PE Series
CHASSIS MOUNT, SINGLE AND DOUBLE STAGE EMI/RFI LINE FILTER.
MECHANICAL DIMENSIONS
(Unit: mm)
75.0
L
0.80 TYP.
L'
2x
5.00
N
N'
89.0
3.5x2 TYP.
6.40 TYP.
G
FEATURES
The PE series provides general-purpose common mode and
differential mode filters. These filters are designed in a small
package and offers single and double stage filtering.
APPLICATIONS
Computer & networking equipment, Measuring & control
equipment, Data processing equipment, laboratory instruments,
Switching power supplies, other electronic equipment.
51.0
TECHNICAL DATA
•
•
•
•
•
37.0
Rated Voltage: 250VAC
Rated Current: 5A, 10A, 15A, 20A, 30A
Power Line Frequency: 60Hz
Leakage Current: 0.8mA, 250VAC
Hipot Rating (one minute)
Line to Ground: 2250VDC
Line to Line: 1450VDC
•
Temperature Range: -25C to +85C
Specifications subject to change without notice. Dimensions (mm).
145 Algonquin Parkway, Whippany, NJ 07981 • 973-560-0019 • FAX: 973-560-0076
e-mail: filtersales@powerdynamics.com •
www.powerdynamics.com
31
PE Series Example & Ordering Code
PE
CURRENT RATING (A):
05
=
=
=
=
=
05
10
15
20
30*
Q - 1
TERMINAL:
QUICK CONNECT
SCREW
=Q
= PS
=1
=2
SCHEMATIC:
(ONE STAGE)
(TWO STAGE)
* Screw Mount Only
PE Series Attenuation Tables
Non-Medical Applications
Insertion loss in dB (50 Ohm circuit)
ONE STAGE
Current
Rating
5A
10A
15A
20A
30A
TWO STAGE
Comm. Mode(L-G) MHz
Diff. mode(L-L) MHz
.15 .5 1 5 10 30 .15 .5 1 5 10 30
6
28
23
14
16
42
42
39
22
24
38
37
31
24
26
35
34
28
31
29
37
34
30
34
38
32
35
23
28
39
30
5
9
9
14
40
44
39
32
22
33
42
37
31
34
29
39
33
36
35
31
40
36
39
42
27
38
27
34
40
Inductance
in mH
5.0
3.0
2.0
0.9
0.5
Current
Rating
5A
10A
15A
20A
Inductance
in mH
5.0
1.2
0.9
0.5
Comm. Mode(L-G) MHz
Diff. mode(L-L) MHz
.15 .5 1 5 10 30 .15 .5 1 5 10 30
53
26
28
14
84
63
57
39
70
76
68
49
58
66
67
63
53
62
63
59
51
42
46
38
7
8
15
13
57
77
33
25
58
72
60
57
57
62
59
64
52
57
56
57
48
53
61
45
SCHEMATICS
ONE STAGE
L mH
LOAD
TWO STAGE
Cx
0.1 F
Cy
3300pF
Cy
3300pF
L mH
LOAD
L
LINE
L'
L
LINE
L mH
Cx
0.1 F
Cx
0.1 F
L mH
10M
L mH
L'
Cx
0.1 F
N'
G
N
10M
Cx
0.1 F
L mH
G
N
N'
