SMT Power Inductors - DO5010H Series
•
Irms
ratings up to 15 A; saturation currents up to 30 A
• Heavy gauge wire for low DC resistance
Designer’s Kit C355
contains 3 of each part
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant tin-silver over copper. Other
terminations available at additional cost.
Weight
3.2 – 4.0 g
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
250 per 13″ reel Plastic tape: 32 mm wide,
0.38 mm thick, 24 mm pocket spacing, 7.8 mm pocket depth
PCB washing
Only pure water or alcohol recommended
DCR
max
(mOhm)
2.6
4.0
6.1
8.6
10
14
17
18
26
28
32
47
66
86
130
190
250
380
560
850
1100
1800
SRF
typ
3
(MHz)
156
100
75
60
55
40
35
35
28
26
20
20
15
9
8
7
6
5
4
3
2.5
2.0
1. When ordering, please specify
termination
and
packaging
codes:
Part Number
1
DO5010H-781ML_
DO5010H-152ML_
DO5010H-222ML_
DO5010H-332ML_
DO5010H-392ML_
DO5010H-472ML_
DO5010H-602ML_
DO5010H-782ML_
DO5010H-103ML_
DO5010H-123ML_
DO5010H-153ML_
DO5010H-223ML_
DO5010H-333ML_
DO5010H-473ML_
DO5010H-683ML_
DO5010H-104ML_
DO5010H-154ML_
DO5010H-224ML_
DO5010H-334ML_
DO5010H-474ML_
DO5010H-684ML_
DO5010H-105ML_
Inductance
2
±20% (µH)
0.78
1.5
2.2
3.3
3.9
4.7
6.0
7.8
10
12
15
22
33
47
68
100
150
220
330
470
680
1000
Isat
4
(A)
30
25
20
17
15
13
12
11
10
8.5
8.0
7.0
5.5
4.5
3.5
3.0
2.6
2.4
1.9
1.4
1.2
1.0
Irms
5
(A)
15
15
12
10
9.0
8.4
7.5
7.5
6.0
5.2
4.4
3.5
3.0
2.6
2.3
1.8
1.5
1.2
1.0
0.82
0.72
0.56
DO5010H-105MLD
Termination: L
= RoHS compliant tin-silver over copper.
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape.
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter D instead.
2. Inductance tested at 100 kHz, 0.1 Vrms using an Agilent/HP 4284A
LCR meter or equivalent.
3. SRF measured using Agilent/HP 8753D network analyzer.
4. DC current at which the inductance drops 10% (typ) from its value
without current.
5. Current that causes a 40°C temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 284-1
Revised 10/14/08
© Coilcraft, Inc. 2009
