3316 POWER INDUCTOR
Outgassing Compliant Power Inductors
AE563PKA
■
High temperature materials allow operation in ambient
temperatures up to 155°C.
■
Tin-lead (Sn-Pb) soldered self-leaded construction for
excellent solderability.
■
Passes NASA low outgassing specifications
■
Very low DCR values and excellent current handling
Core material
Ferrite
Terminations
Tin-lead (63/37) over copper
Weight
0.95 – 1.25 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
750 per 13″ reel
Plastic tape: 24 mm wide, 0.35 mm thick, 12 mm pocket spacing,
6.4 mm pocket depth
DCR
(mOhm)
typ
max
3.0
6.0
6.0
9.0
10
11
13
18
24
25
30
35
38
48
58
70
85
100
128
136
172
200
260
310
360
452
508
618
727
963
1100
1300
1600
SRF
(MHz)
3
min
typ
200
122
100
86
74
63
57
54
46
43
38
35
30
26
25
21
20
19
16
14
12
11
10
9.5
8.3
8.3
7.0
6.0
5.3
4.6
4.4
3.9
3.6
238
153
125
108
92
79
71
68
57
53
48
44
38
33
31
27
25
24
20
18
15
14
13
12
10
10
8.7
7.5
6.6
5.8
5.5
4.8
4.3
Isat
(A)
4
10%
20%
30%
drop drop drop
14.0
8.6
7.0
6.2
6.0
5.1
4.7
4.3
4.0
3.6
3.3
2.9
2.7
2.5
2.2
2.1
1.9
1.7
1.5
1.3
1.2
1.1
0.85
0.82
0.80
0.70
0.65
0.62
0.50
0.44
0.42
0.41
0.35
16.0
10.2
8.4
7.4
6.7
6.0
5.5
5.2
4.4
4.1
3.7
3.4
3.1
2.9
2.5
2.4
2.1
1.9
1.7
1.5
1.4
1.3
1.2
1.1
0.96
0.85
0.80
0.70
0.70
0.54
0.48
0.46
0.44
17.0
10.9
9.3
8.1
7.2
6.4
6.0
5.5
4.8
4.4
4.0
3.7
3.4
3.1
2.8
2.6
2.3
2.1
1.9
1.7
1.5
1.4
1.3
1.2
1.1
0.98
0.86
0.80
0.65
0.62
0.58
0.53
0.48
Irms
(A)
5
20°C 40°C
rise
rise
8.0 12.0
6.1
8.8
3.4
5.6
3.2
5.0
2.9
4.5
2.7
4.2
2.4
4.0
2.4
4.0
2.4
3.7
2.2
3.3
2.2
3.3
2.2
3.2
2.1
3.1
1.7
2.7
1.9
2.6
1.9
2.5
1.8
2.4
1.3
1.9
1.3
1.8
1.3
1.8
1.1
1.5
0.9
1.3
0.82 1.2
0.81 1.2
0.80 1.1
0.68 0.90
0.63 0.87
0.54 0.76
0.53 0.73
0.43 0.62
0.41 0.57
0.38 0.53
0.34 0.47
1. When ordering, specify
testing
code:
AE563PKA301MSZ
Testing: Z
= COTS
H
= Screening per Coilcraft
CP-SA-10001
N
= Screening per Coilcraft
CP-SA-10004
2. Inductance tested at 100 kHz,
0.1 Vrms, 0 Adc using an Agilent/HP
4263B LCR meter or equivalent.
3. SRF measured using Agilent/
HP 8753D network analyzer or
equivalent..
4. Typical DC current at which the
inductance drops 10% (typ) from its
value without current.
5. Typical Current that causes a 40°C
temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface
Mount Components” before soldering.
Part number
1
AE563PKA301MSZ
AE563PKA901MSZ
AE563PKA122MSZ
AE563PKA182MSZ
AE563PKA222MSZ
AE563PKA272MSZ
AE563PKA332MSZ
AE563PKA392MSZ
AE563PKA472MSZ
AE563PKA562MSZ
AE563PKA682MSZ
AE563PKA822MSZ
AE563PKA103MSZ
AE563PKA123MSZ
AE563PKA153MSZ
AE563PKA183MSZ
AE563PKA223MSZ
AE563PKA273MSZ
AE563PKA333MSZ
AE563PKA393MSZ
AE563PKA473MSZ
AE563PKA563MSZ
AE563PKA683MSZ
AE563PKA823MSZ
AE563PKA104MSZ
AE563PKA124MSZ
AE563PKA154MSZ
AE563PKA184MSZ
AE563PKA224MSZ
AE563PKA274MSZ
AE563PKA334MSZ
AE563PKA394MSZ
AE563PKA474MSZ
Inductance
2
±20% (µH)
0.3
0.9
1.2
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
2.6
5.1
5.1
7.7
6.8
9.4
11.1
15.3
20.4
21.3
25.5
29.8
32.3
40.8
49.3
59.5
72.3
85
109
116
146
170
221
264
306
384
432
525
618
819
935
1105
1360
®
