC topologies, the
required inductance for each winding in a coupled induc-
tor is half the value needed for two separate inductors,
allowing selection of a part with lower DCR and higher
current handling.
These inductors provide high inductance, high efficiency,
excellent current handling and 500 V isolation in a very
rugged part. They are well suited for use as VRM induc-
tors in high-current DC-DC and VRM/VRD controllers.
They can also be used as two single inductors connected
in series or parallel, as a common mode choke or as a
1 : 1 transformer.
0.484
max
12,3
Dot indicates pin1
Dash number
Internal code
+
L1
V
IN
Q1
C1
D1
+
+
Load
V
OUT
0.484
max
12,3
123
X
L2
C2
–
Refer to Application Note, Document 639,
“Selecting Coupled Inductors for SEPIC Applications”
–
Typical SEPIC schematic
0.236 ±0.008
*
6,0 ±0,2
Suggested
Land Pattern
0.217
5,5
0.157
4,0
2
3
0.197
5,0
0.138
3,5
0.197
5,0
3
2
4
1
0.177
4,5
4
1
0.059
1,5
0.079
2,0
*
Dimensions are for the mounted part.
Dimensions before mounting can be
an additional 0.006 inch (0,152 mm).
1
L1
3
2
L2
4
Dimensions are in
inches
mm
Core material
Ferrite
Terminations
Tin-lead (63/37) over tin over nickel over phos bronze
Weight:
2.8 – 3.2 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55C to +155°C.
Tape and reel packaging: –55°C to +80°C
Winding to winding isolation
500 Vrms
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Winding-to-winding and winding-to-core isolation
500 Vrms
Enhanced crush-resistant packaging
500/13″ reel;
Plastic tape: 24 mm wide, 0.35 mm thick, 16 mm pocket spacing,
6.6 mm pocket depth
®
Specifications subject to change without notice.
Please check our website for latest information.
Document MS703-1
Revised 07/13/12
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2012
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
1260 COUPLED INDUCTORS
MS590PND Series (1260)
Part number
1
MS590PND472MSZ
MS590PND562MSZ
MS590PND682MSZ
MS590PND822MSZ
MS590PND103MSZ
MS590PND123MSZ
MS590PND153MSZ
MS590PND183MSZ
MS590PND223MSZ
MS590PND273MSZ
MS590PND333MSZ
MS590PND393MSZ
MS590PND473MSZ
MS590PND563MSZ
MS590PND683MSZ
MS590PND823MSZ
MS590PND104MSZ
MS590PND124KSZ
MS590PND154KSZ
MS590PND184KSZ
MS590PND224KSZ
MS590PND274KSZ
MS590PND334KSZ
MS590PND394KSZ
MS590PND474KSZ
MS590PND564KSZ
MS590PND684KSZ
MS590PND824KSZ
MS590PND105KSZ
Inductance
2
DCR max
3
(µH)
(Ohms)
4.7 ±20%
0.036
5.6 ±20%
0.040
6.8 ±20%
0.048
8.2 ±20%
0.052
10 ±20%
0.060
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
0.074
0.085
0.097
0.116
0.124
0.134
0.142
0.174
0.198
0.216
0.274
0.322
0.418
0.476
0.536
0.691
0.806
1.09
1.20
1.59
1.81
2.06
2.65
3.06
min
30.0
24.0
22.0
21.0
18.0
SRF (MHz)
4
typ
38.0
30.0
27.0
26.0
22.0
20.0
18.0
16.0
15.0
13.0
12.4
12.0
11.6
10.5
10.0
8.6
7.8
6.8
6.4
6.1
5.5
4.3
4.0
3.6
3.0
2.8
2.6
2.5
2.4
Coupling Leakage
coefficient L typ
typ
(µH)
0.98
0.20
0.98
0.20
0.98
0.24
0.98
0.25
0.99
0.26
0.99
0.99
0.99
0.98
0.99
0.99
0.99
0.99
0.99
>0.99
0.99
0.99
0.99
0.99
0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
0.28
0.32
0.40
0.67
0.50
0.65
1.09
0.80
0.75
0.57
1.52
1.41
1.34
1.52
1.80
1.60
2.23
2.39
3.72
2.89
2.55
5.76
2.86
4.32
10%
drop
9.00
8.00
7.00
6.44
5.40
5.30
4.60
4.50
4.00
3.60
3.30
3.00
2.70
2.50
2.30
2.10
1.90
1.60
1.50
1.40
1.30
1.10
1.00
0.950
0.900
0.800
0.700
0.640
0.590
Isat
(A)
5
20%
30%
drop drop
10.18 11.08
9.06
9.84
8.00
8.64
7.38
7.98
6.32
6.88
6.18
5.30
5.22
4.62
4.14
3.80
3.48
3.12
2.90
2.66
2.40
2.18
1.84
1.76
1.64
1.48
1.30
1.16
1.11
0.994
0.908
0.804
0.732
0.674
6.70
5.80
5.68
5.02
4.50
4.14
3.82
3.40
3.14
2.88
2.60
2.38
2.04
1.92
1.78
1.60
1.40
1.26
1.23
1.09
0.948
0.874
0.802
0.728
Irms
(A)
both
one
windings
6
winding
7
3.16
4.47
3.00
4.24
2.75
3.88
2.63
3.72
2.45
3.46
2.21
2.06
1.93
1.76
1.70
1.64
1.59
1.44
1.35
1.29
1.15
1.06
0.93
0.87
0.82
0.72
0.67
0.57
0.55
0.48
0.45
0.42
0.37
0.34
3.12
2.92
2.73
2.49
2.41
2.32
2.25
2.03
1.91
1.83
1.62
1.50
1.31
1.23
1.16
1.02
0.95
0.81
0.77
0.67
0.63
0.59
0.52
0.49
16.0
14.4
13.0
12.0
10.0
10.0
9.6
9.3
8.4
8.0
6.9
6.2
5.5
5.1
4.9
4.4
3.4
3.2
2.9
2.4
2.2
2.1
2.0
1.9
1. When ordering, please specify
testing
code:
MS590PND105KSZ
Testing: Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10004
2. Inductance shown for each winding, measured at 100 kHz, 0.1 Vrms,
0 Adc on an Agilent/HP 4284A LCR meter or equivalent. When leads
are connected in parallel, inductance is the same value. When leads
are connected in series, inductance is four times the value.
3. DCR is for each winding. When leads are connected in parallel, DCR
is half the value. When leads are connected in series, DCR is twice the
value.
4. SRF measured using an Agilent/HP 4191A or equivalent. When leads
are connected in parallel, SRF is the same value.
5. DC current, at which the inductance drops the specified amount from
its value without current. It is the sum of the current flowing in both
windings.
6. Equal current when applied to each winding simultaneously that
causes a 40°C temperature rise from 25°C ambient. See temperature
rise calculation.
7. Maximum current when applied to one winding that causes a 40°C
temperature rise from 25°C ambient. See temperature rise calculation.
8. Electrical specifications at 25°C.
Refer to Doc 639 “Selecting Coupled Inductors for SEPIC Applications.”
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Temperature rise calculation based on specified
Irms
®
Specifications subject to change without notice.
Please check our website for latest information.
Document MS703-1
Revised 07/13/12
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2012
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
